SERVICE MANUAL

Air-to-water Heat Pump

Vezuri IV

Table of Contents

Troubleshooting

Need help?

Do you have a question about the AZURI Vezuri IV AZI-CQ6.0Pd/NhG4-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Deltron AZURI Vezuri IV AZI-CQ6.0Pd/NhG4-E

Page 1 SERVICE MANUAL Air-to-water Heat Pump Vezuri IV...
Page 2: Table Of Contents
Contents Product Data ........................1 1 Product Data ....................... 1 1.1 Lineup ..........................1 1.2 Nomenclature ........................2 1.3 Product Features ......................2 1.4 Operating Principle ......................5 1.5 Technical Data ........................6 2 Exploded Views and Part Lists ................23 3 Supply Scope ......................36 Model Selection ......................
Page 3 1.1 Control Principle Diagram ....................45 1.2 Control Flowchart ......................48 2 Main Control Logics ....................48 2.1 Cooling ..........................48 2.2 Heating ..........................49 2.3 Water Heating .......................49 2.4 Shutdown ........................50 2.5 Control to the Compressor ....................50 2.6 Control to the Fan ......................50 2.7 Control to the 4-way Valve ....................50 2.8 Control to the Water Pump .....................51 2.9 Control the Electronic Expansion Valve ................51...
Page 4 4.2 Pre-Installation ........................96 4.3 Selection of Installation Location ..................97 4.4 Outline dimension of outdoor unit ...................97 4.5 Installation of Monobolc Unit ...................98 4.6 Installation of Hydraulic Unit ..................100 4.7 Installation of Water Tank ....................103 4.8 Requirements on water quality ..................107 4.9 Wiring of the Terminal Board ..................108 4.10 Wiring of the 2-Way Valve ...................112 4.11 Wiring of Other Thermal ....................113...
Page 5: Product Data
Product Data 1 Product Data 1.1 Lineup 1.1.1 Main Unit Cooling Heating Power Series Model Product Code Capacity Capacity Refrigerant Image Supply (kW) (kW) AZI-CQ6.0Pd/NhG4-E ER01002160 6.50 6.00 AZI-CQ8.0Pd/NhG4-E ER01002170 8.30 8.20 AZI-CQ10Pd/NhG4-E ER01002150 10.20 10.20 AZI-CQ12Pd/NhG4-E ER01002120 AZI-CQ14Pd/NhG4-E ER01002100 13.7 14.2 AZI-CQ16Pd/NhG4-E...
Page 6: Nomenclature
1.2 Nomenclature 1.2.1 Main Unit Description Options AZURI A-AZURI Air to water heat pump Heat Pump Water Heater Heating Mode S= Static; C=Circulating Function Q=Multi-function; Omitted=Single-function 4.0=4.0 kW 6.0=6.0kW; 8.0=8.0kW;10=10kW; 12=12kW; 14=14kW; Nominal Heating Capacity 16=16kW Compressor Type Pd=DC Inverter; Default=On/Off Refrigerant Nh=R32 Design Serial Number...
Page 7 1.3.2 Features Wide Operation Range ◆ Heating: -25~35°C; Cooling: -15~48°C; Water Heating: -25~45°C Unique Low Ambient Dual-stage Compressor ◆ (1) Under low-temperature conditions, compared with the conventional compressor, the dual-stage low ambient dual-stage compressor will generate less loss of heat capacity and get higher energy efficiency. (2) Floodback, high discharge temperature and other problems can be completely avoided under low-temp conditions and the compressor’s reliability will be enhanced greatly.
Page 8 All-in-one Design ◆ (1) The unit can integrate with terminal units, like the radiator, floor heating device, FCU, water heating device, solar kit, gas furnace etc. Versatile functions can meet various kinds of demands from different users and enhance applicability of this product. (2) The all-in-one structure design can save more installation cost, reduce risks of refrigerant leak, and improve safety and reliability of the system.
Page 9: Operating Principle
1.4 Operating Principle 1.4.1 Schematic Diagram...
Page 10: Technical Data
1.5 Technical Data 1.5.1 Parameter List AZI-CQ4.0Pd/ AZI-CQ6.0Pd/ AZI-CQ8.0Pd/ AZI-CQ10Pd/ Model NhG4-E NhG4-E NhG4-E NhG4-E Product code ER01002180 ER01002160 ER01002170 ER01002150 Cooling(floor cooling) 5.00 6.50 8.30 10.20 Capacity*1 Heating(floor heating) 5.00 6.00 8.20 10.20 Cooling(floor cooling) 0.962 1.275 1.56 2.00 Power input*1 Heating(floor heating)
Page 11 AZI-CQ12Pd/ AZI-CQ14Pd/ AZI-CQ16Pd/ AZI-CQ8.0Pd/ Model NhG4-E NhG4-E NhG4-E NhG4-M Product code ER01002120 ER01002100 ER01002110 ER01002520 Cooling(floor cooling) 12.00 13.70 15.50 8.30 Capacity*1 Heating(floor heating) 12.00 14.20 15.7 8.20 Cooling(floor cooling) 2.45 3.00 3.60 1.64 Power input*1 Heating(floor heating) 2.43 2.99 3.45 1.62 EER*1(floor cooling)
Page 12 AZI-CQ10Pd/ AZI-CQ12Pd/ AZI-CQ14Pd/ AZI-CQ16Pd/ Model NhG4-M NhG4-M NhG4-M NhG4-M Product Code ER01002090 ER01002130 ER01002140 ER01002080 Cooling(floor cooling) 10.20 12.00 13.90 15.40 Capacity*1 Heating(floor heating) 10.20 12.00 14.2 15.7 Cooling(floor cooling) 2.13 2.61 3.32 4.05 Power input*1 Heating(floor heating) 2.06 2.49 3.09 3.57 EER*1(floor cooling)
Page 13 1.5.2 Nominal Working Conditions Water Side Heat Source/User Side Item Entering Water Temp Leaving Water Wet Bulb Temp Dry Bulb Temp (°C) (°C) Temp(°C) (°C) FCU Cooling — FCU Heating Floor Cooling — Floor Heating Water Heating 1.5.3 Operation Range Water Side Heat Source/User Side Item...
Page 14 Nominal working datas Inspection Displayed Name Remark range(°C) Cooling Heating Hot water no EVI under T-economizer out -30~150 -20~55 -20~55 temperature sensor resistance 20K cooling T-remote room -30~150 18~30 18~30 18~30 Dis. Pressure -40~70 25~60 25~62 25~62 T-weather depend -30~150 7~25 25~60 based on calculation...
Page 15 (e) Ensure safe grounding and the grounding wire shall be connected with the special grounding equipment of the building and must be installed by professional technicians. (f) The specifications of the breaker and power cable listed in the table above are determined based on the maximum power (maximum amps) of the unit.
Page 16 Cooling Capacity Correction_8 Ambient Temp.(°C) Outflow Water(°C) 4.74 5.25 5.60 5.82 5.95 5.71 5.25 4.00 3.54 4.91 5.42 5.82 6.05 6.17 5.92 5.42 4.11 3.67 5.14 5.65 6.05 6.28 6.40 6.13 5.65 4.28 3.83 5.37 5.88 6.28 6.51 6.63 6.35 5.88 4.40 4.00...
Page 17 Cooling Capacity Correction_14 Ambient Temp.(°C) Outflow Water(°C) 7.92 8.78 9.35 9.73 9.94 9.54 8.78 6.68 5.91 8.20 9.06 9.73 10.11 10.30 9.87 9.06 6.87 6.12 8.59 9.44 10.11 10.49 10.68 10.23 9.44 7.16 6.39 8.97 9.83 10.49 10.88 11.08 10.56 9.83 7.35 6.68...
Page 18 Heating Capacity Correction_6 Ambient Temp.(°C) Outflow Water(°C) 2.52 2.94 3.42 3.96 4.32 4.92 5.28 6.12 6.66 7.62 6.66 6.18 5.34 4.68 2.46 2.88 3.36 3.90 4.26 4.86 5.22 6.06 6.54 7.50 6.54 6.06 5.22 4.56 2.40 2.82 3.30 3.84 4.20 4.80 5.16 6.00...
Page 19 Heating Capacity Correction_14 Ambient Temp.(°C) Outflow Water(°C) 6.96 7.38 9.09 9.66 10.37 11.79 13.06 14.48 15.79 17.89 15.76 14.34 12.64 11.01 6.82 7.24 8.95 9.51 10.22 11.64 12.92 14.34 15.51 17.61 15.48 14.06 12.35 10.72 6.67 7.10 8.80 9.37 10.08 11.50 12.78 14.20 15.36 17.47 15.34 13.92 12.21 10.58 6.67 7.10 8.80...
Page 20 Cooling Capacity Correction_6 Ambient Temp.(°C) Outflow Water(°C) 4.93 4.75 4.55 4.37 3.96 3.47 2.91 2.19 1.77 5.48 5.31 5.10 4.92 4.51 4.02 3.36 2.63 2.22 5.58 5.41 5.20 5.03 4.61 4.13 3.47 2.67 2.25 5.65 5.48 5.27 5.10 4.68 4.20 3.54 2.74 2.32...
Page 21 Cooling Capacity Correction_12 Ambient Temp.(°C) Outflow Water(°C) 4.69 4.52 4.32 4.16 3.76 3.30 2.77 2.08 1.68 5.26 5.10 4.90 4.73 4.34 3.87 3.25 2.55 2.16 5.36 5.19 5.00 4.83 4.44 3.97 3.35 2.59 2.19 5.43 5.26 5.06 4.90 4.50 4.04 3.41 2.65 2.26...
Page 22 (2) 1-Phase units Cooling Capacity Correction_8 Ambient Temp.(°C) Outflow Water(°C) 4.79 4.62 4.41 4.25 3.84 3.37 2.83 2.12 1.72 5.43 5.26 5.06 4.89 4.49 4.01 3.37 2.67 2.26 5.53 5.36 5.16 4.99 4.59 4.11 3.47 2.70 2.29 5.60 5.43 5.23 5.06 4.65 4.18...
Page 23 Cooling Capacity Correction_14 Ambient Temp.(°C) Outflow Water(°C) 4.05 3.90 3.73 3.59 3.25 2.85 2.39 1.80 1.45 4.50 4.36 4.19 4.04 3.70 3.30 2.76 2.16 1.82 4.59 4.44 4.27 4.13 3.79 3.39 2.85 2.19 1.85 4.64 4.50 4.33 4.19 3.84 3.45 2.90 2.25 1.91...
Page 24 COP Correction_6 Ambient Temp.(°C) Outflow Water(°C) 2.11 2.65 3.19 3.89 4.48 5.18 5.89 6.43 6.64 7.02 7.24 7.56 7.78 8.10 1.67 2.16 2.65 3.35 3.94 4.64 5.35 5.94 6.16 6.53 6.75 7.07 7.29 7.61 1.40 1.84 2.11 2.75 3.19 3.78 4.32 5.40 5.67...
Page 25 COP Correction_14 Ambient Temp.(°C) Outflow Water(°C) 1.85 2.33 2.80 3.42 3.94 4.56 5.18 5.65 5.84 6.18 6.37 6.65 6.84 7.13 1.47 1.90 2.33 2.95 3.47 4.09 4.70 5.23 5.42 5.75 5.94 6.22 6.41 6.70 1.24 1.62 1.85 2.42 2.90 3.23 3.52 4.75 4.99...
Page 26 COP Correction_12 Ambient Temp.(°C) Outflow Water(°C) 1.88 2.36 2.84 3.47 4.00 4.63 5.25 5.74 5.93 6.27 6.46 6.75 6.94 7.23 1.49 1.93 2.36 2.99 3.52 4.15 4.77 5.30 5.49 5.83 6.03 6.31 6.51 6.80 1.25 1.64 1.88 2.46 2.94 3.28 3.57 4.82 5.06...
Page 27: Exploded Views And Part Lists
2 Exploded Views and Part Lists AZI-CQ4.0Pd/NhG4-E, AZI-CQ6.0Pd/NhG4-E Name Quantity Condenser Assy Temperature Sensor Temperature Sensor Strainer Display Board Receiver Board Electric Box Assy Main Board Radiator Top cover Leaded PFC Inductance Main Board mounting card(main board) Main Board Bipolar AC Contactor Terminal Board Terminal Board...
Page 28 Name Quantity Communication Interface Board Electrical Retaining Plate Terminal Board Terminal Board Jumper Jumper Supporter 4-way Valve Supporter Magnet Coil Plate-type Heat Exchanger Sub-Assy Auto Air Outlet Valve Water Pump Supporter Water Pipe Connector Handle Right side plate Expansion Drum Strainer Relief Valve Steam current Switch...
Page 29 AZI-CQ8.0Pd/NhG4-E, AZI-CQ10Pd/NhG4-E Name Quantity Condenser Assy Filter Silencer Current Divider Supporter Inductance Box Sub-assy PFC Inductance Radiator Drive Board Top cover Filter Board Filter Mounting plate Main board...
Page 30 Name Quantity Bipolar AC Contactor Main board Electric Box Cover Jumper Jumper Electric Box Assy Terminal Board Communication Interface Board Terminal Board Terminal Board Terminal Board Mounting plate Rear Side Plate Pressure Protect Switch Pressure Protect Switch Relief Valve Pressure Protect Switch Pressure Sensor Magnet Coil 4-Way Valve...
Page 31 Name Quantity Electronic Expansion Valve Nozzle for Adding Freon Plate-type Heat Exchanger Electrical Heater(Compressor) Compressor and Fittings Brushless DC Motor Motor Support Sub-Assy Axial Flow Fan Handle Front Grill Front Side Plate Cabinet Water paper connector...
Page 32 AZI-CQ8.0Pd/NhG4-M, AZI-CQ10Pd/NhG4-M Name Quantity Condenser Assy Filter Silencer Current Divider Supporter Inductance Box Sub-assy PFC Inductance Radiator Drive Board Top cover Filter Board Filter Mounting plate Main board Bipolar AC Contactor Main board Electric Box Cover Jumper Jumper...
Page 33 Name Quantity Electric Box Assy Terminal Board Mounting plate Communication Interface Board Terminal Board Terminal Board Rear Side Plate Pressure Protect Switch Pressure Protect Switch Relief Valve Pressure Protect Switch Pressure Sensor Magnet Coil 4-Way Valve Connection Board Nozzle for Adding Freon Gas-liquid Separator Sub-Assy Electronic Expansion Valve Fitting Evaporator Assy...
Page 34 Name Quantity Motor Support Sub-Assy Axial Flow Fan Handle Front Grill Front Side Plate Cabinet Water paper connector...
Page 35 AZI-CQ12Pd/NhG4-E, AZI-CQ14Pd/NhG4-E, AZI-CQ16Pd/NhG4-E Name Quantity Condenser Assy Strainer...
Page 36 Name Quantity Silencer Current Divider Inductance Box Sub-assy PFC Inductance Radiator Drive Board Filter Board Filter mounting card(main board) Main Board Bipolar AC Contactor Main Board Jumper Jumper Terminal Board Electric Box Assy Terminal Board Terminal Board Electrical Retaining Plate Communication Interface Board Terminal Board Pressure Protect Switch...
Page 37 Name Quantity Nozzle for Adding Freon Compressor and Fittings Electrical Heater(Compressor) Brushless DC Motor Axial Flow Fan Handle Front Grill...
Page 38 AZI-CQ12Pd/NhG4-M, AZI-CQ14Pd/NhG4-M, AZI-CQ16Pd/NhG4-M Name Quantity Condenser Assy Strainer Silencer...
Page 39 Name Quantity Current Divider Reactor Reactor Sub-assy Terminal Board Radiator Main Board Filter Board Mounting card(main board) Main Board Bipolar AC Contactor Main Board Jumper Jumper Terminal Board Electric Box Assy Terminal Board Communication Interface Board Electrical Retaining Plate Terminal Board Pressure Protect Switch Pressure Protect Switch Relief Valve...
Page 40: Supply Scope
Name Quantity Electrical Heater(Compressor) Brushless DC Motor Axial Flow Fan Handle Front Grill 3 Supply Scope S= Standard O= Optional F= Field Supplied Standard Part Name Standard Optional Field Supplied Code Owner's Manual for the Main Unit √ 600005063520 600005064437 Owner’s Manual for the Control √...
Page 41: Model Selection
Model Selection 1 Model Selection 1.1 Specification of Power Supply Power Supply Power Supply Model Model V,Ph,Hz V,Ph,Hz AZI-CQ4.0Pd/NhG4-E AZI-CQ8.0Pd/NhG4-M AZI-CQ6.0Pd/NhG4-E AZI-CQ10Pd/NhG4-M AZI-CQ8.0Pd/NhG4-E AZI-CQ12Pd/NhG4-M 230VAC,1Ph,50Hz 400VAC,3Ph,50Hz AZI-CQ10Pd/NhG4-E AZI-CQ14Pd/NhG4-M AZI-CQ12Pd/NhG4-E AZI-CQ16Pd/NhG4-M AZI-CQ14Pd/NhG4-E AZI-CQ16Pd/NhG4-E 1.2 Operation Conditions Capacities and power inputs are based on the following conditions (floor heating /cooling ) a.
Page 42: Selection Of The Underfloor Coils
2 Selection of the Underfloor Coils 2.1 Calculation of Unit Load for Floor Heating Empirical Values of Floor Heating Load Per Square Meter House W/m Dining Room 100~120 Mater Room 100~110 Guest Room 110~130 Study Room 90~110 Villa W/m Dining Room 110~140 Mater Room 100~120...
Page 43: Quantity And Location Of The Water Manifolds
Square-shaped Coil (Recommended) U-shaped Coil Length of coils is calculated as below: Square-shaped coil: =L*W/tube spacing=area/tube spacing U-shaped coil: =L-1+L*W/tube spacing=L-1+area/tube spacing The reason why the square-shaped coils are recommended is because they can keep even temperature distribution. Special demand can be met by adjusting the tube spacing. Distance from the room to the water manifold should be estimated according to the actual conditions of the project and generally should not exceed 30m.
Page 44: Requirements On Installation Of The Water Manifold
Example for how to calculate the floor heating area per single loop: when the tube length is 120m, and tube spacing is 200mm, then the floor heating area per single loop is 120×0.2=24m (4) One trap (collector) cannot be used for different floors, or it would cause uneven water distribution. (5) Distance between the unit and the water manifold should be within 15m.
Page 45: Section Of Fcu
(3) The water supply valve should be installed upstream of the water manifold and the return valve should be installed downstream of the water manifold. (4) A filter is required upstream of the water manifold. 4 Section of FCU 4.1 FCU Type Selection The air-water fan coil unit is optional for Vezuri units.
Page 46: Selection Of The Water Tank
5 Selection of the Water Tank 5.1 Specifications of the Water Tank 230V-1N-50Hz SXTVD300LC/B-E A single coil with the electric heater is integrated, used for floor heating system 400V-3N-50Hz SXTVD300LC/B-M A single coil with the electric heater is integrated, used for floor heating system 5.2 Volume Selection of the Water Tank 5.2.1 Selection Based on Water Consumption Per Capita Building Type...
Page 47: Heat Load Calculation
6.2 Heat Load Calculation 6.2.1 Load Calculation of a Single Floor Room Area Heat Index (W/m Heat Load (W) Master Room 2296 Bathroom Total Load 2296+900=3196W 6.2.2 Arrangement Design of the Underfloor System for A Single Floor Assumed conditions: the floor is cement or ceramics, the normal external diameter of the heating pipe is 20mm; thickness of the stuffer is 50mm;...
Page 48: Model Selection
Average Floor Temperature Area Average Temperature Maximum Temperature Long-term Dwelling Area 24~26 Short-term Dwelling Area 28~30 Nobody Area 35~40 6.3 Model Selection Heat demand for a single layer: 3196W Heat loss for a single layer: 1016W Total heat load for a single layer: 4212W Total heat load of the building: 8424W Capacity of the main unit should be larger than 8424W, so we can select: AZI-CQ10Pd/NhG3-E or AZI- CQ10Pd/NhG4-E or AZI-CQ10Pd/NhG3-M or AZI-CQ10Pd/NhG4-M.
Page 49: Control
Control 1 Integral Control Concept 1.1 Control Principle Diagram Control diagram ◆ Output Control Field Supply Vezuri IV RS485 Main Board Power Supply Vezuri IV Field Supply Input Control...
Page 50 Instructions for Protective Elements ◆ (1) The outdoor temperature is detected by the sensor installed at fins of the finned heat exchanger, which is mainly used to control the initialization steps of the fan and the electronic expansion valve and also limit the maximum running frequency of the compressor.
Page 51 (11) The tempeaure sensor for the vapor line is used to detect the temperature of the vapor refrigerant line. Under the Cooling mode, it and that for the liquid line together are used to control the opening of the electronic expansion valve 1. (12) The tempeaure sensor for the liquid line is used to detect the temperature of the liquid refrigerant line.
Page 52: Control Flowchart
1.2 Control Flowchart Judgment Cooling Heating Control Control Control Control Indication Control Indication Control Indication Indication Indication Indication Expansion Expansion Expansion Control Indication Control Indication Control Indication Compressor Compressor Compressor Control Indication Control Indication Control Indication Cooling Operation Control Indication Control Indication Heating...
Page 53: Heating
2.1.2 Freeze Protection When it is detected that the leaving water temperature of the plate heat exchanger is lower than the freeze protection temperature, the compressor will drop its operating frequency until it reaches the minimum operating frequency. Then if it is still detected that the leaving water temperature is lower than the freeze protection temperature, the main unit will stop as per the shutdown frequency but the water pump keeps normal operation.
Page 54: Shutdown
(4) Over-temperature Protection for Water Heating When the compressor is running, if it is detected that the leaving water temperature of the auxiliary electric heater of the main unit is higher than the over-temperature protection temperature, the compressor will lower its operating frequency until it reaches the minimal operating frequency.
Page 55: Control To The Water Pump
2.8 Control to the Water Pump The water pump firstly will run at the initialized speed and then adjust the speed according to the entering/ leaving water temperature difference. When the temperature difference is large, the fan runs at the high speed. When the temperature difference is small, the fan runs at the low speed.
Page 56: General
3. General (This picture is just for reference) This display panel uses the capacitor touch screen for input operation. The valid touching area indicates the black rectangle when the display panel lights off. This control panel is of high sensitivity and will response to unexpected click by the foreign matters on the display panel.
Page 57: Menu Page
●Under the combined modes, the temperature set point is for space heating or cooling. Only under the water heating mode, it is for water heating. ●It will go back automatically to the homepage when there is no any operation in ten minutes. 3.2 Menu Page Menu Page Above the menu, the corresponding icon will be displayed based on the mode and status of the controller.
Page 58: Backlight
Icon Description Icon Description Cooling + Hot water WiFi Hot water + Cooling Back Quiet Menu page Sanitation Save Emergency Error [Notes] ●The “Cooling” mode is unavailable to the heating only unit. ●The “Hot water” mode is unavailable to the heating only unit. ●The “Heating + Hot water”...
Page 59: Function Setting
ON Page 4.2 Function Setting [Operation Instructions] 1.At the menu page, by touching “FUNCTION”, it will go to the function setting page as shown in the figure below. FUNCTION Setting Page 2.At the function setting page, by touching the page turning key, it will access to the last or next page. When setting is finished, by touching the menu page icon, it will directly back to the menu page;...
Page 60 Item Range Default Remarks When the water tank is unavailable, it will be Fast hot water On/Off reserved. When the water tank is available, it will be defaulted Cool + hot water Cool/Hot water Hot water to be “Hot water”; when unavailable, it will be reserved.
Page 61 ●Mode setting is allowed only when the unit is turned off, otherwise a dialog box will pop up, saying “Please turn off the system first!” ●When the water tank is unavailable, only “Heat” and “Cool” mode are allowed. ●When the water tank is available, “Cool”, “Heat”, “Hot water”, “Cool+ Hot water”, and “Heat+ Hot water” are available.
Page 62 Timer for Quite Mode This setting will be saved by touching the corner at the upper right corner. [Notes] ●It can be set under both ON and OFF statuses, but will work only when the main unit is turned on. ●When it is set to “On”, it will automatically back to “Off”...
Page 63 4.2.7 "Weekly timer" [Operation Instructions] 1.At the function setting page, by touching “Weekly timer”, it will go to the setting page as shown below. 2.At the “Weekly timer” setting page, as shown in the figure below, the weekly timer can be set to “On” or “Off”. 3.At the “Weekly timer”...
Page 64 2.At the “Disinfection” setting page, the disinfection clock, disinfection temperature and disinfection week can be set and the corresponding setting page will pop up at the right side. 3.Then, this setting will be saved by touching the “Save” icon. [Notes] ●This function is unavailable for mini chillers.
Page 65 [Notes] ●When “Clock timer” has been set and “Hot water” mode is involved, in this case, if “Water tank” is changed to “Without”, “Hot water” will be automatically switched to “Heat”, and “Cool/Heat + Hot water” will be switched to “Cool/Heat”.
Page 66 [Notes] ●When “Weekly timer”, “Preset mode”,“Clock timer” “Temp. timer” have been set at the same time, then the latter takes the priority. ●This setting is valid only when the unit is turned on. ●Under the “Cool” or “Cool+Hot water” mode, the setting targets at “WT-Cool”; while under the “Heat” or “Heat+Hot water”...
Page 67 ●When “Holiday mode” has been activated, the controller will automatically deactivate the “Weekly timer” and “Preset mode”and “Clock timer” and “Temp.timer”. ●Under the “Holiday mode”, when the unit is under the control of room temperature, the set point (room temperature for heating) should be set to 10°C; when it is under the control of leaving water temperature, the set point (leaving water temperature for heating) should be 30°C.
Page 68 4.2.15 "Error reset" [Operation Instructions] At the function setting page, by touching “Error reset”, a choice box will pop up, where by touching “OK” the error will be reset and by touching “Cancel” the error will not be reset. [Notes] ●It can be performed only when the unit is turned off.
Page 69: User Parameter Setting
4.3 User Parameter Setting [Operation Instructions] 1.At the menu page, by touching “PARAMETER”, it will return to the parameter setting page, as shown in the figure below. Parameter Setting Page 2.At the menu setting page, by touching the page turning keys, it is able to switch to the page where the desired parameter is.
Page 70: Commissioning Parameter Setting
Displayed Range Range Full Name Default Remarks Name (°C) (°F) Leaving water temperature Unavailable to mini ΔT-Cool 2~10°C 36~50°F 5°C/41°F difference for chillers cooling (Δt1) Leaving water temperature ΔT-Heat 2~10°C 36~50°F 10°C/50°F difference for cooling (Δt2) Leaving water temperature Unavailable to mini ΔT-hot water 2~25°C 36~77°F...
Page 71 Item Range Default Description When the water tank is unavailable, this setting will be reserved. When it is set to “With”, the solar kitting will Solar setting With/Without Without work on its own. When it is set to “Without”, hot water by the solar kitting is unavailable.
Page 72 [Notes] ●When “Remote sensor” is set to “With”, this setting can be set to “T-water out” or “T-room”. When “Remote sensor” is set to “Without”, this setting can only be set to “T-water out”. ● This setting will be memorized upon power failure. 4.4.2 2-Way valve [Operation Instructions] At the commissioning parameter setting page, by touching “Cool 2-Way valve”...
Page 73 4.4.4 Water tank [Operation Instructions] At the commissioning parameter setting page, by touching “Water tank”, the control panel will access to the corresponding setting page, where “Water tank” can be set to “With" or "Without". [Notes] ●This setting will be memorized upon power failure. ●This setting will become valid only when the unit is turned off.
Page 74 ●When it has been activated, “Floor debug”, “Air removal”, and “Emergen.mode” are not allowed to be activated. ●This setting will be memorized upon power failure. 4.4.6 Other thermal [Operation Instructions] 1.At the commissioning parameter setting page, by touching “Other thermal”, the control panel will access to the corresponding setting page.
Page 75 Under the “Heat + Hot water” mode (“Heat” takes the priority), the other thermal only works for space heating, and the electric heater of the water tank works for water heating. In this case, the 2-way valve is controlled base d on the setting of the control panel, and the 3-way valve will always stop.
Page 76 2.At the “Optional E-Heater” setting page, it can be set to “1”, “2” or “Off”. 3.This setting is used to compare with the ambient temperature. Different comparison results are for different status of the optional electric heater. [Notes] ●This setting will be memorized upon power failure. ●Neither “Other thermal”...
Page 77 4.4.10 Floor debug [Operation Instructions] 1.At the commissioning parameter setting page, by touching “Floor debug”, the control panel will access to the corresponding setting page. 2.At the setting page, “Floor debug”, “Segments”, “Period 1 temp”, “Segment time”, and “ΔT of segment” can be set.
Page 78 ●This setting can be set only when the unit has turned off. When this function has been activated, ON operation is un-allowed. ●Defrosting will quit when the defrosting temperature goes to 20 or the defrosting duration is equal to 10 ℃...
Page 79 [Notes] ●This setting will be memorized upon power failure. 4.4.15 Address [Operation Instructions] At the commissioning parameter setting page, by touching “Address”, it can be set the address. [Notes] ●It is used to set the address of the control panel for being integrated to the centralized control system. ●This setting will be memorized upon power failure.
Page 80 ●Three options are available, "Without", "DHW", and "AIR".When it is set to “AIR”, it will be closed (230VAC) under the cooling/heating mode and opened under the DHW(Hot water) mode; when it is set to “DHW”, it will be closed (230VAC) under the DHW(Hot water) mode and opened under the cooling/heating mode. ●This setting is allowed only when the unit has been turned off.
Page 81: Viewing
[Notes] ●For parameters with different defaults at different conditions, once the current condition changes, the corresponding default also will change. ●All parameters at this page will be memorized upon power failure. 4.5 Viewing [Operation Instructions] 1.At the menu page, by touching “VIEW”, the control panel will go to the sub-menu page as shown in the figure below.
Page 82 Full Name Displayed Name Status Remarks Status of the Chassis heater Chassis heater On/Off Status of the heat exchanger heater Plate heater On/Off Status for the system defrosting Defrost On/Off Status of the system oil return Oil return On/Off Off/Cool/Heat/Hot “Cool”...
Page 83 Full Name Displayed Name Remarks Economizer outlet temperature T-economizer out Remote room temperature T-remote room “NA” for mini chillers Discharge pressure Dis. pressure Weather-dependent target temperature T-weather depend 4.5.3 Error [Operation Instructions] At the “VIEW” page, by touching “Error”, it is able to view errors of the unit, as shown in the figure below. Error View Page [Notes] ●The control panel can display real-time errors.
Page 84 Full Name Displayed Name Water tank temperature sensor error Tank sens. ("NA" for mini chillers) Remote room temperature sensor error T-Remote Air Protection for the flow switch of the heat pump HP-Water Switch Welding protection to the auxiliary electric heater 1 of the heat pump Auxi.
Page 85: General Setting
[Notes]: ●The error log can accommodate up to 20 pieces of error. Name and occurrence time are available for each error. ●When error log exceeds 20, the latest will supersede the earliest. 4.5.5 Version [Operation Instructions] At the “VIEW” page, by touching “Version”, the control panel will go to the version view page, where it is able to view both the program version and protocol version.
Page 86 Item Range Default Remarks “Lighted”: the control panel will always light on. “Energy save”: When there is no Back light Lighted/Energy save Energy save touching operation in 5 minutes, the control panel will be lighted off automatically, but will light on again once there is any touching operation.
Page 87: Intelligent Control
5. Intelligent Control As shown in the figure below, remote control via a smart phone is available for the control panel. [Notes]: ●Make sure the smart phone or tablet computer adopts standard Android or Ios operation system. For detailed version, please refer to the APP. ●The Wi-Fi function doesn’t support Chinese Wi-Fi network name.
Page 88 2.Open GREE+ APP and click “Sign up” for registration. 3.Except sign in in the prompt interface, you can also enter the homepage and click the profile picture at the left upper corner to sign in.
Page 89 4.Click "+" at the right upper corner of homepage to add device. After selecting “VERSATI”, the APP interface will provide relevant operation instructions.
Page 90 Reset the air conditioner (refer to the operation instructions in APP interface) and click “Next” to add home appliance automatically (Wi-Fi password shall be input). Or after setting and energizing the air conditioner, click “Add appliance manually” at the right upper corner to select the wireless network for controlling the device. Then confirm family Wi-Fi and arrange configuration.
Page 91: Setting Of Main Functions
After accomplishing device reset and filling correct information, search device and arrange configuration. 5.2 Setting of Main Functions 1.Set mode and temperature.
Page 92: Setting Of Other Functions
2.Click Func at the left lower corner in device operation interface to enter advanced settings. 5.3 Setting of Other Functions Click the profile picture at the left upper corner of homepage and set each function in the following menu.
Page 93 5.3.1 Home management Click “Home management” to create or manage family. You can also add family members according to the registered account. 5.3.2 Help Click “Help” and view the operation instructions of the APP.
Page 94 3.3.3 Feedback Click “Feedback” to submit feedback.
Page 95: Unit Installation
UNIT INSTALLATION 1 Installation Guides WARNING • Installation should be performed by AZURI appointed servicemen, or improper installation would lead to unusual operation, water leakage, electric shock or fire hazard. • The unit should be installed on the foundation which is capable of supporting the unit, or the unit would fall off or even lead to personal injury.
Page 96: Matters Need Attention
(7) Do not install at a place where inflammable or explosive goods exist or a place subject to severe dust, salty fog and polluted air. (8) Drainage pipe is easy to connect out. (9) Do not install at a place where inflammable or explosive goods exist or inflammable or explosive gas might leak.
Page 97: Service Tools
Usage Name Picture Pipe and Pipe It is used to connect the water pipes. Joint Cut-off Valve It is used to cut off or get through the waterway. 3 Service Tools Name Picture Spanner Screw Driver Pliers Tube Tongs...
Page 98: Installation Instructions
4 Installation Instructions 4.1 Installation Examples CASE 1: Connecting Under-floor Coil for Heating and Cooling Notes (a) Type of thermostat and specification should be complied with installation of this manual; (b) Bypass valve must be installed to secure enough water flow rate, and bypass valve should be installed at the collector.
Page 99 CASE 2: Connecting Sanitary Water Tank and Under-floor Coil Under-floor coil Sanitary water tank Booster heater Notes (a) In this case, three-way valve should be installed and should be complied with installation of this manual; (b) Sanitary should be equipped with internal electric heater to to ensure enough heat energy in the very cold days.
Page 100: Pre-Installation
CASE 3 : Connecting Sanitary Water Tank, Under-floor Coil and FCU Note Two-way valve is very important to prevent dew condensation on the floor and Radiator while cooling mode. 4.2 Pre-Installation (1) Installation of the unit must be in accordance with national and local safety codes. (2) Installation quality will directly influence the use of the air conditioner unit.
Page 101: Selection Of Installation Location
4.3 Selection of Installation Location (1) The outdoor unit must be installed with a firm and solid support. (2) Avoid placing the outdoor unit under window or between two constructions, hence to prevent normal operating noise from entering the room. (3) Air flow at inlet and outlet shall not be blocked.
Page 102: Installation Of Monobolc Unit
4.5 Installation of Monobolc Unit 4.5.1 Installation Clearance Unit:mm Inlet Inlet Outlet 2000 ＞ Outlet (1) When moving the unit, it is necessary to adopt 2 pieces of long enough rope to hand the unit from 4 directions. Included angle between the rope when hanging and moving must be 40° below to prevent center of the unit from moving.
Page 103 (2) Installation notes The unit is not allowed to use in a room that has running fire (such as firesource, working coal gas ware, operating heater). It is not allowed to drill hole or burn the connection pipe. The unit must be installed in a room that is larger than the minimum room area. The minimum room area is shown on the nameplate or following table.
Page 104: Installation Of Hydraulic Unit
4.6 Installation of Hydraulic Unit 4.6.1 Available External Static Pressure of Outlet (1) AZI-CQ4.0Pd/NhG4-E, AZI-CQ6.0Pd/NhG4-E (2) AZI-CQ8.0Pd/NhG4-E, AZI-CQ10Pd/NhG4-E, AZI-CQ8.0Pd/NhG4-M, AZI-CQ10Pd/NhG4-M Notes (a) See the curve above for the maximum external static pressure. The water pump is of variable frequency. And during operation, the water pump will adjust its output based on the actual load.
Page 105 (3) AZI-CQ14Pd/NhG4-M, AZI-CQ16Pd/NhG4-M, AZI-CQ12Pd/NhG4-E, AZI-CQ14Pd/NhG4-E, AZI-CQ16Pd/NhG4-E, AZI-CQ12Pd/NhG4-M, AZI-CQ14Pd/NhG4-M, AZI-CQ16Pd/NhG4-M Notes (a) See the curve above for the maximum external static pressure. The water pump is of variable frequency. And during operation, the water pump will adjust its output based on the actual load. (4) Ambient temperature and leaving water temperature upper limit Note:the ambient temperature and water temperature should be subject to the actual operation of the unit.
Page 106 4.6.2 Water volume and expansion vessel pressure Notes (a) The expansion vessel is 2 liter and 1.5bar pre-pressurized for 4/6/8kW unit; 3 liter and 1.5bar perpressurized for 10/12/14/16kW unit ; (b) Total water volume of 44 liter is default for 4/6/8kW unit and 66 liter for 10/12/14/16kW unit; if total water is changed because of installation condition, the pre-pressure should be adjusted to secure proper operation.
Page 107: Installation Of Water Tank
4.7 Installation of Water Tank 4.7.1 Installation measure The insulated water tank should be installed and keep levelly within 5m and vertically within 3m from the indoor unit. It can be installed in the room. Standing water tank must be installed vertically with the bottom on the ground, never suspended. Installation place must be firm enough and the water tank should be fixed on the wall with bolts to avoid vibration, as shown in the following figure.
Page 108 4.7.2 Outline dimension and parameter of water tank Model SXTVD300LC/B-E SXTVD300LC/B-M Litre 300L 300L D(mm) D1(mm) H(mm) 1585 1585 A(mm) B(mm) C(mm) E(mm) F(mm) G(mm) I(mm) J(mm) K(mm) L(mm) Model SXTVD300LC/B-E SXTVD300LC/B-M Outline (Diameter×H) (mm) Φ620×1585 Φ620×1585 Package (W×D×H)(mm) 815×920×1745 815×920×1745 Net weight Gross weight...
Page 109 Circulating water inlet/outlet of water tank 3/4″Female BSP Cooling water inlet of water tank 3/4″Female BSP Pipe joint 3/4″Female BSP 4.7.3 Connection of waterway system (1) If connection between water tank and indoor unit should be through the wall, drill a hole Φ70 for pass of circulating water pipe.
Page 110 PPR pipe is recommended to avoid freeze damage. (c) Waterway pipelines can’t be installed until water heater unit is fixed. Do not let dust and other sundries enter into pipeline system during installation of connection pipes. (d) After connection of all waterway pipelines, perform leakage test firstly. After that, perform heat preservation of waterway system;...
Page 111: Requirements On Water Quality
① ② ③ ① Safety valve ② Check valve ③ Filter Drainage Installation Mode 2 of the Tap Water Valve (Inlet Water Pressure<0.1MPa) The safety valve is bypass installed in the installation mode 2. A check valve is required at the tap water pipe and installed horizontally with the valve cap vertically upwards and the arrow direction at the valve body the same as the water flow.
Page 112: Wiring Of The Terminal Board
4.9 Wiring of the Terminal Board (1) AZI-CQ4.0Pd/NhG4-E, AZI-CQ6.0Pd/NhG4-E...
Page 113 (2) AZI-CQ8.0Pd/NhG4-E, AZI-CQ10Pd/NhG4-E, AZI-CQ12Pd/NhG4-E, AZI-CQ14Pd/NhG4-E, AZI-CQ16Pd/NhG4-E...
Page 114 (3) AZI-CQ8.0Pd/NhG4-M, AZI-CQ10Pd/NhG4-M Terminal board with the reserved grounding terminal...
Page 115 Terminal board without the reserved grounding terminal Notes: (d) For the terminal board with the reserved grounding terminal, the grounding line should be connected to the grounding terminal at the terminal board (e) For the terminal board without the reserved grounding terminal, the grounding line should be connected to the grounding terminal at the installation board.
Page 116: Wiring Of The 2-Way Valve
(4) AZI-CQ12Pd/NhG4-M, AZI-CQ14Pd/NhG4-M, AZI-CQ16Pd/NhG4-M 4.10 Wiring of the 2-Way Valve The 2-way valve 1 is required to control water flow for cooling or heating operation. The role of 2-way valve 1 is to cut off water flow into the underfloor loop when the fan coil unit is equipped for cooling operation. General Information Type Power...
Page 117: Wiring Of Other Thermal
2-Way 2-Way 2-Way Valve 1 Valve 1 Valve 1 WARNING (1) Normally Open type should be connected to wire (OFF) and wire (N) for valve closing in cooling mode. (2) Normally Closed type should be connected to wire (ON) and wire (N) for valve closing in cooling mode. (ON): Live signal (for Normally Open type) from PCB to 2-way valve (OFF): Live signal (for Normally Closed type) from PCB to 2-way valve (N): Neutral signal from PCB to 2-way valve...
Page 118: Wiring Of Optional Electric Heater
Step 2. Electric wiring work Other thermal L and N connect to XT3~1,2. Optional water temperature sensor connecet to AP1 CN16. Optional water temperature sensor CN16 Step 3. Wired controller setting Other thermal should be selected "with" if necessarily from COMMISION → FUNCTION,then set switch on (outdoor)temperature and control logic(1/2/3).
Page 119: Wiring Of The Gate-Controller
Other Thermal Optional Water Temp. Sensor 3-Way Valve 2 2-Way Valve 1 Mixing Floor Valve Temp. Water Pump Tank Temp. of Heat pump system Water Tank EH Water Tank Step 2. Wired controller setting Optional electric heater should be selected "1/2" group if necessary from COMMISION → FUNCTION,then set switch on (outdoor)temperature and control logic(1/2).
Page 120: Wiring Of The Remote Air Temperature Sensor
4.14 Wiring of the Remote Air Temperature Sensor Front side Back side Remote Air Temperature Sensor 1.5 Meters Doors Remote Environment Temp sensor Electric box Notes: (a) Distance between the indoor unit and the remote air temperature sensor should be less than 15m due to length of the connection cable of remote air temperature sensor;...
Page 121 12 13 14 15 Thermostat How to Wire Thermostat (1) Uncover the front cover of indoor unit and open the control box ; (2) Identify the power specification of the thermostat, if it is 220V, find terminal block XT3 as NO.12~15; (3) If it is the heating/cooling thermostat, please connect wire as per the figure above.
Page 122: Commissioning And Test Run
5 Commissioning and Test Run 5.1 Check before startup For safety of users and the unit, the unit must be commissioned for startup. The procedures are as below: The following items shall be performed by qualified maintenance personnel. Confirm with the sales engineer, dealer, installing contractor and users to make sure the following items finished ×...
Page 123: Trial Run
5.2 Trial run Trial run is testing whether the unit can run normally. If the unit cannot run normally, find and solve problems until the trial run is satisfactory. All inspections must meet the requirements before performing the trial run. Trial run should follow the content and steps of the table below: The following procedure should be executed by qualified maintenance personnel.
Page 124: Test Operation & Troubleshooting & Maintenance
TEST OPERATION & TROUBLESHOOTING & MAINTENANCE 1 Precheck 1.1 Check for Wiring NOTE • Do not check for the power supply unless proper checkout equipment has prepared and preventive measures have been taken, otherwise it would lead to severe injury. (1) Are sizes of connection lines and the air switch properly selected? (2) Does wiring comply with relative standards and electric codes? (3) Is there any incorrect wiring?
Page 125 Code Indication Error Name Source of Error Signal Control Description The plug on temperature sensor is not correctly connected to the It will be automatically Suction temp sensor error socket on mainboard. cleared after the failure is The resistance of temperature removed.
Page 126 Code Indication Error Name Source of Error Signal Control Description The communication line of the unit is not connected. The communication line is not through. Communication The communication line of the It will be cleared once malfunction(between unit is not connected correctly. communication recovers or it outdoor mainboard and The two ends of communication...
Page 127 Code Indication Error Name Source of Error Signal Control Description The resistance of temperature sensor is not correct. De-energize the unit and The plug on temperature sensor outlet temperature High- then, energize it again. If the is not correctly connected to the temp protection malfunction is removed, the socket on mainboard.
Page 128: Flow Chart Of Troubleshooting
3 Flow Chart of Troubleshooting (1) Comp high-pressure protection E1 Compressor high-pressure protection E1 Is the high-pressure switch Replace the high-pressure broken? switch. Is the wiring of the high-pressure Replace the wiring. switch loosened? Is water in the tank inadequate? Fill the tank with tank.
Page 129 (2) Comp Low- pressure protection E3 Compressor low-pressure protection E3 Is the low-pressure switch Replace or rewire broken or is the wiring loosened? the low pressure switch. Does the fan stop or run reversely? Check the fan. Repair the leakage and add refrigerant according Is the system leaked? to the required volume.
Page 130 (4) Outdoor fan error EH Outdoor fan error EH Is the mainboard of the Replace the mainboard outdoor unit damaged? of the outdoor unit. Is the wire of terminals of the mainboard broken? Replace the wire. (5) Temperature sensor error Temperature sensor error Is the plug of the temperature sensor correctly...
Page 131: Diagnosis Of Drive
(6) Communication malfunction E6 Communication error E6 Is the communication Connect the line. line of the unit connected? Does the communication Replace the communication line. line work normally? Is the communication line Reconnect the line. of the unit connected correctly? Is the outdoor unit Supply power to electrically powered on?
Page 132 IPM or PFC Over-temperature Protection(Code:"P8") ◆ “Overtemp.-mod.” is displayed on the wired controller P8 is displayed in the mainboard 88 Indicating Lamp Is the IPM or PFC module of the driver board AP4 tightened ? Tighten the IPM or Replace the driver board AP4 PFC module Work Normally...
Page 133 Drive-to-main-control Communication Error(Code:"P6") ◆ “Drive-main com.” is Displayed on the wired controller P6 is displayed in the mainboard 88 Indicating Lamp Is the CPU tightened? Replace Tighten the CPU the driver board AP4 Work Normally Compressor Startup Failure(code:"LC") ◆ "Start failure" is displayed on the wired controller LC is displayed in...
Page 134 Compressor Current Protection (Code:"P5"); Compressor Motor Desynchronizing (Code:"H7"); IPM ◆ Protection (Code:"H5"); Phase Loss (Code:"LD") “Com. over-curr.”, “Desynchronize”, “IPM defective” or “Phase loss” is Displayed on the wired controller P5、H7、H5 or LD is displayed in the mainboard 88 indicating lamp Is the compressor Adjust the...
Page 135: Daily Maintenance And Repair
5 Daily Maintenance and Repair 5.1 Daily Maintenance In order to avoid damage of unit, all protecting devices in the unit have been set before packaging and delivering, so the user should never adjust or remove them. For the first startup of the unit or next startup of unit after long-period stop (above 1 day) by cutting off the power, please electrify the unit in advance to preheat the unit for more than 8hr Never put sundries on the unit and accessories.
Page 136: Repair
Malfunctions Reasons Troubleshooting 1.Enhance heat insulation efficiency of the 1.Poor heat insulation of water system. system. 2.Poor heat exchange of evaporator. 2.Check if air in or out of unit is normal and clean Poor efficiency of hot water heating evaporator of the unit. 3.Poor refrigerant of unit.
Page 137 Picture Name Function It is used to prevent the heat exchanger from being frozen owing to reduced water flow rate. When the flow rate goes Flow Switch down to the point at which the flow switch will act, the switch will trip off and the unit will raise an alarm and shut down.
Page 138 Pressure Meter Connection Pipe Vacuum pump Leak Detection Methods ◆ The following leak detection methods are deemed acceptable for systems containing flammable refrigerants. Electronic leak detector shall be used to detect flammable refrigerant, but the sensitivity may not be adequate, or may need re-calibration (Detection equipment shall be calibrated in a refrigerant-free area).
Page 139 DISTRIBUTOR www.deltron.hr...

This manual is also suitable for:

Azuri vezuri iv azi-cq8.0pd/nhg4-eAzuri vezuri iv azi-cq10pd/nhg4-eAzuri vezuri iv azi-cq12pd/nhg4-eAzuri vezuri iv azi-cq14pd/nhg4-eAzuri vezuri iv azi-cq16pd/nhg4-eAzi-cq10pd/nhg4-m ... Show all
