Summary of Contents for Accent GRID 40
- Page 1 GRID 40 ASSEMBLY GUIDE...
- Page 2 Tools Required 4mm Hex Bit Phillips Screwdriver www.accentworkspaces.co.nz...
- Page 3 TABLE OF CONTENTS CONFIGURATION PAGE NUMBER IMAGE Grid 40 Grid 40 Panel 0800 126 826 | support@accentworkspaces.co.nz...
- Page 4 GRID 40 “Sample layout, your configuration maybe different” PARTS NO. NAME IMAGE End Frame M6 threaded holes on one side only Middle Frame M6 threaded holes on both side only Shelf Planter Box Mid Open Storage Lower Storage 2 hinged doors Bolts www.accentworkspaces.co.nz...
-
Page 5: Assembly Instruction
GRID 40 ASSEMBLY INSTRUCTION STEP STEP Lay end frame on the clean flat surface. Install pins to the frame. Install pins to all frames. Slide Lower storage unit onto pins on the end frame. Note: Mid-frames have pins both sides. - Page 6 GRID 40 ASSEMBLY INSTRUCTION STEP STEP Attached lower storage unit, planter box and shelf. Note: Attach planter box to the mid-frame using Attached mid frame. M6 x 25 bolts. STEP STEP Tilt complete unit onto its back. At this stage attached any additional frames to the unit.
- Page 7 GRID 40 PANEL PARTS LIST NAME QUANTITY IMAGE Panel Clamp Brackets 4pcs Caps 4pcs 0800 126 826 | support@accentworkspaces.co.nz...
- Page 8 Rotate the nob 90degrees anti clock wise. Separate the nob from the clamp bracket. STEP STEP Attached clamp brackets to the Grid 40 frame. Make sure there are 2 clamp brackets on each frame. Push panel onto the clamp brackets Push panel onto the clamp brackets.
-
Page 9: Care And Maintenance
FACTSHEET CARE & MAINTENANCE GENERAL CARE – INFORMATION • Avoid scourers and abrasives as they will damage the surface. • Don’t place hot objects, electrical appliances or pots straight from the oven or cooker onto your laminate surface. • Don’t cut on the laminate surface. •... - Page 10 GRID 40 MODULAR STORAGE SYSTEM www.accentworkspaces.co.nz...
- Page 11 Version #060623 0800 126 826 support@accentworkspaces.co.nz 22 Hood Street Wellsford, Auckland 0900 New Zealand...
