- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. COMFORT-AIRE PTHP09A230BSC Owner's Manual Shop genuine replacement parts for COMFORT-AIRE PTHP09A230BSC Find Your COMFORT-AIRE HVAC Parts - Select From 1486 Models -------- Manual continues below --------...
- Page 2 Owner’s Manual Packaged Terminal Air Conditioners & Heat Pumps 7,000-15,000 BTUH 7,000-15,000 BTUH Cooling w/Electric Heat Cooling w/Electric Heat with seacoast coating PTAC07A130B PTAC09A130B PTAC12A130BSC PTAC12A130B PTAC12A150BSC PTAC12A150B PTAC15A130BSC PTAC15A130B PTAC15A150BSC PTAC15A150B Heat Pump w/Electric Heat Heat Pump w/Electric Heat with seacoast coating PTHP07A130B PTHP09A130B...
-
Page 3: Table Of Contents
Owner’s Manual - PTAC/PTHP130-150B/BSC CONTENTS THE FOLLOWING WARNINGS ARE VERY IMPORTANT FOR SAFETY. UNIT FEATURES ............3 PLEASE READ THEM CAREFULLY BEFORE INSTALLATION! INSTALLATION INSTRUCTION ........ 5 1. This air conditioner must be installed by a qualified WIRING ..............9 installer. -
Page 4: Unit Features
Owner’s Manual - PTAC/PTHP130-150B/BSC UNIT FEATURES • High Pressure Protection - The unit will shut off automatically when the pressure in the system This unit has many features which are different than is over 638 psi and within 10 minutes, after the those found on conventional PTAC units. -
Page 5: High Voltage
Owner’s Manual - PTAC/PTHP130-150B/BSC ON position enables continuous fan for heating. The • Fan Motors Permanently Lubricated - All units default setting Is fan cycled for heating. have two fan motors for quiet operation and No. 8 -Fan CYC/CON for cooling ON position maximum operating efficiency. -
Page 6: Installation Instruction
Owner’s Manual - PTAC/PTHP130-150B/BSC INSTALLATION INSTRUCTIONS To ensure that the unit operates safely and efficiently, it must be installed, operated and maintained according to these installation and operating instructions and all local codes and ordinances or,in their absence, with the latest edition of the National Electric Code (or CEC for Canadian Installations). - Page 7 Owner’s Manual - PTAC/PTHP130-150B/BSC Preparation of the Wall The sleeve should be installed during construction and lintels should be used to support the block above the wall sleeve. The sleeve can not support the load of bricks/ blocks. For existing construction, wall opening must be created,the proper dimensions are necessary to avoid use of fillers or additional framing .The sleeve is modular in height and width (refer to Fig.
-
Page 8: Chassis Installation
Owner’s Manual - PTAC/PTHP130-150B/BSC CHASSIS INSTALLATION IMPORTANT NOTES: 1. Remove the cabinet front from the chassis as 1. The unit is equipped with a rubber grommet described In Front Removal. mounted compressor. These grommets are factory 2. Insert the chassis into the wall sleeve. set and require no adjustment. -
Page 9: Wiring
Owner’s Manual - PTAC/PTHP130-150B/BSC WIRING Operating Voltage Cord connection to a wall socket is not permitted for Unit Voltage Voltage Utilization Range 265V units. All 265V units must be hard wired using Rating Minimum Minimum the hard wire kit or make use of the plug in receptacle 230/208 in the standard subbase. -
Page 10: Operating Instructions (Accessory Optional)
Owner’s Manual - PTAC/PTHP130-150B/BSC OPERATING INSTRUCTIONS Operation mode buttons Fan Speed button Receiver of IR remote controller signal Press these buttons to select Press this button to the unit mode heat, cool or select the fan speed on fan. high, low or auto. Fan speed indicator lamp. -
Page 11: Ventilation Control
Owner’s Manual - PTAC/PTHP130-150B/BSC VENTILATION CONTROL COOL / FAN / HEAT MODE OPERATION PROCEDURE The ventilation control lever is located at left side of Control panel: unit, behind front panel. • Press the ON/OFF button. NOTE: The vent door shipping tape must be removed •... -
Page 12: Air Discharge Grille
Owner’s Manual - PTAC/PTHP130-150B/BSC Discharge Air Flow WARNING 3. Remove the seven (7) screws which secure the HIGH VOLTAGE discharge air grille to the cabinet front. DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT, FAILURE TO DO SO MAY CAUSE Location of 7 Screws PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. -
Page 13: Yearly Maintenance And Cleaning
Owner’s Manual - PTAC/PTHP130-150B/BSC 2. Pull the filter straight up and remove. Routine scheduled Maintenance 3. Clean filter with vacuum or with running water. To achieve continuing top performance and high Reverse this procedure to reinstall the filter. efficiency, establish a “once a year” cleaning/inspection schedule for the unit. -
Page 14: Normal Operating Sounds And Condition
Owner’s Manual - PTAC/PTHP130-150B/BSC Air sounds 4. Tilt the non-compressor side of the unit up no higher than 45 degrees and allow water to drain out the other The fan cycle switch sets the operational mode of the side of the unit. fan. -
Page 15: Troubleshooting
Owner’s Manual - PTAC/PTHP130-150B/BSC TROUBLESHOOTING POSSIBLE CAUSES SOLUTIONS • Check that plug is plugged securely in wall receptacle. UNIT DOES NOT START • Unit may be unplugged Note: Plug has a test/reset button on it. Make sure that the plug has not tripped. •... -
Page 16: Limited Express Warranty
LIMITED ONE (1) YEAR PARTS AND LABOR EXPRESS WARRANTY The sole remedy under the Limited Warranty is replacement of the MARS/Comfort-Aire/Century warrants all parts of the PTAC or PTHP to be defective part. If replacement parts are required within the period of... - Page 17 8/2017...
