Coby IR850 - Wireless Internet Radio System Quick Setup Manual

Requirements
To connect and use your Internet Radio, you will need the following:
• Broadband Internet connection
A connection speed of 64 Kbps or greater is recommended.
• Wireless Router or Access Point
Your wireless router should support Wi-Fi 802.11b/g connections.
If you have a router that supports 802.11n, make sure that it has
been configured to accept 802.11b/g connections as well.

Basic Controls

Remote Key
Navigate through menus (Left,
1
Right, Up, Down)
Enter a menu selection.
Access the Main menu
2
Change the station information
3
displayed on screen.
Change the function mode
4
(Internet Radio, Music Player,
FM radio)
Turn the unit on or off
5
Turn the volume level up.
6
Function Remote Key
7
For a full description of all available controls,
please refer to the instruction manual.
Quick Start Guide
• Wireless Router Network Settings
You will need to know the name of your network (SSID) as well as
the WEP or WPA password if your network is secured. These set-
ings can usually be found on the administration webpage of your
wireless router. Please refer to your wireless router's documenta-
tion for help.
Function
Turn the volume level down.
Before using the remote control, pull out
the protective strip of plastic from the bat-
tery compartment to remove it.
IR850 | Wireless Internet Radio
1
2
3
4
5
6
7
