27.6 Vdc Switch Mode Power Supply for Fire - EN54-4:1997 +A1+ +A2
F
EATURES
The powersupplies are an EN54-4:1997+A1+A2 approved power supply for use in Fire & Smoke and
ven�la�on control Systems. Its regulated 27.6V dc output will supply up to 1.2 Amps con�nuous
current into the load, in addi�on to providing up to 300mA for charging the standby ba�ery capaci�es
of 7Ah (BAT7). The power supply output features electronic short circuit protec�on under
both mains and standby ba�ery opera�on. Maximum ba�ery life is assured through con�nuous ac�ve
ba�ery monitoring and the use of a two stage charger, comprising bulk and temperature compensated
final float phase depending upon ba�ery condi�on. Once fully charged the product operates in
Eco power saving mode, whereby the ba�eries are charged for 4 hours in every 24 hour period
while s�ll being con�nuously monitored. This reduces wasted energy in charging already fully
charged ba�eries and extends their working life. Deep discharge protec�on prevents premature
ba�ery failure when opera�ng from standby for extended periods. Two sets of volt free
solid state relay fault output signal (i) loss of mains and (ii) ba�ery fault, charger fault and loss of
output. In addi�on there is an op�onal plug in serial interface that can provide diagnos�c and fault
repor�ng informa�on to supervisory systems.
Cer�fied by UL to EN54-4:1997 +A1 +A2.
•
Up to 1.2A current to load at 27.6V dc nominal regulated output.
•
Charging capability to support 7Ah Ba�eries
•
Electronic overload protec�on shuts down output un�l overload or short circuit is removed.
•
Ba�ery Monitor detects ba�ery missing, low ba�ery, short-circuit or reverse connec�on or circuit
•
impedance (Ri) in excess of 500m , caused by connector or wiring problem/corrosion, within 4 hours.
Ba�ery charging circuit is energised only when a ba�ery is correctly connected and the ba�ery voltage
•
is greater than 14 V.
No loss of output during automa�c connec�on of ba�ery to load on loss of mains.
•
Deep discharge protec�on disconnects ba�ery from load when ba�ery voltage falls below 21 V.
•
Diagnos�c indicator LED (Orange) (Internal).
•
Fault indicator LED (Yellow) flashes on detec�on of output fault, ba�ery fault, charger fault and mains
•
failure.
Mains indicator LED (Green) showing mains present Indicators check at start-up.
•
Op�onal RS232 serial interface for fault repor�ng and diagnos�cs.
•
0843-CPR-0213 14 (UL)
2531-CPR-CSP11212 20 (DBI)
