Grid Battery HAN P1 – Quick Start Guide
The Grid Battery HAN P1 is a plug-and-play dongle that connects your smart meter to
your Grid Battery, enabling direct meter data communication.
What's in the box?
● Grid Battery HAN P1 Dongle
● Antenna
● RJ12 Cable
Installation (3 Easy Steps)
1. Attach the antenna
Screw the included antenna into the connector on the HAN P1 adapter.
2. Connect to the electricity meter
Plug the RJ12 cable into the P1 port on your electricity meter and the other end
into the HAN P1 adapter.
3. Finalize settings
To complete the setup, go to Operating Modes > Select Meter Data Source in
the battery interface and choose "Nelinor HAN" from the list.
LED Indicator Guide
Red Light – No meter data
��
→ Check the RJ12 cable is properly connected
→ Try another cable if needed
Green Light – Connected
��
→ The HAN P1 is successfully connected with your battery
Need Help?
Contact support: info@nelinor.com
