  • Page 1 USER MANUAL BUSH Series EV Charger Copyright...
  • Page 2 Any part of this manual, including text, pictures, graphics, etc., belongs to Hangzhou Livoltek Power Co., Ltd. Without written permission, no unit or individual may extract, copy, translate or modify all or part of this manual in any way. V.01...
  • Page 3: Table Of Contents

    Catalogue About This Manual ......................3 Applicable Chargers....................3 Applicable Readers .....................3 Sign Description ....................4 Manual Preservation ...................4 Safety Statements.......................5 Packing List .........................7 Wall-mounted Version..................7 Column Version....................8 Base Version .......................8 Product Introduction......................9 Technical Parameter..................10 Nameplate......................10 Safety Protection ....................12 Charging Interface .................... 13 Device Reception......................
  • Page 4 Enter the Configuration Interface ..............28 Set the Module Type ..................29 8.2.1 Set WIFI......................29 8.2.2 Set 4G......................30 8.2.3 Set Ethernet..................... 30 Connect to the OCPP1.6J Platform ..............31 Operating instructions ...................... 33 Charging with RFID card .................. 33 LED Indicators ....................
  • Page 5: About This Manual

    1 About This Manual Applicable Chargers This manual is valid for the following charging stations: LIVOLTEK B1U21E2E0M5S (single phase B1U2ME2E0M5S (three phase with Gun line) with Gun line) B1U21E2S0M0S (single phase B1U2ME2S0M0S (three phase with socke) with socket) B1U21E2S0P0S (single phase...
  • Page 6: Sign Description

    Sign Description Sign Description Description text, indicating supplementary description and interpretation INDICATE of the text. Attention text, meaning to remind the user of some important operations NOTICE or prevent potential injury and property loss. Warning text, indicating that there are potential risks. If not avoided, i t WARNING may cause injury accidents, charger damage or charging interruption.
  • Page 7: Safety Statements

    WARNING Persons not authorized by LIVOLTEK are not allowed to open the charger. Do not disassemble, repair or refit the charger and relevant ancillary facilities without permission. Improper operation may cause damage, water leakage, electric leakage and other damage to the charger or potential personal injury.
  • Page 8 Please start and stop the charging according to the user manual and relevant prompts provided by LIVOLTEK. When plugging in and out the vehicle connector, pay attention to the appropriate force and press the unlock button (Type 1).
  • Page 9: Packing List

    3 Packing List Wall-mounted Version Item Model Picture Quantity Charger 1 PC Expansion bolts 4 PCS Wall-mounted 1 PC Bracket Bracket Ear 2 PCS Screws M5*10 6 PCS 2 PCS Fireclay 1 PC Quick Installation 1 PC Guide Certificate 1 PC...
  • Page 10: Column Version

    Column Version Item Model Picture Quantity Charger 1 PC Expansion Bolt 4 PCS Key for Cabinet 2 PCS 2 PCS Fireclay 1 PC Quick Installation 1 PC Guide Certificate 1 PC Base Version Item Model Picture Quantity 1 PC Charger...
  • Page 11: Product Introduction

    1 PC 4 Product Introduction The LIVOLTEK BUSH series chargers are designed to meet all the requirements for electric vehicle charging in both public and private settings. They allow simultaneous charging of two vehicles and come in two optional configurations: Case B and Case C.
  • Page 12: Technical Parameter

    Technical Parameter B1U2ME2S0M0S B1U2ME2E0M5S B1U21E2S0M0S B1U21E2E0M5S Model B1U2ME2S0P0S B1U2ME2E0P5S B1U21E2S0P0S B1U21E2E0P5S Input/Output Rated Power 2*22 kW 2*7.3 kW Rated Input Voltage 400Vac 230Vac Input Voltage Range 400Vac±10% 230Vac±10% Rated Output Current 64A (32A+32A) Rated Frequency 50/60Hz Grid Architecture TN-C-S / TN-S / TT Type 2 Socket Type 2 Socket Type2 Connector 5m...
  • Page 13 Working Temperature -30 °C to +50 °C Storage Temperature -40℃~70℃ Working Humidity 5%~95% RH Working Altitude ≤2000 m Standby Power <10W User Interface 7'' Touch Screen; Charging LED Indicators Connectivity Bluetooth, Ethernet, Wi-Fi /4G (optional) Power Management Support Firmware Update Local / OTA User Authorization RFID (ISO 14443), POS Ready (Optional)
  • Page 14: Nameplate

    EMC requirements LIVOLTEK BUSH series chargers are equipped with the necessary filtering elements to meet electromagnetic compatibility (EMC) requirements for domestic applications, thereby preventing interference with other equipment outside the installation.
  • Page 15: Charging Interface

    Charging Interface Type 2...
  • Page 16: Device Reception

    5 Device Reception Device Reception 1. Unboxing and Inspection  Upon receiving the charging station, please open the packaging immediately.  Carefully inspect the packaging for any damage. If you notice any damage or abnormalities, contact the supplier immediately.  Verify that all accessories in the package match the packing list. Standard accessories typically include the charging station unit, mounting bracket, screws, and user manual.
  • Page 17: Storage Conditions

    Storage Conditions 1. Environmental Requirements: Store the charging station in an environment with temperatures between -40°C and  +70°C. Maintain relative humidity below 85%.  Avoid direct exposure to sunlight or extreme weather conditions.  2. Physical Protection: Use the original packaging materials or suitable alternatives to wrap the charging ...
  • Page 18: Equipment Transportation

    (rain), and any other conditions or substances that could potentially damage or alter its performance. Failure to adhere to these instructions may result in the voiding of the product warranty, for which LIVOLTEK will not be held responsible. Transportation...
  • Page 19: Unpacking

    • Disassemble the unit in a horizontal position. If any anomalies are observed, please contact LIVOLTEK immediately. Separating the Packaging: You can deliver all the packaging materials to an authorized non- hazardous waste management company. In any case, each part of the packaging can be recycled as follows: •...
  • Page 20: Preparation & Installation & Electrical Connection

    7 Preparation & Installation & Electrical Connection Before installing the device, the packaging must be removed, taking particular care not to damage the housing (see section “6.2. Unpacking”) for possible later requirements. Tools preparation...
  • Page 21: Additionally Required Materials

    Cable and its (26.67mm²) (26.67mm²) (16.77mm²) matching terminal recommended E25-16/ E35-16 E25-16/ E35-16 SC16-6/ SC25-6 * Note: Ensure installation complies with local regulations. Livoltek is not responsible. Torque: L1/L2/L3/N: 1.8~2.0 N·M; PE: 3~4 N·M. L, N: 1.8~2.0 N·M; PE: 3~4 N·M.
  • Page 22: Installation Environment Requirements

    Installation Environment Requirements It is recommended that the charger be installed by an authorized service provider of LIVOLTEK. The installation position of charger shall not be close to dangerous positions such as water pipe, gas pipe and steam pipe. The charger shall not be installed in places with severe vibration or high temperature.
  • Page 23: Installation

    Installation  Wall-mounted Version Installation Before installation, take out the device, four expansion bolts, the wall-mounted bracket, two bracket ears and six M5*10 screws from the accessory. Step 1: Put the wall-mounted bracket on the wall and put a spirit level on the top of the bracket to ensure the bracket is level.
  • Page 24 Step 4: Take out the two bracket ears, align the ears with the holes of the charger and the wall-mounted bracket on both sides of the device and secure the charger and the bracket with six M5*10 screws.  Column Version Installation Before installation, take out the device, the four expansion bolts and keys from the accessory.
  • Page 25  Base Version Installation Before installation, take out the device, the base and four M8 screws from the accessory. Step 1: Dig a cubic hole in accordance with the dimensions of the base, put the base in the hole and make the base level. Step 2: Thread the cable through the hole of the base and remain enough length for cable wiring and electrical connection.
  • Page 26: Electrical Connection

    Step 4: Wait until the cement is dry. Cut the inlet at the bottom of the cabinet. Thread the cable from the base through the inlet into the cabinet. Align the holes at the bottom of the device with the four bolts on the top surface of the base and put the device on the base correctly.
  • Page 27  Wall-mounted Version Step 1: Open the door of the charger. Step 2: Cut the inlet at the bottom or at the back of the charger. Choose one inlet to cut and thread the cable through the inlet. Thread the grid cable through the inlet into the charger, strip and crimp terminals with the wires.
  • Page 28  Column Version Step 1: Open the door of the charger. Step 2: Cut the inlet at the bottom of the charger. Thread the cable from the columnar cabinet through the inlet into the charger, strip and crimp terminals with the wires. Connect the assembled N, L1, L2, L3 and PE wire to the N, L1, L2, L3 and PE terminal of the three- phase charger.
  • Page 29 The charger has a RJ45 connection meaning that the unit can be connected to other chargers and/or to a communications device (router, modem, switch, etc.).  Installing the SIM card The Charger comes with an integrated 4G modem. The charger takes Nano SIM cards, which must be placed in the cardholder in the small control panel on the top right-hand side, as shown in the following image.
  • Page 30: Methods For Connecting To The Ocpp Platform

    8 Methods for Connecting to the OCPP Platform Enter the Configuration Interface 1)Click the LIVOLTEK button on the homepage 2)After clicking, the system will jump to the password input interface. 3)Input the password “123456”. 4)When you have finished typing, click the Confirm button. The system will verify...
  • Page 31: Set The Module Type

    8.2 Set the Module Type 8.2.1 Set WIFI 1) Click NetworkModuleType→Set to 4 2) Click WifiName→Set wifi name Click WifiPassword→Set wifi password...
  • Page 32: Set 4G

    8.2.2 Set 4G 1) Click NetworkModuleType → Set to 5 8.2.3 Set Ethernet 1) Click NetworkModuleType → Set to 6...
  • Page 33: Connect To The Ocpp1.6J Platform

    Connect to the OCPP1.6J Platform For example: The following example illustrates the method for connecting to the CSCP platform. The CSCP platform mentioned here is our self-developed OCPP 1.6J platform.. 1) The charging pile ID for connecting to the CSCP platform, which can be customized 2)...
  • Page 34 3) CSCP Platform Port Number:8094 Click OCPPPort→set to 8094. 4) CSCP Platform Path:ocpp Click OCPPWebPath → set to ocpp.
  • Page 35: Operating Instructions

    9 Operating instructions Charging with RFID card The charger supports charging with swiping card. When the charger is in standby, the user first inserts the vehicle connector into the vehicle inlet, and then swipes the card to start charging. When the vehicle battery is full or swipes the card to stop charging, the charging is completed.
  • Page 36: Expand Functions

    Expand Functions 10.1 Free charge Allows operators to offer complimentary charging sessions for promotional events, emergencies, or maintenance purposes. Overrides standard billing rules when activated via DIP switch or app. 10.1.1 Hardware setup (DIP switch) Locate the DIP switch panel on the charging station (typically inside a secured compartment).
  • Page 37: Emergency Stop

    3. Toggle the Enable Free Charge option. 10.2 Emergency stop Instantly cuts off power to the charging station and stops the charging process. Designed to prevent accidents by isolating electrical hazards during emergencies such as short circuits, overloads, or physical risks. Operation: 1.
  • Page 38 2. Enable the Emergency stop by choose “Enable” on the Emergency stop drop down box. If the emergency stop function is not needed, you can set it to disabled on the app.
  • Page 39: Dynamic Power Limit

    10.3 Dynamic power limit The BUSH Series features adjustable power limiting functionality. When combined with our EV HUB product, it enables dynamic load balancing, automatically adjusting the charging power of each charging station based on real-time grid load conditions. Refer to the diagram below.
  • Page 40 *Note: If the unit is 0.1kW, the three-phase is not more than 440, single-phase is not more than 146. PIN description is shown below: The connection diagram is shown below:...
  • Page 41: Troubleshooting

    PE Line Break connection may be breakpoints, if the interrupted fault is not removed, please contact LIVOLTEK by phone. Chek whether the emergency stop switch is in the correct The scram switch position, if the fault is Emergency Stop...
  • Page 42 Communication the fault is not become loose or Error removed, please have poor contact contact LIVOLTEK by during phone. transportation. If the fault is not External It could be a removed, please...
  • Page 43 Ac or DC leakage in the entire loop, if Leakage Current exists in the loop the fault is not removed, please contact LIVOLTEK by phone. During Please check the line, if transportation, the Built-in Meter the fault is not...
  • Page 44 50 ° and humidity C and that the wiring Valid for Socket Overtemperature environment, harness is securely Version Only Warning running at high load, connected If the fault or detecting device is not rectified,Please faults contact LIVOLTEK by phone.
  • Page 45: Disclaimer

    Disclaimer There are clear requirements and conditions for the transportation, storage, installation and use of electric vehicle charger. LIVOLTEK is not responsible for providing free relevant services, technical support or compensation, including but not limited to: The charger has expired the warranty period and has not purchased extended warranty service.
  • Page 46 Dear customer, thank you for choosing LIVOLTEK product. For registering product warranty, please prepare everything ready and register on https://www.livoltek.com/registration.html. Product Information Product Model Product S/N Installation Date Installation Company Personal Information Your Name Your Contact Number Your Email Address...
  • Page 47 Manufacturer: Hangzhou LIVOLTEK Power Co., Ltd. Add: 1418-7 Moganshan Road, Hangzhou City, China E-mail: info@livoltek.com Web: www.livoltek.com...
