Summary of Contents for KETELESE DK01
- Page 1 Bluetooth Speaker DK01 Novel Engineering glass speaker...
- Page 2 Why we Choose glass? It is from a large amount of research data and patent authorization Novel Engineering glass: Natural and authentic sound has always been our attempt and pursuit to bring people a comfortable hearing, using thin and tough glass (amorphous SiO2) as a sound radiation film for various traditional and novel speaker driver designs.
- Page 3 Tech Support Service Please contact us immediately if you need any tech support service and have any after-sale problems. We will give feedback to you within 24 hours. ktls004@shineconn.net www.ketelese.online...
- Page 4 After-sales service and support Warranty Period 15 months from the date of purchase of the product. Free service During the product warranty period, if the product quality problem causes the failure, get in touch with the dealer according to the manual to enjoy free maintenance. The following conditions are not warranted 1.
- Page 5 MFB knob: Press and hold: Power ON/Power OFF Click (BT): Play/Pause Click (AUX): Mute/Unmute Quick triple-click: Disconnect Rotation: Volume +/- LED: Red/Blue light Red light: Power supply Blue light: Bluetooth connected Blue light flashes every 0.5s: DC 18V Bluetooth pairing Blue light flashed every 1s: AUX mode...
- Page 6 1s to enter into AUX mode. Bluetooth Connection Search bluetooth name "DK01" on your equipment like mobile phone and choose to connect. After click to connect, will have sound playing “Connected” and blue light stays on.
- Page 7 Bluetooth Over range Disconnected Once the Bluetooth exceeds the effective connection distance, the speaker will play “Disconnected” and re-enters into the pairing state. Bluetooth Over range Callback Once Bluetooth returns to the valid connection distance, the speaker will automatically re-connect and play “Connected”. The blue light will stay on. MFB Knob –...
- Page 8 MFB Knob – Rotate Rotate MFB knob counterclockwise to “volume down”. Can volume down to no sound. Of course, you can still adjust the volume up/down with the connected equipment like mobile phone. Bluetooth/AUX Mode Switching After power on, plug in AUX wire at anytime, enter into AUX mode; Pull out the AUX wire at any time, enter into bluetooth mode.
- Page 9 Notes: iPhone automatically synchronizes with volume; Google phone can choose whether to synchronize with volume. There’s no call function, when the mobile phone has telephone access, automatically stop the speaker then talk through the mobile phone terminal.
-
Page 10: Product Specification
Product Specification Bluetooth name: DK01 IC Solution: ATS2853+TPA3118 Bluetooth Rev. No: V5.0 Transmission Frequency: 2.402GHz～2.480GHz Bluetooth Profile: A2DP，AVRCP Audio Decoding: SBC Transmission Power: CLASS 2 Wireless Range: ≥10m Power Voltage: 18V Power Adapter: AC Input 100V~240V 50~60HZ DC Output 17~18.5V Rated Current: 1.66A... - Page 11 Audio output specification Speaker outer Diameter: 4 inches Speaker Impedance: 4Ω±15 % Sensitivity: 85dB±3 dB Fo / Resonance Frequency: 75±20% Hz Frequency Range: 20~20KHz Rated Output: 30W Maximum Output: 40W THD: 5% 1KHz...
-
Page 12: Safety And General Information
Safety and General Information This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
