Do not subject the device to severe impact or drop it from heights.
Do not use the device in extreme hot or cold, dusty or damp conditions. Do not
expose it to direct sunlight.
Avoid using the device near strong magnetic fields.
Normal functioning of the product may be disturbed by ESD. If so, simply reset
and restart the device following the instruction manual. During file transmission,
please handle with care and operate in a static-free environment.
Keep the device away from water and other liquids. In the event that water or
other liquids enter the device, power off the product immediately and clean the
device.
Do not use chemicals to clean the device in order to avoid corrosion. Clean it
with a dry cloth.
Do not install this equipment in a confined space such as a book case or similar
unit. The ventilation should not be impeded by covering the ventilation openings
with items such as newspaper, table-cloths, curtains etc.
No naked flame sources, such as lighted candles, should be placed on the
apparatus.
Attention should be drawn to environmental aspects of battery disposal.
Use the apparatus in moderate climates.
We are not responsible for damage or lost data caused by malfunction, misuse,
modification of the device or battery replacement.
Do not attempt to disassemble, repair or modify the product. This will invalidate
the warranty.
If the device will not be used for an extended period of time, please charge the
battery at least once per month to maintain battery life.
Charge the battery if:
a) The battery level icon displays
b) The device powers off automatically when restarted.
c) There is no response when pressing keys with keys unlocked and battery full.
Do not interrupt the connection when the device is being formatted or
transferring files. Otherwise, data may be corrupted or lost.
When the device is used as a portable HD, please use only per the instructions.
Otherwise, permanent data loss could occur.
Please use and install data using the attachments/accessories provided and only
according to the manufacturer's instruction.
Please refer to the information on the bottom of the device for electrical and
safety information before installing data or operating the device.
To reduce the risk of fire or electric shock, do not expose this device to rain or
moisture. The device should not be exposed to dripping or splashing. Never
place objects filled with liquids, such as vases, on the device.
There is danger of explosion if the battery is replaced incorrectly. Replace only
with the same or equivalent type.

Safety Precautions

1
(An empty battery)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS15AT07 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yifang NS15AT07

  • Page 1: Safety Precautions

    Safety Precautions  Do not subject the device to severe impact or drop it from heights.  Do not use the device in extreme hot or cold, dusty or damp conditions. Do not expose it to direct sunlight.  Avoid using the device near strong magnetic fields. ...
  • Page 2  The battery (battery or batteries or battery pack) should not be exposed to excessive heat such as sunlight, fire or the like.  Please follow responsible procedures for battery disposal.  If the power adaptor disconnected from the device, the device will remain operable as long as the battery has sufficient charge.
  • Page 3: Listening Cautions

    Listening Cautions  This product respects the current regulations for limiting the output volume of consumer audio devices to a safe level. By listening to your device with headphones or earbuds at high volumes, you run the risk of permanent damage to your ears.
  • Page 4: Table Of Contents

    Table of Content Safety Precautions ....................1 Listening Cautions ....................3 Feature Summary ....................5 Accessories ......................5 Buttons & Ports ......................5 Charging Battery ...................... 6 Transferring Files from Computer ................6 Turning On the Unit ....................7 Home Screen ......................7 Unlocking the Screen ....................
  • Page 5: Feature Summary

    Feature Summary Wi-Fi Connectivity With the latest Wi-Fi technology, this device can connect you to the Internet wherever you are. 7.0” Touch Screen Touch or slide your finger on the screen, the screen responds instantly. Third-party Application Support With the built-in Android OS, you can install a large number of third-party applications in this device.
  • Page 6: Charging Battery

    Earphone socket – connects to stereo earphones. Microphone 3. Charging indicator– Lights red during charging, and lights orange as charging completes. 4. Micro USB Port – Connects to PC via USB cable. 5. Front Camera Lens 6. Power –Briefly press to lock or unlock the screen; press and hold to turn on/off the unit;...
  • Page 7: Turning On The Unit

    Note: The pre-installed applications and Android OS occupy a considerable part of capacity –more than 1GB, it is normal that you see huge difference between available memory space and total capacity. Turning On the Unit To turn on the device, press and hold the Power button on the unit until you see the boot-up screen.
  • Page 8: Changing The Wallpaper

     To move a Home Screen item, hold your finger onto it until it is highlighted, then drag it to the desired location, and release it.  To remove a Home Screen item, hold your finger onto it until it is highlighted, drag it to the recycle bin “Remove”...
  • Page 9: Tips On Touching Screen

    Tips on touching screen  Click: Briefly click on an item can open an application or page.  Drag: When watching a video or listening to music, you can tap on the progress bar to playback any designated section of the file. You can drag the cursor of the progress bar to any other elapsed time point of the file.
  • Page 10: Reading E-Books

    range of your device. Choose a network from the list and then tap “Connect” to connect. Some network may be secured with password, enter the password before connecting. If the connection is successful, the message Connected to…(WiFi Network Name) will appear under the WIFI Setting. Note: a) The available network list is constantly refreshed automatically.
  • Page 11: Start Reading

    e-books from your computer’s local drive to the device by USB connection (see the “Transferring files” section mentioned before). Note: Make sure your e-books are in format of PDF, EPUB, TXT, FB2, RTF or PDB supported by the device. Start Reading (1) In the Application page, tap “E-book”...
  • Page 12: Playing Music

    Playing Music Tap the Music icon in the application page to launch the music player. Music Library You should enter the music library once you start the music player. The Music Library shows your music files sorted by categories (Artist, Album, etc.) if your music files contain these song information tags.
  • Page 13: Playback Menu

    Playback menu During playback of a music file, tap on the MENU icon to bring up a context menu: Library– return to music library menu. Party Shuffle – select Party Shuffle mode Add to playlist – add a song to the playlist. Delete –...
  • Page 14: Viewing Photos

    Viewing Photos Tap the Gallery icon in the application page to launch the Photo Gallery. Viewing Photos Photos should be listed in thumbnail. You can slide your finger on the screen left or right to browse photos. Tap a photo thumbnail to view the photo in full screen. To display the previous/next picture, slide your finger on the screen horizontally.
  • Page 15: Display Menu

    Display Menu When you are viewing the picture, you can tap on the screen or the Menu icon show a menu. Using the Camcorder/Camera Tap the Camera icon in the application page to launch it. Settings tab Viewfinder Start/Stop Front/Rear Mode: Photography/ camera Panorama/ VCR...
  • Page 16: Using The Explorer

    Using the Explorer Navigate through Files and Folders  You can drag your finger up and down to scroll the file list up and down.  To open a file or folder, tap the file/folder.  Tap MANAGE APPLICATIONS, you can uninstall applications (see details in the “Managing 3 party Applications”...
  • Page 17 that you want to delete. Hold the selected file/folder until a pop-up menu appears. Select “Delete” from the pop-up menu, then select “Delete” to confirm or “Cancel” to quit. Rename Files and Folders In the file list, scroll up and down the list by sliding finger to select the file/folder that you want to rename.
  • Page 18 Sliding your finger on the toolbar can scroll through all tools. Home Go to the Home Screen. Go back one level in the directory. Multi Select more than one file. Edit Copy, delete, move, paste or rename the file or folder. Search Search for a specific file or folder Back...
  • Page 19: Sending/Receiving E-Mails

    Sending/Receiving E-mails This device has an E-mail application pre-installed. You can send or receive e-mails from the Internet at any time with this device. Make sure you have an Internet connection before using the email service. In the Home Screen, tap the Applications shortcut to display all applications and then tap the Email icon to launch the e-mail application.
  • Page 20: Managing 3 Rd Party Applications

    (4) Tap on “Remove Account”,and then tap on “OK” to confirm. Check the Account Setting (1) When you are in the email box, tap on the Menu icon to display the menu items. (2) Tap on “Accounts” to display all email accounts. (3) Hold your tap on the account that you want to check until a menu pop up.
  • Page 21: Close Recent Applications

    Close Recent Applications Your device can remember applications that you used recently. That’s very useful when you want to go back to a window you opened recently. Also, you can close these applications to enhance system performance. to display applications that you used recently. Hold your tap on the application that you want to stop, and then select “Remove from list”.
  • Page 22: Fcc Caution

    WARNING IC Caution. RSS-Gen Issue 3 December 2010"&"CNR-Gen 3e é ditionDé cembre 2010: - English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 23: Specifications

    Specifications Item Description Based on Cortex-A9 (dual-core); Main CPU frequency:1.4GHz DDR3 Built-in operating system Android OS 4.2 Hardware IBM PC or compatible PC, Note-book or Macintosh with USB port Internal Memory 4GB,8GB (Optional) Memory Card type SD card: 2GB, 4GB (SDHC), 8GB, 16GB, 32GB(SDHC) Operation System Windows2000/XP/Vista/windows 7/Linux2.4/ MAC OS 10.6.7 above Interface...
