Streamax X3N-H0404 Installation Manual

Hide thumbs Also See for X3N-H0404:
Table of Contents

Advertisement

Quick Links

Download this manual
www.streamax.com
X3N-H0404
Installation Guide
Page 1 of51

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X3N-H0404 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Streamax X3N-H0404

Summary of Contents for Streamax X3N-H0404

  • Page 1 X3N-H0404 Installation Guide Page 1 of51...
  • Page 2 Type of document General Product planning document Public Version 60 pages in total V1.1 Revision History Date Revision Modification Description Author April 26, 2021 V 1.0 First draft X3N-H0404 solution May 10, 2021 V 1.1 Content optimization Page 2 of51...

  • Page 3: Table Of Contents

    Table of Contents Foreword............................ 5 Important Instructions........................5 System Overview........................7 Product Overview......................7 Schematic Diagram of Equipment Connection............7 Schematic Diagram of System Connection..............7 Definition of External Cable Interface............... 8 Preparation for Installation....................10 Technical Requirements for Installation..............10 Understanding of Installation Environment............
  • Page 4 Installation and Calibration of Optional Components.............26 ADAS Camera......................26 5.1.1 Requirements for Installation Position................. 26 5.1.2 Requirements for Installation Details................27 5.1.3 Installation Steps......................28 5.1.4 Calibration Requirements..................... 29 Camera.......................41 5.2.1 Requirements for Installation Position................. 41 5.2.2 Requirements for Installation Angle................42 5.2.3...

  • Page 5: Foreword

    This document is applicable to installation engineering personnel. Streamax Technology Co., Ltd. has the right of final interpretation for this document, and reserves the right to make corrections to this document or to make changes to the information and description herein.
  • Page 6 9. Please scan the QR code below, or search and download the Veyes APP in the App Store. After the download is completed, connect the APP to the equipment for related operations according to the prompt on the interface of the APP.

  • Page 7: System Overview

    System Overview Product Overview X3N-H0404 is a cost-effective and functionally scalable device specially designed for vehicle video surveillance and remote video surveillance. Its features are as follows: Support GPS positioning technology, allowing recording vehicle traveling trajectory in real time for background analysis;...

  • Page 8: Definition Of External Cable Interface

    Definition of External Cable Interface Alarm Serial Port Connecting Cable Page 8 of51...
  • Page 9 Serial Port Connecting Cable Page 9 of51...

  • Page 10: Preparation For Installation

    Preparation for Installation Technical Requirements for Installation Relevant personnel shall be familiar with the functions, applications and the overall composition principle of the product. Relevant personnel shall understand the electrical circuits and structure of motor vehicles, and common installation methods of in-vehicle equipment.

  • Page 11: Connection Of Necessary Signal Cables

    Connection of Necessary Signal Cables Where required, the following signal cables must also be connected to enable the intelligent assisted driving functions of X3N-H0404: Vehicle speed pulse cable or CAN data cable - to obtain accurate vehicle speed data; Left and right steering signal cables - to obtain left and right steering information of vehicle;...

  • Page 12: Preparation Of List Of Installation Materials And Tools

    After unpacking the product, please confirm whether the EDR is intact and whether the accessories are complete. List of Product Materials Picture Product Name Purpose Qty. X3N-H0404 On-board main unit with hard disk 1 pcs 1 pcs ADAS camera Road condition detection 1 pcs...

  • Page 13: Preparation Of Installation Tools

    MINI key 1 pcs Unlock WIFI antenna 1 pcs Enhance the WIFI signal Socket-mounted fuse, plug-in, ordinary 7.5A fuse 1 pcs type 32V, 7.5A Socket-mounted fuse, plug-in, ordinary 15A fuse 1 pcs type, blue case, 32V, 15A Wet and dry paper...
  • Page 14 Common screwdriver Tighten screws; optional 1 pcs socket Crow plate Pry up the vehicle panel 1 pcs Ties Bundle cables Several Dry cleaning cloth Clean the countertop 1 pcs Install the EasyCheck App for video Smartphone/pad 1 pcs preview and parameter configuration...
  • Page 15 Corrugated conduit Aesthetic wiring and cable protection The following installation tools are also required for the installation of DMS camera if required: DMS Camera Installation Tools S/N Picture Name of Tool Purpose Qty. 1. Adjust and fix the DMS camera lens at...

  • Page 16: Preparation Of Sim Card And Sd Memory Card

    20m tape measure Ranging and calibration 1 pcs Drill holes on the carbody Electric hand drill 1 pcs High-speed steel Drill holes on the carbody Several drill bits 3.4mm and 3.8mm drill bits Drill holes on the carbody for the concealed...

  • Page 17: Installation Of X3N Main Unit

    Installation of X3N Main Unit Installation of SIM Card and SD Card Loosen the silver bolt. ① Turn the lock cylinder to OPEN with a key, and then pull out the upper hard-disk cartridge. ② Open the lower right cover, and then insert SIM card and SD card.

  • Page 18: Installation Of X3N Main Unit

    Installation of 15mm thick hard disk If a 9.5mm/7.0mm thick hard disk is installed in the original state, while you want to install a 15mm thick hard disk, you need to remove the bracket and then install the 15mm thick hard disk.

  • Page 19: Power Supply Connection And Connection Of Signal Cables

    Waterproofing: During installation of the terminal, attention shall be paid to high temperature prevention and waterproofing. Damp-proofing: The terminal shall be installed at a dry and ventilated place. Dust-proofing: The terminal shall be installed at a place with less dust.

  • Page 20: Connection Of Signal Cables (Pulse Or Can/Left/Right Steering Signal/Reversing)

    *Note: The power cable shall be connected using "special stripping-free connection terminal" where possible (no stripping is required, so as to avoid the risk of electric leakage), and the connection shall be wrapped with insulated rubber tape to avoid electric leakage/short circuit.
  • Page 21 14, respectively. (The cable sequence varies with the shape of OBD interface. The example here is only for illustration.) After the connection is completed, log in to the EasyCheck App to connect the X3N- H0404 main unit. Enter the configuration interface, set the CAN model and baud rate of the equipment, and set the speed source as "OBD".
  • Page 22 X3N-H0404 main unit through the EasyCheck App, so as to enter the configuration interface and set the use of corresponding signal cable. Example: ① Connect SENSOR IN1 to the left steering signal cable of the vehicle. In this case, click [Preferences] gt;...

  • Page 23: Installation Of Gps, 3G/4G And Wifi Antennas

    *Note: If the measured signal is a pulse signal, the source of left steering/right steering/brake signal shall be set as pulse on the setting interface of the main unit; if the measured signal is a continuous high or low level signal, the source of left steering/right steering/brake signal shall be set as level on the setting interface of the main unit.

  • Page 24: Installation Of 3G/4G Antenna

    4.5.2 Installation of 3G/4G Antenna Installation requirements: 1. The equipment that may interfere with 3G/4G signals, such as original on-board GPS positioning module, shall be kept more than 15 cm away from the antenna. 2. Excess tail harness of the 3G/4G antenna shall be concealed in the A-pillar or the center console.
  • Page 25 Tear off the 3M adhesive film on the bottom of the WiFi antenna to stick the antenna to one side of the center console of the vehicle. Installation requirements: 1. The antenna cannot be installed in a confined space, as this may affect signal reception.

  • Page 26: Installation And Calibration Of Optional Components

    Installation and Calibration of Optional Components ADAS Camera *Before installation and calibration of the ADAS camera, it must be ensured that the vehicle is parked on the flat ground. It is forbidden to park the vehicle on a slope or a potholed road for ADAS installation and calibration.

  • Page 27: Requirements For Installation Details

    Make sure that ADAS is installed within the working area of the left and right windshield wipers (so as to ensure that the area within the range of the ADAS camera lens can be cleaned by the windshield wiper).

  • Page 28: Installation Steps

    Next, in the vertical direction, locate another horizontal center point 2 on the front windshield at least 20 cm away from center point 1. Connect center points 1 and 2 with a mark pen, to draw the centerline of the front windshield.

  • Page 29: Calibration Requirements

    If there is a special mounting bracket for ADAS (as shown in the figure below), the following steps are implemented: Place the mounting bracket vertically on the dashboard below the target installation area, and then tear off the 3M adhesive film on ADAS, and align the lower edge of the ADAS camera to the notched ADAS fixing seat above the special bracket.
  • Page 30 The two calibration methods are introduced below. To ensure the calibration effect and the recognition effect of ADAS, if conditions permit, the "long-distance calibration method" is preferred. 5.1.4.1 Long-distance calibration method (20m/30m/40m) Application scenario: The installation site is open and has at least 30m flat road section. To ensure the calibration accuracy, this method is preferred.
  • Page 31 Confirm that ADAS is installed at a reasonable position on the front windshield and is within the working range of the windshield wiper. Measure the installation height of ADAS (it should be noted that the height refers to the height of the camera lens to the ground, accurate to cm/inch), and enter this value on the interface of the EasyCheck App.
  • Page 32 According to |CD|=|AB|, keep a tape measure perpendicular to point D to determine position C of the camera on the ground from point D, and make a mark. Enter the measured installation height |BD| of lens on the interface of EasyCheck App, which is taken as 203cm in this installation.
  • Page 33 After entering the installation height of lens, click "Next" on the operation interface of EasyCheck App to enter the following interface. You can view the ADAS calibration tutorial on this interface. If you know how to calibrate, continue to click "Next".
  • Page 34 Open the back cover of ADAS camera and adjust the angle of ADAS lens to make the 20m calibration line in ADAS calibration screen coincide with the mark point at 20m on the ground, and the 30m calibration line in ADAS calibration screen coincide with the mark point at 30m on the ground.
  • Page 35 Go back to the real-time preview interface of ADAS channel (double-click the ADAS channel screen to enter the main stream), and check that there is no calibration line superimposed on the screen at this time, which means that ADAS channel has returned to normal mode at this time.
  • Page 36 ADAS screen will be adjusted to match the corresponding mark point on the ground. In case of short-distance calibration, it is limited by the environment of the installation site, and it is impossible to set mark points at 20m/30m/40m. According to the principle of similar triangle, when a telemeter rod is set at 3m/5m (as shown at point F below), corresponding height |HF| of line AK can be found on the telemeter rod.
  • Page 37 Calibration process: Log into the Veyes APP to enable the ADAS calibration process. Click [Preview] on the homepage to enter the preview interface, and then click [AI Calibration] on the lower left corner of the screen for calibration selection.
  • Page 38 Select calibration channel. Since ADAS cameras are all installed in channel 1, select channel 1 here. Next, click "Calibration" at the lower right corner of the screen to enable the calibration process. Confirm that ADAS is installed at a reasonable position on the front windshield and is within the working range of the windshield wiper.
  • Page 39 Measure the installation height of ADAS (it should be noted that the height refers to the height of the camera lens to the ground, accurate to cm/inch), and enter this value on the interface of the EasyCheck App. The method for measuring the installation height of lens is the same as that used in long- distance calibration, and will not be repeated here.
  • Page 40 Open the back cover of ADAS camera, and adjust the angle of ADAS lens to make the 20m calibration line in ADAS calibration screen coincide with the mark point at 152cm on the vertical telemeter rod at 5m. Page 40 of 60...

  • Page 41: Dms Camera

    After that, click "Next", select the source of speed according to the actual installation situation, set the left and right turn signal parameters, and then click "Next". In the next interface, check whether the left and right turn signals are valid according to the prompts.

  • Page 42: Requirements For Installation Angle

    If the A-pillar camera (CA29M, the recommended model in general) is selected, the DMS camera shall be installed on the A-pillar on the driver's side, with the side facing the driver's face. The DMS camera lens shall be 80-110 cm away from the driver's face.

  • Page 43: Requirements For Installation Details

    Make sure that the fill light of the DMS camera faces towards the driver's face (the fill light shall not face towards the seat belt; otherwise, it will lead to overexposure of video). Make sure that there is no other object (such as steering wheel) in the DMS video screen that will block the driver's face and the seat belt features.
  • Page 44 A-pillar (with the arc side facing toward the driver). If the driver stands right side up in the screen, there is no need to set the installation type of DMS camera.
  • Page 45 After the appropriate installation position meeting the above requirements for installation details is determined through the DMS camera screen, first tighten the upper screw of the DMS camera mount (with the lower screw of the mount not tightened temporarily, so as to adjust the angle of the camera up and down).
  • Page 46 After adjusting the angle of the DMS camera up and down/left and right, make sure that the driver sits according to normal driving habits and posture, to meet the following conditions: (1) Make sure that the driver's face appears in the middle of the video screen, and the lower edge of the screen is below the driver's chest.

  • Page 47: Calibration Requirements

    5.2.5 Calibration Requirements Log in to the EasyCheck App. Click [Preview] on the homepage to enter the preview interface. Double-click the driver channel to enter the main-stream full screen. Adjust the angle of the DMS camera so that the driver's face appears in the middle of the screen and the lower edge of the screen is below the driver's chest.
  • Page 48 Select [DMS] for calibration. Select corresponding channel of the DMS camera (select channel 3 here). Click [Calibration] to move on to the next step. Confirm the prompts — click [Next] to move on to the next step. Select [Front] or [Side] to determine the installation method of DMS camera.
  • Page 49 Never select front calibration if side installation is selected. The driver shall turn the head sideways to face toward the camera to complete the calibration. Click [Next] to move on to the next step for automatic face calibration. During calibration, make sure that the driver sits still according to normal driving habits and posture and looks straight ahead.

  • Page 50: Side Bsd Camera

    Click [Finish] to complete the calibration and exit the calibration mode. Side BSD Camera *Before installation and calibration of the BSD camera, it must be ensured that the vehicle is parked on the flat ground, and it is forbidden to park the vehicle on a slope or at the location with a cavity for BSD installation and calibration.
  • Page 51 As shown in the figure below, "B" is in the red circle of the label, indicating that the camera is installed on the right side. As shown in the figure below, "A" is in the red circle of the label, indicating that the camera is installed on the left side.

  • Page 52: Installation Steps

    (3) During installation of the BSD camera, the BSD camera base can first be installed with the round hole at the upper part and the waist hole at the lower part (so as to facilitate adjustment left and right, and thus ensure the vertical installation of BSD).

  • Page 53: Calibration Requirements

    Finally, tighten the mount screws, as shown in Fig. 2 below. Fix the camera on the mount (first apply excessive glass sealant to the inlet hole), and measure the installation height of the lens, as shown in Fig.
  • Page 54 Place a marker close to the side of the vehicle at 2m in front of the vehicle head, as shown in the left picture below. Start and connect the equipment, and preview the picture through the EasyCheck App, as shown in the right figure below.
  • Page 55 On the preview interface, click "AI Calibration" and select "BSD Calibration", as shown in the figure below: Select the left or right BSD to be calibrated, and enter the real-time preview screen. Here, take the right BSD as an example.
  • Page 56 On the real-time preview screen of BSD, click "Calibration" at the bottom of the real-time screen, At this point, a vertical red line, a horizontally inclined yellow line and a yellow box appear on the screen, and "Up", "Down", "Left" and "Right" buttons appear on the left side of the screen: Click the "Left"...

  • Page 57: Process Requirements

    Process Requirements Treatment Standard of Unused Connection Wire Ends All unused signal connection wire ends must be wrapped. Refer to the figure below for the standard treatment process requirements. Unused aviation connectors must also be wrapped. Connection Process of Aviation Connector...

  • Page 58: Interior Opening For Wiring Of Vehicle

    6.3.1 Interior Opening for Wiring of Vehicle If the mode of opening for wiring is adopted, a rubber sleeve shall be additionally set at the ① opening to protect the cables from being worn out by the sharp part of the opening.
  • Page 59 At the screwing part of camera and the opening for installation of tail harness on the ① exterior of the carbody, glass sealant shall be applied for waterproofing. For the purpose of aesthetics, the color of glass sealant shall be the same as or be similar to ②...

  • Page 60: Acceptance And Cleaning

    Acceptance and Cleaning Cleaning Clean up the installation site, collect and take away tools and waste separately, and put the original articles in the vehicle to their original place, and then the installation work ends. Installation Acceptance Conduct acceptance for the installation details and parameter setup item by item according to the acceptance list provided by the customer.
