Step 1: Attach the Legs metal (1) by using Bolt (A) and Washer (B)
#7225-ALTON 8' BT
ASSEMBLY INSTRUCTION
1L
2
Use the camera on your
phone to scan this QR
code to see a video of
the easiest way to
assemble the base
A
B
A
B
NO
NAME
SIZE
1
LEGS(2L+2R)
36 3/4" x 17 15/32" x 27"
2
METAL
20 3/32" x 5 7/8" x 3/16"
NO
NAME
SIZE
A
BOLT
B
WASHER
VERSION
09/06/2022
/9
1
PCS DRAW
4
1
PCS DRAW
2
2
Advertisement
Summary of Contents for HB 7225-ALTON 8' BT
- Page 1 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 1: Attach the Legs metal (1) by using Bolt (A) and Washer (B) Use the camera on your phone to scan this QR code to see a video of the easiest way to...
-
Page 2: Assembly Instruction
VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 2: Attach the Legs metal (1) by using Bolt (A) and Washer (B) Use the camera on your phone to scan this QR code to see a video of the easiest way to... - Page 3 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 3: Attach the Legs metal (1) by using Bolt (A) and Washer (B) Use the camera on your phone to scan this QR code to see a video of the easiest way to...
- Page 4 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 4: Attach the Legs metal (1) by using Bolt (A) and Washer (B) Use the camera on your phone to scan this QR code to see a video of the easiest way to...
- Page 5 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 5: Attach the Long beams (3) to the Legs (1) by using Bolt (C) ,Washer (D) and Nut(E). NAME SIZE PCS DRAW LONG BEAMS 90 3/4"x3 5/8"x1 25/32" NAME PCS DRAW SIZE...
- Page 6 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 6: Attach the short beams (4), mid beams (5) to the long beams using Bolt (F), Washer (D) and Nut (E) NAME PCS DRAW SIZE SHORT BEAMS 35" x 3 3/8" x 1 3/8"...
- Page 7 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 7A: Locate the center piece of framed slate and position it on the cross beam assembly so that it is centered to both the length and width of the assembly (you must be very accurate with placement).
- Page 8 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 9: Attach the Corner top to the Side rail and End rail by using Dowel (H), Threaded rod (I), Nut (J) and Washer (B) . Step 10: Attach the End Blinds to the Side Blinds by using Connect Metals (L), Screws (K) and Dowel (H) .
- Page 9 VERSION #7225-ALTON 8' BT 09/06/2022 ASSEMBLY INSTRUCTION Step 12: Attach rail/blind assemblies to the slate using Dome Washer (O), Star Washer (P), Threaded rod (Q) and Nut (E). Step 13: NOTE: the side pockets and corner pockets ARE different and will only work correctly one way.
