MYSAir MS101V Manual

Hide thumbs

Advertisement

Table of Contents

A
MYS
ir
®
Sistema Zonas
MANUAL INSTALLER
MS101V - MS102R
MS103M - MS103R
MYS
A
ir
Sistema Zonas
www.mysair.es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS101V and is the answer not in the manual?

Questions and answers

Summary of Contents for MYSAir MS101V

  • Page 1 ® Sistema Zonas MANUAL INSTALLER MS101V - MS102R MS103M - MS103R Sistema Zonas www.mysair.es...
  • Page 2 Features. Functions of thermostats. 22-23 Initial setup. MS20, MS22, MS25 Other functions. 25-28 THERMOSTAT MS20, MS22 y MS25 Pag. Thermostat installation. Features. 31-33 Functions of thermostats. Initial setup. MS20, MS22, Ms25 35-36 Other functions. 37-39 WARRANTY Pag. Warranty policy. www.mysair.es...
  • Page 3 C/ Mayor 27, 30149. MURCIA (ESPAÑA) Failure to comply with these environmental measures are subject to sanctions Telf: + 34 966744473 established by the Law on Environmental Protection. FAX: + 34 966741928 www.mysair.es www.agfri.com MS101V MS102R MS103M/R www.mysair.es...
  • Page 4 Connection of a maximum of 7 zones, without using the motorized Bypass. * MS103M / R, maximum of 3 zones, without Ÿ possibility of installing motorized Bypass. Areas expandable through expansion plates up to a total of 14 zones, only for the MS101V and MS102R models. Ÿ Integration with production equipment through the Total Control Cable.
  • Page 5 SYSTEM FUNCTIONS MS101V - MS102R In the diagram below, the different connections existing in the Switchboards MS101V - MS102R are detailed. AC 230V BUS 1 BUS 2 SONDA A1 B1 1 2 3 4 V W X Y Z A2 B2 ®...
  • Page 6 ON / OFF machines. 3 x output zones for motorized elements. Outputs 1-2 (relay1). Outputs 3-4 (relay2) Output Total FanCoil Control Module and IR Total Control. *(Option) Bus Control Total. Output Connection with Total Control Gateway module. *(Option) IR receiver input. www.mysair.es...
  • Page 7 MOTORIZED DIFFUSION CONNECTION The 12V motor outputs allow us to connect the MYSAir® motorized elements of each zone to the Switchboards . With a maximum of up to 7 engines (without ByPass) and up to 2 engines per zone (slaves).
  • Page 9 Master Slave Slave Slave ® Sistema Zonas Centralita MS101V Insulation tape is not used. Use a splice tab 230-250V TERMOS M7/B Note: This work mode involves the cancellation of zone 2 of the D + - control units. That is, the motorized elements that are installed in this output, will work at the same time as the "M1".
  • Page 10 CONNECTION WIRED THERMOSTATS The wired entrance of MYSAir® thermostats is made in the "TERMOS" connector of the Switchboard. The connection for the thermostats can be in PARALLEL or in SERIES. * RADIO versions of thermostats only compatible with control units MS102R and MS103R.
  • Page 11 For a new thermostat, reset or without code / installation number, it is necessary to configure this code in the thermostat before connecting it to the control unit. The steps to follow are on page. 35 (point 1) of this manual. www.mysair.es...

  • Page 12: Total Control

    A2 B2 A1 B1 1 2 3 4 V W X Y Z A2 B2 ® ® ® Sistema Zonas Sistema Zonas Sistema Zonas Centralita MS101V Centralita Centralita 230-250V MS101V MS101V 230-250V 230-250V TERMOS M7/B D + - TERMOS M7/B...
  • Page 13 D + - NOTE: Each gateway includes its specific and detailed connection manual. More information: www.mysair.es -> Manuals. Total Control with Infrared Gateway module. The connection is made through terminal V-Z (AUX) and terminal A2-B2 (BUS2) in control unit and terminals A2-B2 in Ctotal.
  • Page 14 A1 B1 V W X Y Z 1 2 3 4 ® Sistema Zonas Centralita MS101V 230-250V TERMOS M7/B D + - NOTE: By default the MicroSwith DIP3 (page 14) is supplied in the OFF position, so in cold mode only relay No. 1 is activated and in heat mode, relays No.
  • Page 15 1-10V output . NOTE: Each gateway includes its specific and detailed connection manual. + Info: www.mysair.es -> Manuals. CTOTAL FANCOIL TRIAC 1-10V Suitable for the Total Control of machines with TRIAC 1-10V control and machines with a single winding fan. In case of having a speed winding, the regulated output would be connected to the maximum speed winding.
  • Page 16 SW-8 -- ON = The maximum speed of the indoor fan does NOT work. (This switch refers to Switch 4). SW-8 -- OFF = If the maximum speed of the indoor fan works. (This switch refers to Switch 4). * Bold text indicates factory settings. www.mysair.es...

  • Page 17: Power Supply

    To make use of more zones than the Default Unit allows, it is necessary to use the MS104Z Zone Expansion Module. Cable section 0.25mm. * Not installable next to the Switchboard MS103M. NOTE: Next to the expansion module you will find its detailed installation manual. More information: www.mysair.es -> Manuals. www.mysair.es...
  • Page 18 2. En los termostatos hay que habilitar el modo de trabajo “Suelo”. MS20/MS22/MS25, pag. 33 opción 65. MS23, pag. 26 point 8. Next to the expansion module, you will find its detailed installation manual. More information: www.mysair.es -> Manuals. DELAY CLOSES LAST ZONE VARIANTE 1 ZONA CON 1 MAESTRO 5 ESCLAVOS Possibility of adjusting the time delay for closing the last motorized element in heat mode.
  • Page 20 Cable section 0.25mm² Cable section 0.25mm²...
  • Page 21 INSTALLER MANUAL THERMOSTAT MS23 www.mysair.es...

  • Page 22: Wall Installation

    For the version of the thermostat with stand or base, it will be powered by an internal rechargeable battery. Plug the FM415B/N charger into the electrical power and place the thermostat on the base so that it is always charged. www.mysair.es...
  • Page 23 Power Type of power 4.2 VDC Consumption at rest 100mW Temperatures Switch Switched ON Working range 16ºC to 32ºC Storage temperature -20ºC to 85ºC Working temperature 0ºC to 70ºC Jack feed base. FUNCIONES PRINCIPALES MS23 www.mysair.es...
  • Page 24 Setpoint temperature 25.0º WIFI thermostat. Room temperature 29.5º On / Off To rise / to lower temperature. Fan speed. Cold Mode. Heat mode. Floor Heating / Heating mode. Thermostat work information. Modo Frío Vel. Min. Name Thermostat or zone. DORMITORIO www.mysair.es...
  • Page 25 The assigned zone will connect this thermostat to the connected Asignación Zonas grid in the Switchboard. Zona Test This function calibrates the thermostat (NTC) of the thermostat. Sonda Temperatura Calibrar Termostato It does a "reset" to the thermostat to restore it to factory defaults. Reset Fábrica Reset www.mysair.es...
  • Page 26 3) Locate the ignition switch and turn it On (fig.3). A green LED will light indicating that the thermostat is powered. 4) Close the housing. Video tutorial: www.mysair.es -> Videos. VCC EXT. MS23 thermostat with base. 1) Connect the power cable of the FM415B / N transformer in the input jack of the base.
  • Page 27 Video-tutorial: www.mysair.es -> Videos. 10) Check the set configuration data (Fig. 7). In the Menú Ajustes (Settings Menu), click on "1 - Información Termostato” (Thermostat information) and The zone number, the installation name and the installation name will appear among other information name of the thermostat.
  • Page 28 7. WIFI configuration of the thermostat (fig.11). The Wifi version of the MS23 thermostat can be configured to give access to the control via the mobile phone / tablet and the MYSAir® applications located in the Play Store and App Store (Free download).
  • Page 29 First select or press on the floor icon and in less than 5 seconds, before the independent floor mode is set, press Cold or Heat so that both modes or icons are illuminated on the screen. In this way, you will work on the floor stage in combination with the selected mode. www.mysair.es...
  • Page 30 Note1: The fan speed will be restored to "Vel. Zonal "each time the thermostat is started again. Note2: The Switchboard will obey the last thermostat in selecting permanent speeds. Note3: The fan speed lock can not be combined in a system with wired thermostats, since wiring will prevail. www.mysair.es...
  • Page 31 INSTALLER MANUAL THERMOSTAT MS20 MS22 MS25 Sistema Zonas MS20 MS22 MS25 www.mysair.es...
  • Page 32 BUS 2 SONDA A1 B1 1 2 3 4 V W X Y Z A2 B2 Datos ® Sistema Zonas Centralita MS101V 230-250V TERMOS M7/B D + - MS20 Sistema Zonas WARNING TERMOS The connection wiring of the D + -...
  • Page 33 "Ed, rd, CC, Cf ...". * Floor heating mode will only work when exist in Lower temperature -0.5ºC. the radiant stage installation. * Speeds Fan only available when the Total Control Increase temperature + 0.5ºC. Module is installed. www.mysair.es...
  • Page 34 Lower temperature -0.5ºC. Increase temperature + 0.5ºC. No. Current area of work / Indicator of state of data transmission Ed, rd, CC ..Room temperature. Work mode*. * Underfloor mode will only work when it exists in the radiant stage installation. www.mysair.es...
  • Page 35 Timer (30/60/90/120). Timer time / "OFF" indicator. Work mode *. Mode selection button / Settings button and config. Lower temperature -0.5ºC. Increase temperature + 0.5ºC. * Underfloor mode will only work when it exists in the radiant stage installation. www.mysair.es...
  • Page 36 OPENING IN HEAT MODE 5 Slaves 65 % - Default factory 100% Note: The value of each section in bold is the one that is configured by factory default. The parameters in blue color are only adjustable in the MS20 thermostat. www.mysair.es...
  • Page 37 2) Select the zone number from "01" to "14" with the buttons and Confirm by pressing on the buttons: MS20 press on the selected zone number, MS22 press on the "M" button and MS25 press on the button See Number of zones in the Table pag. 33 www.mysair.es...
  • Page 38 Note 4: The fan speed lock can only be set with radio thermostats and can not be combined in system with wired thermostats. Permanent unlock speed Fan. To unlock the permanent speed, keep the button pressed for 5 seconds. www.mysair.es...
  • Page 39 3) Select function "95" from the Installer Menu to set the zone nº1, nº2 and nº3 work at the same time. Total up to 6 engines in a single area. 4) Restart Switchboard after adjusting slave zones, to memorize change. www.mysair.es...
  • Page 40 These can be altered if you increase or decrease the grid measurements so that it interprets another open surface and the ventilation speed changes. Video tutorial: www.mysair.es -> Videos. CODES OF STATE COMMUNICATION THERMOSTATS WITH SWITCHBOARD. Thermostat status codes and in communication with Switchboard.
  • Page 41 Reception error, There is no communication with the Switchboard (radio). Sending Thermostat data to the Switchboard. Grid closed by slogan. Turning on the thermostat will mark the thermostat area. Running Total system stop. Shows the actual temperature and the set temperature. www.mysair.es...

  • Page 42: Warranty Policy

    The Buyer receives the "standard warranty" mentioned by default. Upon request, an "extended warranty" or "customized project guarantee" can be agreed after evaluating the specific conditions of the application, installation or use. This document reflects the General Warranty Terms. For more information you can ask for the full warranty policy document at agfri@agfri.com. www.mysair.es...
  • Page 43 MATERIALES Y SOPORTES IND. DEL LEVANTE, S.L. C/ Mayor 27, 30149. MURCIA (ESPAÑA) Telf: + 34 966744473 FAX: + 34 966741928 www.mysair.es www.agfri.com...

This manual is also suitable for:

Ms102rMs103mMs103r
