This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Air/Manual Hydraulic Bottle
Jacks Instruction Manual
MODELS:
J18124, J18204
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
*
Fax: 816-448-2142
Website: www.bvahydraulics.com
U.S. Patent Nos. 6,012,377 - 5,946,912
J18124-M1_082021
Advertisement
Table of Contents
Related Manuals for BVA Hydraulics J18124
Summary of Contents for BVA Hydraulics J18124
- Page 1 J18124-M1_082021 Air/Manual Hydraulic Bottle Jacks Instruction Manual MODELS: J18124, J18204 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com U.S. Patent Nos. 6,012,377 - 5,946,912 This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Safety And General Information
SAFETY and GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this jack before using. The owner and/or operator shall have an understanding of the device, its operating characteristics and safety operating instructions before operating the equipment. The owner and/or operator shall be aware that use and repair of this product may require special skills and knowledge. -
Page 3: Specifications
5-1/2" J18204 20 Ton 8-1/2" x 7-1/8" 1-7/8" 9-3/4" 18-5/8" 5" Air Motor Quick Connector Saddle Ram Plunger Air Hose Oil Filler Screw Lift Control Carry Handle Valve Release Valve Handle Handle Sleeve Figure 1 - J18124 & J18204 Nomenclature... -
Page 4: Operation
OPERATION MAINTENANCE Raising the Ram Plunger NOTICE: Use only good quality hydraulic jack oil. Avoid 1. Assemble handle, ensure that spring clips align mixing different types of fluid and NEVER use brake with slots. fluid, turbine oil, transmission fluid, motor oil or glycerin. 2. -
Page 5: Troubleshooting
TROUBLESHOOTING Symptom Possible Causes Corrective Action Jack will not lift load • Release valve not tightly closed • Ensure release valve tightly closed • Overload condition • Remedy overload condition • Air pressure inadequate • Ensure adequate air pressure Jack will lift, but not maintain •... -
Page 6: Replacement Parts
REPLACEMENT PARTS (refer to page 6 & 7) Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give Model number, serial number and parts description. Call or write for current pricing: SFA Companies Inc. - Page 7 Replacement Parts List for Models J18124 & J18204 Item Part# for J18124 Part# for J18204 Description Qty. SQ12-1200-039 SQ20-2000-039 Cylinder Fastener SQ12-1200-036 SQ20-2000-036 Guide Ring SQ12-1200-040 SQ20-2000-040 Filler Screw SQ20-2000-028 SQ20-2000-028 Special Washer 5905-00054-000 5905-00054-000 Seal SQ20-2000-035 SQ20-2000-035 Release Valve...
- Page 8 • Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components.
