Master Flash® Multi-Flash Square Vent Standard
If necessary, use the lines clearly shown on the flashing
to trim an opening 10 - 20% smaller than pipe diameter.
Slide the Master Flash® down the pipe, using a non-petroleum-
based lubricant to ease installation.
Press Master Flash® down, bending it to conform to roof profile or
irregularities. A blunt tool will help to form flashing to tight roof
angles.
Apply sealant between the base of the flashing and the roof.
Fix the flashing to the surface using self-drilling screws assembled
with washers. The spacing between the screws should not exceed
38 mm (1,5 inch.).
Advertisement
Summary of Contents for Aztec Master Flash Multi-Flash
- Page 1 Master Flash® Multi-Flash Square Vent Standard If necessary, use the lines clearly shown on the flashing to trim an opening 10 - 20% smaller than pipe diameter. Slide the Master Flash® down the pipe, using a non-petroleum- based lubricant to ease installation. Press Master Flash®...
- Page 2 Master Flash® Multi-Flash Square Vent Retrofit If necessary, use the lines clearly shown on the flashing to trim an opening 5 - 10% smaller than pipe diameter. Additionally if applicable cut the opening for the zip-tie penetration. Slide the Master Flash® down the pipe, using a non-petroleum- based lubricant to ease installation.
