astreea ACS111 Installation Manual

Ev charger – all vertical models

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Built for a lifetime.

ENG

Installation

Guide

EV Charger – All Vertical Models

ACS111, ACS121, ACS211 and ACS221

(11KW/22KW) and subsets.

Table of Contents

Need help?

Do you have a question about the ACS111 and is the answer not in the manual?

Questions and answers

Summary of Contents for astreea ACS111

Page 1 Built for a lifetime. Installation Guide EV Charger – All Vertical Models ACS111, ACS121, ACS211 and ACS221 (11KW/22KW) and subsets.
Page 2 3. Retain this Guide for future reference 4. These cards that you will find in the Guide are very important. Please give them your attention. Astreea Igloos North America, LLC PO Box 773192 Eagle River Alaska 99577 www.us.astreea.com Please call our customer service US &...
Page 3: Table Of Contents
4. Linking the wires 5. Finishing the installation Installation guide for wall chargers 1. Anchoring the charger to the wall 2. Linking the supply line and wires 3. Finishing the installation Usage operations 1. LED status indicator 2. Astreea® Charger App...
Page 4: Requirements Before Installation
Attention! General safety hazard Ignoring the instructions may result in damage to the charging Astreea® assumes no liability for the following cases in the event station, serious injury or even death. of personal injury or property damage: • Mishandling of the charging station •...
Page 5 Installation Guide - Astreea® Charger - All vertical models 1.4 Requirements and Observations The following requirements and observations must be met and followed: • No direct spray of water on the surface of the • Never use it at places where gas or other chemi- charger.
Page 6 • Knowledge of circuit breaker voltages and fundamental principles When deciding on the placement of your Astreea® Charger, please keep in mind the importance of not obstructing entry or exit points and allowing for the passage of rescue or emergency vehicles.
Page 7 Installation Guide - Astreea® Charger - All vertical models 1.8 Information on initial inspections after installation and repeat inspections National regulations may necessitate inspections of the charging 2. Insulation Test: Since the charging system incorporates a disconnecting relay, two insulation measurements are required. To system both before its initial startup and at regular intervals there- after.
Page 8 The charging process will commence automatically once the 3. Employ the Astreea® Charger app to cease the charging ses- charging coupler is plugged in and the vehicle requests a charging sion.
Page 9 Installation Guide - Astreea® Charger - All vertical models 1.13 The structure of your Astreea® Charger Structure of Astreea® Charger: 1. Body 2. Status LED light 3. Protective cover 4. Charging plug 5. Charging cable 6. Antenna and NFC controller 7.
Page 10: About Our Ev Chargers And Technical Data
Installation Guide - Astreea® Charger - Single socket Model - Anchoring on alternative ground Installation Guide - Astreea® Charger - All vertical models Discover our EV chargers Self Standing 22 kW Single Socket or Cable Charger Model: ACS111-11, ACS111-12, ACS111-21, ACS111-22 Max Output Power:...
Page 11 Installation Guide - Astreea® Charger - All vertical models Installation Guide - Astreea® Charger - Single socket Model - Anchoring on alternative ground Wallbox 22 kW Single Socket or Cable Charger Model: ACS211-11, ACS211-12, ACS211-21, ACS211-22 Max Output Power: 22 KW Output Connection:...
Page 12: Technical Data
Installation Guide - Astreea® Charger - All vertical models 2. Technical Data Vehicle Connection Chargers with 1 socket Chargers with 2 sockets Type 2 charging socket 16 A* / 32A 2 x 16 A* / 32A Maximum charging current 16 A / 32 A...
Page 13 Installation Guide - Astreea® Charger - All vertical models Mandatory power connections Nominal voltage 230 / 400V Nominal current 16 A / 32 A Circuit Breakers 20 A / 40 A, 3-poles AC fault detection RCCB, Type A, 30mA *Some software features and systems may still be in the development phase at the time of purchase.
Page 14: Assembly. Anchoring With Foundation And Metal Frame
3. Assembly. Anchoring with foundation and metal frame. 3.1. Creating the foundation To ensure the secure and stable installation of the Charger, Astreea® recommends utilizing the optional Stainless steel Foundation Frame, which is embedded in concrete. It is essential to prevent any cement from entering the threaded holes during this process.
Page 15 Installation Guide - Astreea® Charger - All vertical models 3.2. Mount the sleeve on the lower cap Once the foundation has solidified, follow these steps: 1. Detach the Lower Cap from the interior of the charger by pulling down. 2. Attach the Sealing Sleeve to the Lower Cap in the designated position.
Page 16: Linking The Wires
Installation Guide - Astreea® Charger - All vertical models 4. Linking the wires 4.1 Feed the supply cables through the cable gland Pull the cables through the cable gland, adjust the length of the wires and strip off the jacket making sure to leave out at least 10 mm at the top.
Page 17 Installation Guide - Astreea® Charger - All vertical models After you’ve customized the wire length and removed the cable insulation, proceed to connect the wires. Refer to the connection diagram in the table below, which illustrates how to connect the ground-side supply line to the charging unit cables along with their respective functions.
Page 18: Finishing The Installation
Installation Guide - Astreea® Charger - All vertical models 5. Finishing the installation 5.1 Fix the charger to the foundation After securely connecting the cables, carefully insert the socket back into the Charger and position it over the Foundation Frame. Ensure that the holes in the Charger’s base align with those in the Foundation Frame.
Page 19: Ready To Use
It’s essential to ensure a stable internet connection is maintained for both the charger and the mobile app to operate smoothly. The Astreea® Charger includes a sticker that contains crucial information about the charging station. Whether or not you...
Page 20: Installation Guide For Wall Chargers
Installation guide for wall chargers...
Page 21: Anchoring The Charger To The Wall
Prior to charger installation, it is essential to select an appropriate mounting surface capable of enduring both the installation process’s forces and the everyday wear and tear of the charging station. Astreea® suggests utilizing concrete as the preferred mounting surface, ensuring it possesses the necessary physical characteristics suitable for both installation and long-term use.
Page 22 Installation Guide - Astreea® Charger - All vertical models 1.2 Mounting on the chosen surface Step 2. Place the support piece on the wall, aligning the hole marked at the bottom with the other two holes matching the line drawn on the wall, marking the positions of the fastening holes.
Page 23 Installation Guide - Astreea® Charger - All vertical models 1.3 Mounting on the chosen surface Step 3. After attaching the support piece to the wall, you should mark the positions of the other two fastening holes for the lower support according to the specified measurements. Pay close attention to their alignment, ensuring they are perfectly vertical and centered with respect to the support piece.
Page 24 Installation Guide - Astreea® Charger - All vertical models 1.4 Mounting the Inferior Cap 1. Unscrew the two M5x10 screws to remove the bottom cover of the station. 2. Detach the WAGO female connector. 3. Screw the conduit gland onto the bottom cover.
Page 25 Installation Guide - Astreea® Charger - All vertical models 1.5 Mouting on the wall Position the station on the wall, using the support piece, while also checking if the lower support needs to be adjusted vertically. If repositioning is required, ensure that the station is securely fastened both at the bottom and the top.
Page 26: Linking The Supply Line And Wires
Installation Guide - Astreea® Charger - All vertical models 2. Linking the supply line and wires The power cable should be passed through the conduit gland and the first bottom cover. Connect the wires to the WAGO female con- nector according to the following diagram:...
Page 27: Finishing The Installation
Installation Guide - Astreea® Charger - All vertical models 3. Finishing the installation Mount the bottom cover onto the station body by tightening the two M5x10 screws. After tightening the screws, also tighten the conduit gland nut to ensure a proper seal.
Page 28 It’s essential to ensure a stable internet connection is maintained for both the charger and the mobile app to operate smoothly. The Astreea® Charger includes a sticker that contains crucial information about the charging station. Whether or not you...
Page 29: Usage Operations
• Blue: The charger is waiting for authorization via the app or an NFC/RFID card. • Blue – pulsating: The charging process is currently in progress. • Red: The station has encountered a fault. Please contact Astreea® Support for assistance. Proudly manufactured by ARSAT® in the European Union...
Page 30: Astreea® Charger App
Installation Guide - Astreea® Charger - All vertical models 2. Astreea® Charger App How to use the mobile app Privacy notice - tap “Continue” after reading the privacy notice Login screen - enter your account details or login with your Apple account After log in - tap “Start...
Page 31 Installation Guide - Astreea® Charger - All vertical models Charging screen - you have a full status of your Charger(s), the duration and costs for each and additional settings Status screen - you’ll get a full status of your charge...
Page 32 Installation Guide - Astreea® Charger - All vertical models Page 32 Proudly manufactured by ARSAT® in the European Union...
Page 33 Installation Guide - Astreea® Charger - All vertical models Certified by: Missing or you lost spares? Please call our customer service: (907) 931-4469 Proudly manufactured by ARSAT® in the European Union Page 33...
Page 34 Installation Guide - Astreea® Charger - All vertical models The Certificate of Conformity The Certificate of Conformity (CoC) contains crucial details about your charger purchase. To register your Astreea® Charger using the mobile application, you must utilize the app to scan the QR codes found on the CoC.
Page 35 Installation Guide - Astreea® Charger - All vertical models Certificat nr.: AS-CH-202300003 Data: 16.06.2023 Serial nr.: SNASTR2161 1 367577FB579C2D252FF96AFA2DFF21D22B6CEBE3 CERTIFICAT DE CALITATE/CONFORMITATE/GARANȚIE S.C. ARSAT INDUSTRIE S.R.L., str. 601, nr. 53, 317235, Pecica, Furnizor: Arad, Romania S.C. ARSAT INDUSTRIE S.R.L., str. 601, nr. 53, 317235, Pecica, Producător:...
Page 36 Installation Guide - Astreea® Charger - All vertical models Page 36 Proudly manufactured by ARSAT® in the European Union...
Page 37 Installation Guide - Astreea® Charger - All vertical models Proudly manufactured by ARSAT® in the European Union Page 37...
Page 38 Installation Guide - Astreea® Charger - All vertical models Page 38 Proudly manufactured by ARSAT® in the European Union...
Page 39 Installation Guide - Astreea® Charger - All vertical models Proudly manufactured by ARSAT® in the European Union Page 39...
Page 40 Installation Guide - Astreea® Charger - All vertical models Page 40 Proudly manufactured by ARSAT® in the European Union...
Page 41 Installation Guide - Astreea® Charger - All vertical models Proudly manufactured by ARSAT® in the European Union Page 41...
Page 42 Installation Guide - Astreea® Charger - All vertical models Page 42 Proudly manufactured by ARSAT® in the European Union...
Page 43 Installation Guide - Astreea® Charger - All vertical models Proudly manufactured by ARSAT® in the European Union Page 43...
Page 44 EV Charger – All Vertical Models ACS111, ACS121, ACS211 and ACS221 (11KW/22KW) and subsets. Scan for: astreea.com/charger...

This manual is also suitable for:

Acs121Acs211Acs221
