QUICK INSTALLATION GUIDE
FOR ID/LED BOARD
MONUMENT SIGNAGE
1
#
<PRE-INSTALLATION>
PREPARING THE SITE
Dig and Form a hole based
on the Engineering Drawing.
2
#
PAPER TEMPLATE
Use the Paper template provided
to position the anchor bolts and the conduit.
3
#
SECURE THE
ANCHOR BOLT
Drill Wood to Secure the anchor bolt
and conduit in place.
ALPHA SERIES INSTALLATION INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALPHA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mega ALPHA Series

  • Page 1 Dig and Form a hole based on the Engineering Drawing. PAPER TEMPLATE Use the Paper template provided to position the anchor bolts and the conduit. SECURE THE ANCHOR BOLT Drill Wood to Secure the anchor bolt and conduit in place. ALPHA SERIES INSTALLATION INSTRUCTIONS...
  • Page 2 Leave it attached to the bottom pallet. Carefully align the 4 holes and the conduit on the base plates to the anchor bolts. Secure the pedestal by tightening the nut. ALPHA SERIES INSTALLATION INSTRUCTIONS...
  • Page 3 If your sign is equipped for Wireless Communications, Orient the Wi-Fi Wireless Antenna to the building to have Strong Wireless Signal. Turn main breaker to the sign, Face to Face Setup and the sign will Turn On. (For Mounting Type Antenna) ALPHA SERIES INSTALLATION INSTRUCTIONS...
  • Page 4 <ELEVATION> P4. ELECTRICAL CONDUIT Locate the electrical conduit and feed it into the pole. Then, Align 8 holes on the bottom of the cabinet to the pedestal. ALPHA SERIES INSTALLATION INSTRUCTIONS...
