Colour Television
Contents
2. Technical Specifications, Diversity, and Connections2
Wiring diagram Oscar 32"
Block Diagram Bolt-On 1, 3104 313 65372,
xxPFL9xx6 series except 37"
Block Diagram Bolt-On 1, 3104 313 65402,
37PFL9xx6 series
Block Diagram Bolt-On 1, 3104 313 65372,
xxPFL8xx6 series
Block Diagram Bolt-On 3, 3104 313 65462,
xxPFL7xx6 series
10. Circuit Diagrams and PWB Layouts
A 272217190451 PSL
Published by MB/EL/TY 1271 Quality, the Netherlands
©
2012
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
7
BB 310431364723
11
44
49
65
UD 310431365083
79
80
82
83
84
85
86
87
88
89
90
91
11. Styling Sheets
92
Oscar 32"
93
94
95
Drawing
96
100
104
149
151
195
197
218
220
245
Chassis
Q551.2E
Page
247
265
267
276
286
288
290
292
293
294
295
296
299
300
325
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
Subject to modification
EN 3122 785 19058
LA
19050_000_110505.eps
110809
2012-Nov-05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Philips 40PFL8606T/12
Summary of Contents for Philips 40PFL8606T/12
-
Page 1: Table Of Contents
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V. -
Page 2: Revision List
Revision List EN 2 Q551.2E LA 1. Revision List Manual xxxx xxx xxxx.0 Manual xxxx xxx xxxx.4 • First release. • Chapter 4: added LVDS connector details, see 4.3.2 SSB 4.4.5 SSB. • Chapter 11: Updated styling sheets Oscar, see 11.1 Oscar Manual xxxx xxx xxxx.1 32"... -
Page 3: Technical Specifications, Diversity, And Connections
Technical Specifications, Diversity, and Connections Q551.2E LA EN 3 Mechanics Descriptions Schematics Styling 40PFL8606T/12 Cannes 65392 2.3 4-3 4.5 4.5.2 7.2 9.7 9.16 n.a. 10.51 10.15 10.16 10.17 10.18 10.19 10.20 10.21 10.22 10.23 10.24 10.25 10.27 11.7 10.53 10.28... - Page 4 Technical Specifications, Diversity, and Connections EN 4 Q551.2E LA Connections Connections Side SD CARD Back SCART (RGB / CVBS) Y Pb Pr - L R AUDIO IN DVI / VGA Bottom NETWORK AUDIO OUT HDMI 1 HDMI 2 HDMI 3 ANTENNA OPTICAL 19050_067_110505.eps...
- Page 5 Technical Specifications, Diversity, and Connections Q551.2E LA EN 5 2.3.1 Back Connections 10 - HDMI 1: Digital Video - In, Digital Audio with ARC - In/ 5 - Video RGB - In, CVBS - In/Out, Audio - In/Out 10000_017_090121.eps 090428 Figure 2-5 HDMI (type A) connector 10000_001_090121.eps 090121...
-
Page 6: Chassis Over View
Technical Specifications, Diversity, and Connections EN 6 Q551.2E LA - Video Green 0.7 V / 75 ohm 3 - SD-Card: Secure Digital Card - In/Out (optional) - Video Blue 0.7 V / 75 ohm - n.c. - Ground - Ground Red - Ground Green - Ground Blue DAT1/IRQ... -
Page 7: Precautions, Notes, And Abbreviation List
Spare Parts the following points: • Route the wire trees correctly and fix them with the For the latest spare part overview, consult your Philips Spare mounted cable clamps. Part web portal. • Check the insulation of the Mains/AC Power lead for external damage. - Page 8 Precautions, Notes, and Abbreviation List EN 8 Q551.2E LA result in sets which have the same CTN (Commercial Type 6 = play 16 : 9 format, 12 = play 4 : 3 Number; e.g. 28PW9515/12) but which have a different B.O.M. format number.
- Page 9 6.5 MHz. L' is Band (VESA standard for communication I, L is all bands except for Band I channel and display). Using E-DDC, LG.Philips LCD (supplier) the video source can read the EDID Loudspeaker information form the display.
- Page 10 SOPS Self Oscillating Power Supply Serial Peripheral Interface bus; a 4- wire synchronous serial data link standard S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board Spread Spectrum Clocking, used to reduce the effects of EMI...
-
Page 11: Mechanical Instructions
Mechanical Instructions Q551.2E LA EN 11 4. Mechanical Instructions Index of this chapter: • Figures below can deviate slightly from the actual situation, 4.1 Cable Dressing due to the different set executions. 4.2 Service Positions 4.3 Assy/Panel Removal Oscar Styling (xxPFL96xx/xx series) 4.4 Assy/Panel Removal Sundance Styling (xxPFL7xxx/xx series) 4.5 Assy/Panel Removal Cannes Styling (xxPFL8xxx/xx... - Page 12 Mechanical Instructions EN 12 Q551.2E LA 19051_161_110809.eps 110809 Figure 4-2 Cable dressing 37PFL9606x/xx (Oscar 37") 19051_162_110809.eps 110809 Figure 4-3 Cable dressing 40PFL8606x/xx (Cannes 40") back to 2012-Nov-05 div. table...
- Page 13 Mechanical Instructions Q551.2E LA EN 13 19055_006_111215.eps 111215 Figure 4-4 Cable dressing 40PFL9606x/xx (Oscar 40") 19051_163_110809.eps 110809 Figure 4-5 Cable dressing 46PFL8606x/xx (Cannes 46") back to 2012-Nov-05 div. table...
- Page 14 Mechanical Instructions EN 14 Q551.2E LA 19051_164_110810.eps 110810 Figure 4-6 Cable dressing 46PFL9706x/xx (Oscar 46") 19051_165_110810.eps 110810 Figure 4-7 Cable dressing 50PFL7956x/xx (Sundance 50") back to 2012-Nov-05 div. table...
-
Page 15: Service Positions
Mechanical Instructions Q551.2E LA EN 15 19051_166_110810.eps 110810 Figure 4-8 Cable dressing 52PFL9606x/xx (Oscar 52") 19051_167_110810.eps 110810 Figure 4-9 Cable dressing 58PFL9956x/xx (Oscar 58") Service Positions display. Caution: Failure to follow these guidelines can For easy servicing of a TV set, the set should be put face down seriously damage the display! on a soft flat surface, foam buffers or other specific workshop Ensure that ESD safe measures are taken. - Page 16 Mechanical Instructions EN 16 Q551.2E LA Caution 4.3.1 Rear Cover When removing the SSB, the board should not be handled by touching the heatsink of the PNX85500. Warning: Disconnect the mains power cord before you remove Refer to section 5.9.12 Additional information for replacing the the rear cover.
- Page 17 Mechanical Instructions Q551.2E LA EN 17 4.3.3 Speakers The speakers are located in the stand. When defective, replace the whole unit. 4.3.4 Mains Switch The mains switch is mounted on a plastic subframe and can be removed without removing the subframe. When defective, replace the whole unit.
- Page 18 Mechanical Instructions EN 18 Q551.2E LA 4.3.9 LCD Panel Refer to Figure 4-15 Figure 4-16 for details. 19050_076_110506.eps 110506 Figure 4-15 LCD panel 1. Remove the AL units as earlier described. 2. Remove the power switch with the power inlet subframe [1].
- Page 19 Mechanical Instructions Q551.2E LA EN 19 2. Lift the rear cover from the TV. Make sure that wires and 2. Remove the fixation screws [2]. flat coils are not damaged while lifting the rear cover from 3. Take the board out. the set.
- Page 20 Mechanical Instructions EN 20 Q551.2E LA 4.4.7 Ambilight Units The Ambilight units can be lifted from the subframes without the use of tools. Refer to Figure 4-25 for details. Click! LVDS flat foil Click! 19222_001_120626.eps 19100_054_110216.eps 120626 110216 Figure 4-22 SSB LVDS connector catches (optional) -2- Figure 4-25 Ambilight units 4.4.6 Keyboard Control, IR &...
- Page 21 Mechanical Instructions Q551.2E LA EN 21 4.4.8 LCD Panel Refer to Figure 4-26 Figure 4-27 for details. 19100_055_110216.eps 110216 Figure 4-26 LCD panel [1/2] 1. Remove the SSB as described earlier. 2. Remove the PSU as described earlier. 3. Remove the tweeters with their subframes and subwoofer as described earlier.
-
Page 22: Set Re-Assembly
Mechanical Instructions EN 22 Q551.2E LA 4.5.1 Rear Cover Set Re-assembly To re-assemble the whole set, execute all processes in reverse order. Warning: Disconnect the mains power cord before you remove the rear cover. Notes: • While re-assembling, make sure that all cables are placed Refer to Figure 4-28 for details. -
Page 23: Service Modes, Error Codes, And Fault Finding
Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 23 5. Service Modes, Error Codes, and Fault Finding Index of this chapter: How to Activate SDM 5.1 Test Points For this chassis there are two kinds of SDM: an analogue SDM 5.2 Service Modes and a digital SDM. - Page 24 Y.W.Z is the sub version number (a higher number is always compatible with a lower number). 39mm – B. STBY PROC Version. Displays the software PHILIPS version of the stand-by processor. MODEL: 32PF9968/10 – C. Production Code. Displays the production code of PROD.SERIAL NO:...
- Page 25 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 25 Also the production code (factory location code) can be Key in the code “123654” via the standard RC transmitter. entered here via the RC-transmitter. Note: Activation of the CSM is only possible if there is no (user) Correct data can be found on the side/rear sticker.
- Page 26 Service Modes, Error Codes, and Fault Finding EN 26 Q551.2E LA Quality items Stepwise Start-up • Signal quality. Bad / average /good (not for DVB-S). When the TV is in a protection state due to an error detected by • Ethernet MAC address.
- Page 27 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 27 Stand by or Mains is applied Protection Standby Supply starts running. All standby supply voltages become available. st-by µP resets If the protection state was left by short circuiting the Initialise I/O pins of the st-by µP: SDM pins, detection of a protection condition during - Switch reset-AVC LOW (reset state)
- Page 28 Service Modes, Error Codes, and Fault Finding EN 28 Q551.2E LA Reset-system is switched HIGH by the Reset-system is switched HIGH by the AVC at the end of the bootscript AVC at the end of the bootscript AVC releases Reset-Ethernet, Reset-USB and AVC releases Reset-Ethernet, Reset-USB and Reset-DVBs when the end of the AVC boot- Reset-DVBs when the end of the AVC boot-...
- Page 29 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 29 Constraints taken into account: - Display may only be started when valid LVDS output clock can be delivered by the AVC. - To have a reliable operation of the EEFL backlight, the backlight should be driven with a maximum PWM duty cycle during the first seconds.
- Page 30 Service Modes, Error Codes, and Fault Finding EN 30 Q551.2E LA Semi Standby The assumption here is that a fast toggle (<2s) can only happen during ON->SEMI ->ON. In these states, the AVC is still active and can provide the 2s delay. If the transition ON->SEMI- >STBY->SEMI->ON can be made in less than 2s, Wait until previous on-state is left more than 2 we have to delay the semi ->...
- Page 31 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 31 Active Mute all sound outputs via softmute Wait 100ms Set main amplifier mute (I/O: audio-mute) Force ext audio outputs to ground (I/O: audio reset) And wait 5ms switch off Ambilight Wait until Ambilight has faded out: Output power Observer should be zero Switch off POK line...
- Page 32 Service Modes, Error Codes, and Fault Finding EN 32 Q551.2E LA Semi Stand by If ambientlight functionality was used in semi-standby (lampadaire mode), switch off ambient light (see CHS ambilight) *) If this is not performed and the set is Delay transition until ramping down of ambient light is switched to standby when the switch off of finished.
-
Page 33: Service Tools
Introduction The error code buffer contains all detected errors since the last ComPair (Computer Aided Repair) is a Service tool for Philips time the buffer was erased. The buffer is written from left to Consumer Electronics products and offers the following: right, new errors are logged at the left side, and all other errors 1. - Page 34 Service Modes, Error Codes, and Fault Finding EN 34 Q551.2E LA • Via the blinking LED procedure. See section 5.5.3 How to content, as this history can give significant information). This to Clear the Error Buffer. ensure that old error codes are no longer present. •...
-
Page 35: The Blinking Led Procedure
Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 35 procedure when SDM is switched on. Remark: this only Example: Error 12 8 6 0 0. works for TV sets with an I C controlled screen included. After activation of the SDM, the front LED will show: •... - Page 36 Service Modes, Error Codes, and Fault Finding EN 36 Q551.2E LA starts over and over again. The headphone amplifier will becomes available (+12V is enabled by STANDBY signal when also behaves similar. "low"). Supply voltages +3V3, +2V5, +1V8, +1V2 and +5V-TUN are switched "on"...
- Page 37 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 37 5.9.5 Power Supply Unit Uart loggings reporting fault conditions, error messages, error codes, fatal errors: • Some failures are indicated by error codes in the logging, For fault finding tips, refer to section 7.2.1. check with error codes table (see Table “5-2 Error code overview”).e.g.
- Page 38 Service Modes, Error Codes, and Fault Finding EN 38 Q551.2E LA • Press the heatsink with a pressure of 4kg during a minimal Attention points: duration of 5 seconds. Sufficient board support should be • A removed or touched heatsink should be replaced by a present during mounting and pressing.
- Page 39 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 39 5.9.13 SSB Replacement For a more general overview of steps to follow, refer to figure 5-14 SSB replacement flowchart. Follow the instructions in the flowchart in case a SSB has to be exchanged.
- Page 40 Before starting: - prepare a USB memory stick with the latest software - download the latest Main Software (Fus) from www.p4c.philips.com - unzip this file - create a folder ”upgrades” in the root of a USB stick (size > 50 MB) and save the autorun.upg file in this "upgrades"...
- Page 41 Service Modes, Error Codes, and Fault Finding Q551.2E LA EN 41 Set is st art in g u p in F act o ry m o d e Set is starting up in F actory m ode? Noisy picture with bands/lines is visible and the An “F”...
-
Page 42: Software Upgrading
1. Disconnect the TV from the Mains/AC Power. 1. Set the correct option codes (see sticker inside the TV). 2. Press the “OK” button on a Philips TV remote control or a 2. Update the TV software => see the eUM (electronic User Philips DVD RC-6 remote control (it is also possible to use Manual) for instructions. - Page 43 How to start the “back-up software upgrade application” manually: 1. Disconnect the TV from the Mains/AC Power. 2. Press the “CURSOR DOWN”-button on a Philips TV remote control while reconnecting the TV to the Mains/AC Power. 3. The back-up software upgrade application will start.
-
Page 44: Alignments
Alignments EN 44 Q551.2E LA 6. Alignments Index of this chapter: • LATAM models: an NTSC M TV-signal with a signal 6.1 General Alignment Conditions strength of at least 1 mV and a frequency of 61.25 MHz 6.2 Hardware Alignments (channel 3). -
Page 45: Option Settings
Alignments Q551.2E LA EN 45 • When finished press OK on the RC, then press STORE (in Table 6-11 White tone default setting 50" (Sundance) the SAM root menu) to store the aligned values to the NVM. • Restore the initial picture settings after the alignments. White Tone e.g. - Page 46 Alignments EN 46 Q551.2E LA 6.4.2 Dealer Options of the TV, needed for this procedure, was not hampered as a result of the defect. The procedure of “channel map cloning” is clearly described in the (electronic) user manual. For dealer options, in SAM select “Dealer options”. See Table 6-13 SAM mode overview.
- Page 47 Alignments Q551.2E LA EN 47 6.5.1 SSB identification Whenever ordering a new SSB, it should be noted that the correct ordering number (12nc) of a SSB is located on a sticker on the SSB. The format is <12nc SSB><serial number>. The ordering number of the correct “Service”...
- Page 48 Alignments EN 48 Q551.2E LA Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description Test setting Digital info Current frequency: 538 QAM modulation: 64-qam Display information is for development purposes Symbol rate: Original network ID: 12871 Network ID: 12871 Transport stream ID: 2 Service ID: 3 Hierarchical modulation: 0 Selected video PID: 35...
-
Page 49: Circuit Descriptions
Circuit Descriptions Q551.2E LA EN 49 7. Circuit Descriptions Index of this chapter: 10. Circuit Diagrams and PWB Layouts).Where necessary, 7.1 Introduction you will find a separate drawing for clarification. 7.2 Power Supply 7.3 DC/DC Converters 7.4 Front-End Analogue and DVB-T, DVB-C; ISDB-T reception Introduction 7.5 Front-End DVB-S(2) reception The Q551.2E LA chassis comes with the following stylings:... - Page 50 Circuit Descriptions EN 50 Q551.2E LA 19070_102_110720.eps 110720 Figure 7-2 Architecture of TV550 platform 2011 (remaining sets) back to 2012-Nov-05 div. table...
- Page 51 Circuit Descriptions Q551.2E LA EN 51 7.1.2 SSB Cell Layout 19050_079_110506.eps 110506 Figure 7-3 SSB layout cells (top view) (32" Oscar) back to 2012-Nov-05 div. table...
- Page 52 Circuit Descriptions EN 52 Q551.2E LA 19051_168_110810.eps 110810 Figure 7-4 SSB layout cells (top view) (remaining sets) back to 2012-Nov-05 div. table...
-
Page 53: Power Supply
7.2.1 Power Supply Unit is available in the regular market. Consult the Philips Service web portal for the order codes of the For 32" and 37" sets, power supply units should be repaired on boards. component level. Detailed information is given in sections 7.2.3... - Page 54 Circuit Descriptions EN 54 Q551.2E LA Table 7-3 Connector overview 40 - 46" sets Table 7-5 Connector overview 52" sets Connector Connector 1308 1316 1M95 1308 1316 1319 1M95 Descr. Mains to display to SSB Descr. Mains to display to display to SSB Anode 1+ +3V3stdby...
- Page 55 Circuit Descriptions Q551.2E LA EN 55 Check First step Second step Normal operation Check the fuse (F101) Apply the mains voltage (AC Check the Standby voltage Check the entire block (PC102, V , etc.) at C306: measure 3.3 V Check the PFC voltage at C644 PFC present: measure 380 V to 400 V Check the entire block (V , ICs, etc.)
- Page 56 Circuit Descriptions EN 56 Q551.2E LA Check First step Second step Normal operation Check the fuse (F101) Apply the mains voltage (AC Check the Standby voltage Check the entire block (PC102, V , etc.) at C306: measure 3.3 V Check the PFC voltage at C644 PFC present: measure 380 V to 400 V Check the entire block (V , ICs, etc.)
- Page 57 Circuit Descriptions Q551.2E LA EN 57 + 5V 5-TUN 196 m A + 5V + 5V 5-TUN + 5V -TUN + 5V + 5V -TUN 2179 m A 196 m A dc -dc s tabiliz er + 12V + 3V 3 + 3V 3 + 2V 5 + 3V 3...
- Page 58 Circuit Descriptions EN 58 Q551.2E LA • RT control • Improved MPEG artefact reduction compared with • HPD control PNX8543 • Sync detection • Security for customers own code/settings (secure flash). • TMDS output control • CEC control The TV550 combines front-end video processing functions, •...
- Page 59 Circuit Descriptions Q551.2E LA EN 59 DDR2 1 × 64MB-800 DDR3 2 × 128MB-1333 8 × Vx1 Dual LVDS Trident Vsync, LR FRC-V 3D-LED C -Set ENABLE-DCDC SPLASH-ON FPGA BL-ON SPI/Vsync Sound in stand Back -end detection Board FPGA + FRC-V 1W35 19051_169_110810.eps 110810...
- Page 60 Circuit Descriptions EN 60 Q551.2E LA DDR2 1 × 64MB-800 DDR3 8 × LVDS 2 × 128MB-1333 8 × mini LVDS Dual LVDS TCON Trident BL-PWM Vsync, LR FRC-V FPGA Backlight 3D-LED C -Set ENABLE-DCDC SPLASH-ON BL-ON Sound in stand Back -end detection 5 ×...
- Page 61 Circuit Descriptions Q551.2E LA EN 61 DDR2 1 × 64MB-800 DDR3 2 × 128MB-1333 4 × HS LVDS Dual LVDS Trident FRC-V+ Enable LGD 2D Dimming C -Set ENABLE-DCDC SPLASH-ON BL-ON Sound in stand Back -end detection Board BL-PWM FPGA + FRC-V 1W35 19051_172_110810.eps 110810...
- Page 62 Circuit Descriptions EN 62 Q551.2E LA 1M54 1M09 1M99 1F53 (4p) (10p) (9p TH) DC/DC DC/DC Trident GPIO FRC-V LVDS TRANS 27x27 R×B4+ LVDS R×A0- 1T20 1T02 1SG2 1T51: 51pin 1G51: 51pin 1T25 1W35 1T01 19051_173_110810.eps 110810 Figure 7-18 Back-end layout cells (top view) Oscar except 37" & Cannes back to 2012-Nov-05 div.
- Page 63 Circuit Descriptions Q551.2E LA EN 63 1M54 1M99 1T25 1T03 1T02 1W35 1G51: 51pin (10p) (9p TH) 1F53 Trident DC/DC + GPIO FRC-V LVDS TRANS R×B4+ 27x27 DC/DC LVDS TCON DC/DC R×A0- 1L02: 80pin 1L01: 80pin 19051_174_110810.eps 110810 Figure 7-19 Back-end layout cells (top view) Oscar 37" 1M09 19051_175_110810.eps 110810...
- Page 64 Circuit Descriptions EN 64 Q551.2E LA Figure 7-20 Back-end layout cells (top view) Sundance AmbiLight For the configuration, refer to Figure 7-21 Figure 7-22. Glue Microprocessor logic AmbiLight AmbiLight AmbiLight optional 19052_003_110907.eps 110907 Figure 7-21 High-level architecture AmbiLight 2-/3-sided (12-V implementation) 19052_004_110907.eps 110907 Figure 7-22 Low-level architecture AmbiLight 2-/3-sided (12-V implementation)
-
Page 65: Ic Data Sheets
IC Data Sheets Q551.2E LA EN 65 8. IC Data Sheets This chapter shows the internal block diagrams and pin electrical diagrams (with the exception of “memory” and “logic” configurations of ICs that are drawn as “black boxes” in the ICs). - Page 66 IC Data Sheets EN 66 Q551.2E LA Diagram 10-3-10 Temp sensor & headphone B01J, LM75BDP (IC 7FD1) Block diagram LM75B BIAS POINTER CONFIGURATION REFERENCE REGISTER REGISTER TEMPERATURE COUNTER BAND GAP REGISTER 11-BIT TEMP SENSOR SIGMA-DELTA A-to-D TIMER REGISTER CONVERTER OSCILLATOR COMPARATOR/ THYST INTERRUPT...
- Page 67 IC Data Sheets Q551.2E LA EN 67 Diagram 10-4-1 NANDflash - conditional access B02A, PNX855xx (IC7S00) Block diagram PNX8550x MEMORY CONTROLLER TS input MPEG SYSTEM CI/CA LVDS for PRIMARY TS out/in for PROCESSOR flat panel display PCMCIA VIDEO LVDS (single, dual or OUTPUT quad channel) DVB-T/C...
- Page 68 IC Data Sheets EN 68 Q551.2E LA Diagram 10-5-1 Audio B03A, TPA312xD2PWP (IC7D10) Block diagram TPA3120D2 0.22 F 22 H 470 F ROUT 0.68 F PGNDR 0.68 F PGNDL LOUT BYPASS 22 H 470 F AGND 0.22 F PVCCL AVCC PVCCR VCLAMP Shutdown...
- Page 69 IC Data Sheets Q551.2E LA EN 69 Diagram 10-5-2 DC/DC B03B, TPS53126PW (IC7U03) Block diagram Pinning information VBST1 DRVH1 DRVL1 PGND1 VFB1 TRIP1 VREG5 TEST1 V5FILT TEST2 TRIP2 VFB2 PGND2 DRVL2 DRVH2 VBST2 18310_300_090319.eps 100416 Figure 8-5 Internal block diagram and pin configuration back to 2012-Nov-05 div.
- Page 70 IC Data Sheets EN 70 Q551.2E LA Diagram 10-5-5 DC/DC B03E, ST1S10PH (IC 7UD0) Block diagram ST1S10PH Pinning information DFN8 (4 × 4) PowerSO-8 I_18010_083.eps 110601 Figure 8-6 Internal block diagram and pin configuration back to 2012-Nov-05 div. table...
- Page 71 IC Data Sheets Q551.2E LA EN 71 Diagram 10-5-5 DC/DC B03E, LD1117DT25 (IC 7UD2) Block diagram LD1117DT Pinning information DPAK F_15710_166.eps 100402 Figure 8-7 Internal block diagram and pin configuration back to 2012-Nov-05 div. table...
- Page 72 IC Data Sheets EN 72 Q551.2E LA Diagram 10-6-3 Ethernet & Service B04C, LAN8710A-EZKH (IC 7E10) Block diagram MODE0 HP Auto-MDIX Auto- 10M Tx MODE1 MODE Control Negotiation Logic Transmitter TXP / TXN MODE2 Reset Transmit Section RXP / RXN nRST Control 100M Tx...
- Page 73 IC Data Sheets Q551.2E LA EN 73 Diagram 10-6-4 HDMI B04D, SII9x87B (IC 7EC1) Block diagram Pinning information 18770_303_100217.eps 100217 Figure 8-9 Internal block diagram and pin configuration back to 2012-Nov-05 div. table...
- Page 74 IC Data Sheets EN 74 Q551.2E LA 8.10 Diagram 10-6-5 Headphone B04E, TPA6111A2DGN (IC 7EE1) Block diagram IN 1− − TPA6111A2 IN 2− − SHUTDOWN Bias Control Pinning information D OR DGN PACKAGE (TOP VIEW) IN1− BYPASS IN2− SHUTDOWN 18770_309_100217.eps 110602 Figure 8-10 Internal block diagram and pin configuration back to...
-
Page 75: Block Diagrams
IC Data Sheets Q551.2E LA EN 75 8.11 Diagram 10-9-1 DVBS-FE B07A, STV6110AT (IC 7R02) Block diagram STV6110AT RF_OUT RF_IN PLL, dividers DC offset compensation XTAL_IN C bus interface Amplifier XTAL_INN XTAL_OUT 18770_304_100217.eps 110601 Figure 8-11 Internal block diagram and pin configuration back to 2012-Nov-05 div. - Page 76 IC Data Sheets EN 76 Q551.2E LA 8.12 Diagram 10-10-1 DVBS supply B08A, TPS54283PWP (IC 7T03) Block diagram TPS54283PWP BOOT1 CLK1 Level PVDD1 Shift Current ) + DC(ofst) Comparator DRAIN1 DRAIN1 Overcurrent Comp 0.8 V COMP SLOPE1 MAX1 Weak Soft Start CLK1 Pull-Down Anti-Cross...
- Page 77 IC Data Sheets Q551.2E LA EN 77 8.13 Diagram 10-10-2 DVBS supply B08B, LNBH23Q (IC 7T50) Block diagram ISEL ISEL ADDR ADDR SDA SCL SDA SCL Vcc- Vcc- Vcc- Preregulator Preregulator +U.V.lockout +U.V.lockout +P.ON reset +P.ON reset Rsense Rsense VSEL VSEL P-GND P-GND...
- Page 78 IC Data Sheets EN 78 Q551.2E LA Personal Notes: 10000_012_090121 back to 2012-Nov-05 div. table...
-
Page 80: Wiring Diagram Oscar 37
1M84 1M83 AMBILIGHT MODULE (1075) 1M20 1M09 1M83 1M84... - Page 81 1M84 1M83 1M09 1G51 1M21 1735 1M20 1M95 1M99 1M83 1M84...
-
Page 82: Wiring Diagram Oscar 46
1M84 1M83 AMBILIGHT MODULE (1075) 1M09 1M20... -
Page 83: Wiring Diagram Oscar 52
1M84 1M83 1M84 1M83 AMBILIGHT MODULE AMBILIGHT MODULE (1073) (1074) 8686 1M09 1M21 1735 1G51 1M20 1M95 1M99... -
Page 84: Wiring Diagram Oscar Platinum 58
1M84 1M84 1M83 1M83 AMBILIGHT MODULE AMBILIGHT MODULE (1073) (1074) 8686 8581 1M20 1L11 1L12 1M09 1M95 1M99 1M09 1M99 1M95... -
Page 85: Wiring Diagram Cannes 40 - 46
1M84 1M83 AMBILIGHT MODULE (1075) 1M09 1M99 1M95 1M20 1M84 1M83... -
Page 86: Wiring Diagram Sundance 50
1M84 1M83 AMBILIGHT MODULE (1074) 1M21 1M99 1M95 1M09 1M20 1308 1M83 1M84... - Page 285 1L11 24S6 64R6 64R5 24S4 24T5 24T3 24S5 64R8 64R7 24Z4 34Z4 34Z2 24Z2 F631 24S1 24T4 34Z6 24Z6 24Z8 34Z8 24S9 64P6 74R2 64P8 64P5 74R5 34Z3 24Z3 34R6 24Z1 64P7 24S8 24S2 34Z7 24Z7 34R8 24Z5 3602 24S7 24S3 3603 24T7...
