Sandel HeliTAVVS ST3453H Installation Manual

Helicopter terrain awareness warning system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ST3453H

Helicopter

Terrain Awareness

Warning System

Installation Manual

Sandel Avionics

2401 Dogwood Way

Vista, CA 92081

Phone (760) 727-4900

FAX (760) 727-4899

Website: www.sandel.com

Email:

support@sandel.com

82050-IM-C

Table of Contents

Need help?

Do you have a question about the HeliTAVVS ST3453H and is the answer not in the manual?

Questions and answers

Summary of Contents for Sandel HeliTAVVS ST3453H

Page 1 ST3453H Helicopter Terrain Awareness Warning System Installation Manual Sandel Avionics 2401 Dogwood Way Vista, CA 92081 Phone (760) 727-4900 FAX (760) 727-4899 Website: www.sandel.com Email: support@sandel.com 82050-IM-C...
Page 2 [This page intentionally left blank] 82050-IM-C ST3453H INSTALLATION MANUAL Page ii...
Page 3 Revision History Revision Date Comments 26-APR-2013 Updated for AR 1294 Updated TOC. All references to 1553B have been updated to 1553. Section 1.1: Introduction updated. Section 1.4: Data recording description updated. Section 1.9: Installation Kit P/N added. Section 1.7: Updated for MIL-STD-1553 for Airdata and Radalt.
Page 4 Updated for AR 1290. Updated TOC. Section 1.5.1: Updated Note. Section 1.7: Updated interface characteristics. Section 1.9: Updated table. Section 2.1: Schematic section number reference updated. Section 3.2: Position interface description updated. Section 4.2: Typo corrected. Section 4.5: Updated section reference. Updated table. Section 4.7: Section number added.
Page 5 [This page intentionally left blank] 82050-IM-C ST3453H INSTALLATION MANUAL Page v...
Page 6: Table Of Contents
TABLE OF CONTENTS GENERAL INFORMATION ............... 1-1 1.1 Introduction ........................1-1 1.2 LIMITATIONS ........................ 1-1 1.3 Radalt Indicator Replacement ..................1-1 1.4 Equipment Description ....................1-1 1.4.1 Features ............................. 1-2 1.4.2 FAA HTAWS Requirement ...................... 1-2 ...
Page 7 4.3 Mechanical Installation Considerations ................4-1 4.3.1 Instrument Location in the Cockpit ................... 4-1 4.3.2 Assembly and Mounting Instructions ..................4-1 4.4 Electrical Installation Considerations ................4-2 4.5 Connector P1 ........................4-3 4.6 Configuration Module Connector ..................4-7 4.7 ...
Page 8 7.12 Radar Altimeter ........................ 7-6 7.13 GPS/FMS/INS Position (POS PRI) ................. 7-7 7.14 FMS Flight Plan (Optional) ..................... 7-7 7.15 GPS/FMS/INS Position (POS SEC) ................7-7 7.16 Traffic ..........................7-8 7.17 MUTE switch ........................7-9 7.18 Sensitivity switch ......................7-9 7.19 ...
Page 9: General Information
The ST3453H has FAA TSO authorization and has been tested to RTCA DO-160F and MIL- STD-810G environmental standards. Sandel Avionics ST3453H HTAWS may be covered by one or more U.S. and foreign patents and pending patent applications, including U.S. Patent Nos. 6,259,378, 6,489,916, 6,507,288, 6,591,170, 6,670,892, 6,683,556, 6,780,788, 6,889,124, 6,972,695, 6,999,023, 7,057,549, 7,187,304 and foreign counterparts.
Page 10: Features
LCD and CRT displays. Even though the Sandel display is in a 3-inch form factor, its image is near the size of a 4” primary display, and can remain directly in the pilot’s field-of-view.
Page 11: Databases
1.5.2 Keeping the databases current Updated databases can be loaded into the equipment using a Sandel supplied Windows loader program, USB cable and a laptop computer. This is done through a high-speed USB port located on the front right corner.
Page 12: Technical Specifications
Technical Specifications The following section describes the technical characteristics, which include the appliance approval basis, physical and electrical properties, electrical connector pin allocation which details function and gradient or equipment protocol, and MIL1553 and ARINC label support. Also included is the description of the ST3453H installation components, other equipment and installation requirements.
Page 13: Operational Characteristics
Connector Weight: 0.12 lbs Mounting: 3 ATI Clamp Display: 200dpi 1.6.3 Operational Characteristics Temperature/Altitude: -40° C to +55° C / up to 55,000 feet including display. CPU and alerting system temperature range operational to -40° C Power Input: 28VDC nominal, 1.0A nominal at 100% brightness. Operating range 22VDC –...
Page 14: System Part Number
The ST3453H HeliTAWS is part of the ST3400H HeliTAWS family. The part number for the Sandel HeliTAWS is comprised of two parts: The basic FAA model designation “ST3400H” and a dash number, ST3400H-xxxx. The dash number designates minor product variations, bezel color and/or NVIS support.
Page 15 Another copy must be presented to the aircraft owner for entry into the aircraft maintenance records, as well as a copy forwarded to Sandel Avionics along with the Warranty Registration Form, to be filed after completion and installation acceptance.
Page 16: Installation Planning
INSTALLATION PLANNING The ST3453H has been designed to ensure maximum interoperability with external avionics. Contact Sandel with any questions about interfacing to specific avionics equipment not covered in the installation drawings in this manual. General Information To simplify installation, after signals are wired to the ST3453H pins, on-screen setups are used in a post-installation procedure.
Page 17 ohm resistance check on ground pins to airframe ground; and presence of inverter 400Hz (if used) only on the appropriate pins.  Review any special items particular to the subject helicopter installation.  Power up the ST3453H in maintenance mode and sequentially access each maintenance page to select the installed equipment.
Page 18: Interface Functions
INTERFACE FUNCTIONS Power The primary power is 28 volt dc on J1-P and is supplied from the aircraft avionics buss through a circuit breaker. Ground is provided on J1-R and should be attached to an approved airframe ground. A 26 volt 400Hz excitation input is available at J1 - W. It is only used in the case of an XYZ heading source.
Page 19: Glideslope
Glideslope This input provides the GPWS mode-5 glideslope alert. MIL-STD-1553, ARINC 429 or low level analog inputs for Glideslope deviation, Glideslope flag status, and Localizer and Localizer Flag are provided. An additional discrete input is available for Back Course from the HSI, which acts to disable Glideslope alerting while on a Back Course approach.
Page 20: External Annunciator-Only Functions
The external switches perform the same functions as their related front panel switches. If power to the unit drops below 20VDC, external switch functions will be inoperative. 3.9.2 External Annunciator-Only Functions These annunciator discrete outputs are available:  Caution Alert ...
Page 21: Audio Output
3.11 Audio Output The audio output produces all advisories and alerts which utilize audio. A headphone output is provided. Connection to this output is required. The headphone output, if used, must connect to the un-switched input of the helicopter audio system.
Page 22: Installation
Mechanical Installation Considerations 4.3.1 Instrument Location in the Cockpit The Sandel ST3453H is a direct replacement for a currently installed 3ATI Radar altimeter indicator. Installation should conform to customer requirements and airworthiness standards affecting the location and type of installation.
Page 23: Electrical Installation Considerations
Electrical Installation Considerations The installing agency fabricates and supplies all wiring harnesses. Refer to the ST3453H Interconnect Wiring Diagrams for detailed wiring information and appropriate notes.  Refer to the Functional Pinout Descriptions for explanations of pin functions.  The length and routing of wires must be carefully planned before starting the installation. ...
Page 24: Connector P1
Connector P1 For electrical characteristics, see the table in section 4.7 by referencing the signal type indicated in italics. Signal types enclosed in parentheses indicate functionality that is reserved. PIN # Name Signal Type (dependent on system configuration) For Analog Radalt Radalt Fail In Discrete >9VDC nom = Radalt Valid...
Page 25 PIN # Name Signal Type (dependent on system configuration) For analog localizer Lat LL Dev DC- Polarity: + indicates right deviation; flight left Lat LL Dev In (A429) Also used as Nav B side 429 -Right A429 RADALT B Low side 429 (R422) - side 422 For analog localizer...
Page 26 PIN # Name Signal Type (dependent on system configuration) For analog Radalt Radalt Valid Discrete Valid Programmable OPEN/GND or OPEN/+28 Note: Not used when 1553/429 is data source A429* A side 429 TCAS A (R422*) + side 422 (R232) Ground side Radalt Hi Res Analog DC+ Pri 1553 Gnd...
Page 27 PIN # Name Signal Type (dependent on system configuration) 429-1 Out B A429 B Side - Alert output to FDR - High Speed (100Kbps) 429-2 Out A A429 A side 429 429-2 Out B A429 B side 429 Selectable Discrete* TCAS Inhibit (default) Open Drain...
Page 28: Configuration Module Connector
PIN # Name Signal Type (dependent on system configuration) Sensitivity Switch In Discrete OPEN/GND Momentary Switch Spare RS232TxD RS232 Spare Discrete 1 Discrete Programmable OPEN/GND or OPEN/+28 Selectable Discrete* Radalt Test (default) Open Drain TCAS Test Mode Selectable Discrete* Reduced Sensitivity Annunciator (default) Open Drain...
Page 29: Electrical Characteristics By Signal Type
Electrical Characteristics by Signal Type Inputs Signal Type Nom Range Absolute Max Z (Ω – Power Off) 1553 18-27Vac 27Vac ≥ 100K A429 +/- 5Vdc 5.5Vdc >100K A429* +/- 5Vdc 14Vdc >100K A429** +/- 5Vdc 33Vdc >100K RS232 +/- 10Vdc 14Vdc >100K RS232**...
Page 30 Power On Load = 60.4K. For Vert/Lat Deviation there may need to be a 1K load somewhere else in the system to meet the receiver load requirements. Check installation instructions for the interfaced receiver. Outputs are protected against shorts to ground. Shorts to power supply may cause damage to components. Discrete inputs actively pulled to 27.5v through 30k ohms when selected ‘active low’...
Page 31: Setup Procedures
SETUP PROCEDURES General Setup procedures for the ST3453H are described along with the Maintenance menu below. The Maintenance Menu is accessed and addressed through the use of pushbuttons and the BRT/MINs knob. No external connector programming is required. Accessing Maintenance Menus To access the Maintenance Menus perform the following operations: ...
Page 32: Configuration Module Failure
Configuration Module Failure If a configuration module error occurs, the CM MOD FAIL screen will appear and will display one or more failure indications in yellow text. The user cannot exit this screen. If this screen appears, the unit is non-operational and must be serviced.
Page 33: Fatal System Error
Fatal System Error If the ST3453H displays a fatal system error message screen, the unit must be restarted. This message will occur only during startup and may be caused by one of the reasons listed below. If the message persists, the unit should not be used. Report the message and accompanying cause (if displayed) to maintenance.
Page 34: Post Installation Procedures
POST INSTALLATION PROCEDURES After all wiring has been verified and the ST3453H has been installed into the panel, the maintenance pages must be accessed to properly configure the ST3453H for the installed equipment. Prior to applying power to the ST3453H, press and hold the [MUTE] and [SENS] buttons, and then apply power to the unit.
Page 35 The Maintenance Page Number/Title is displayed on every maintenance page showing the maintenance page number and title. The Cursor points to the item, which may be modified or selected. If there are no selectable items on the currently displayed maintenance page, the Current Line Indicator is not displayed. ...
Page 36 COMMON Maintenance Page Soft-Keys Name Description Provides access to read secondary data from a piece of equipment. The [DOWN]/[UP] soft-keys VALUE will scroll through each Data Value that is available. When secondary data is not available, the soft- key is not displayed. Returns function of [DOWN]/[UP] soft-keys back from VALUE selection monitoring into TYPE TYPE selection.
Page 37: Index
Page 1: INDEX The Maintenance Index page is a multiple–choice list that provides an index of all other maintenance pages and allows the operator to jump to a particular page. First scroll the Cursor to point to the desired maintenance page listing using the [Up] soft-key or [Down] soft-key or the BRT/MINS.
Page 38: System
Database and software conflicts will be indicated by a red text message at the bottom of the display. A list of possible conflict messages is shown below. If any of these messages are observed contact Sandel Avionics for assistance. Configuration Field...
Page 39: Air Data
Page 3: AIR DATA The Air Data page contains the setup information for the Airdata system. Use the [UP] or [DOWN] soft-keys to select a setup item. This will move the cursor to the appropriate line and display the current input data value, input voltage (if applicable) and pin-pairs of the selected signal.
Page 40: Hdg
Page 4: HDG The HDG page contains the setup information for the HDG system. Use the [UP] or [DOWN] soft-keys to select a setup item. This will move the cursor to the appropriate line and display the current input data value, input voltage (if applicable) and pin-pairs of the selected signal. When selecting analog inputs, a VALID select will be present.
Page 41: Discretes
Page 5: DISCRETES The Discretes page shows all the discrete inputs. A Discrete may be VALID-LOW or VALID-HIGH. In either case a 30K resistor is connected to pull the signal to the invalid state (ground or aircraft power) as applicable unless the valid signal is applied.
Page 42: Output Pins
Page 6: OUTPUT PINS Configuration Field Options Comment NONE P1-NN LOW SENS Ind Configures the output pin. TCAS ALT SEL SW NONE P1-MM RA Self Test OUT Configures the output pin. TCAS S-Test SW NONE P1-CC TAWS INH Ind Configures the output pin. RA MINS Ind NONE P1-BB...
Page 43: Nav / Ils
Page 7: NAV / ILS The NAV/ILS page selects the configuration of NAV receiver Vertical/Lateral Deviation inputs. When the input is selected to 429, the glideslope uses the same 429 port as the NAV. When analog, these two signals are selected separately. Once a selection is made, the port configuration for NAV will be automatically made based on the selection chosen and data will appear in the data VALUE area.
Page 44: Radalt
Page 8: RADALT The Radalt page selects the configuration of Radar altimeter input. If no Radar altimeter is installed set configuration of RALT to NONE. Radar altimeters are selected by equipment type, i.e. ALT55 for Collins ALT55 altimeter, etc. Once the equipment is selected, the Radar altitude can be read from the data VALUE line to check for correct operation.
Page 45 Configuration Options Comment Field NONE 429H ALT50 ALT55 KRA405 Selects the Radar Altimeter source. RT220/300 FF RA 429 FF RA 429H SIK 429 RA PRI SIK 429H 1553 MIL-81296D(AS) -8mv/Ft RT804 Range: 0 to 5,000 ft. Flags @ < -46.7V MIL-81296D(AS) -40mv/Ft RT805...
Page 46 82050-IM-C ST3453H INSTALLATION MANUAL Page 6-13...
Page 47: Pos Pri (Position/Flight Plan)
Page 9: POS PRI (Position/Flight plan) The POS PRI input is used for position data and flight plan data. The multiple–choice list allows the operator to specify the type of GPS/FMS connected to the POS PRI position ports. Select the desired receiver using the [UP]/[DOWN] soft-keys and use the [SET] soft-key to make the selection.
Page 48: Pos Sec (Position)
6.10 Page 10: POS SEC (Position) The POS SEC input is used for position data. The multiple–choice list allows the operator to specify the type of GPS/FMS connected to the POS SEC position ports. Select the desired receiver using the [UP]/[DOWN] soft-keys and use the [SET] soft-key to make the selection. Once a selection is made, the port configuration will be automatically made based on the selection chosen and data will appear in the data VALUE area.
Page 49: Tcas
6.11 Page 11: TCAS The TCAS page shows selections available for Traffic. The multiple–choice list allows the operator to specify the type of Traffic processor connected to the Traffic port. Select using the [UP]/[DOWN] soft-keys and use the [SET] soft-key to make the selection.
Page 50 Configuration Options Comment Field Enter the purchased 11 character key code to enable traffic. Use the MUTE and SENS keys to select the character and the OVLY and TFC TCAS KEY Blank by default keys to move the cursor. When the TCAS selection is set to NONE, the TCAS KEY field is not displayed.
Page 51: Status
6.12 Page 12: STATUS The Status page shows a composite status of all the ST3453H inputs. 82050-IM-C ST3453H INSTALLATION MANUAL Page 6-18...
Page 52: Other Settings
6.13 Page 13: OTHER SETTINGS This page is used to allow the installer to specify the nominal and maximum audio levels for the low level audio output. The low level output acts as master gain. Initiate an audio level test by selecting the desired volume level and pressing the TEST soft-key.
Page 53: Callouts
6.14 Page 14: CALLOUTS The Callouts page allows enabling Radar Altitude audio callouts. Use the [UP] or [DOWN] soft-keys to select a setup item, this will move the Cursor to the appropriate line. [+] and [-] select “ON” or “OFF for each callout. Radar Altimeter input is required for the Callouts to function.
Page 54: Power
6.15 Page 15: POWER The Power maintenance page consists of readouts that monitor the unit’s internal environment and the unit’s power measurements for reference. Any of these items that are outside normal operating limits will post an on-screen error by way of the systems built-in-test processes.
Page 55: Text Message
CRC update process may take up to 60 minutes. This operation may be canceled if desired by pressing the cancel softkey. Contact Sandel if “FAIL” is annunciated for any of the values. If any of the CRC related messages shown below appear when viewing the normal flight display while in the maintenance mode, contact Sandel Avionics for assistance.
Page 56: Cs Status
6.17 Page 17: CS STATUS Displays information about the Configuration Module. 82050-IM-C ST3453H INSTALLATION MANUAL Page 6-23...
Page 57 [This page intentionally left blank] 82050-IM-C ST3453H INSTALLATION MANUAL Page 6-24...
Page 58: Checkout Procedures
CHECKOUT PROCEDURES Power-On Self-Test The Power-On Self-Test capability is an automatic test of equipment condition. It executes during the power-up sequence and reports any internal errors via on-screen readouts. The failure of the display itself is a major failure and will result in the inability to show further system-level error messages.
Page 59: St3453H Configuration
ST3453H Configuration Configure and record configuration information from the ST3453H Maintenance and Summary pages. Items that are preconfigured on the Configuration Module will be locked and not editable during installation. Note: Meet all approved maintenance and safety conditions. Use of appropriate ground power for the aircraft is required.
Page 60: Required Test Equipment
PAGE EQUIPMENT FUNCTION DATA TYPE POS SEC SELECTION SELECTION TCAS TCAS KEY STATUS AUDIO Audio Level ADJUSTMENT BRIGHTNESS OTHER Adj Control CONTROL SETTINGS TAWS INH ON EXTERNAL Ena / Dis MODE 300’ 200’ 100’ 50’ CALLOUTS 40’ 30’ 20’ 10’ Required Test Equipment: ...
Page 61: Air Data Input
Air Data Input Follow Aircraft Manufacturer’s instructions and connect Pitot/Static test box to the aircraft Pitot/Static system. Select ST3453H to Maintenance Page 3: AIRDATA monitor the air data input. RECORD SIGNAL FUNCTION TOLERANCE PASS FAIL VALUE Verify pressure altitude is within Pressure +- 75 ‘...
Page 62: Discrete Inputs
7.10 Discrete Inputs Check all discrete inputs that are interfaced to Sandel ST3453H. See Sandel ST3453H installation wiring diagrams for aircraft. Select ST3453H to Maintenance Page 5: DISCRETES. SIGNAL FUNCTION RESULT PASS FAIL NVIS NVIS Verify that the NVIS display annunciation goes...
Page 63: Radar Altimeter
7.12 Radar Altimeter Note: The Radar Altimeter test may be performed by pressing the Radar Altimeter self test button, or by utilizing a Radar Altimeter test set. This manual references the use of the Radar Altimeter self test button and does not provide the information in the use of a Radar Altimeter test set.
Page 64: Gps/Fms/Ins Position (Pos Pri)
7.13 GPS/FMS/INS Position (POS PRI) Select ST3453H to Maintenance Page 9: POS PRI SIGNAL FUNCTION RESULT PASS FAIL GPS position receiver GPS Lat and Long value displayed should locked on with valid GPS POSITION match position on GPS signal Turn off position GPS GPS position value Lat and Long will not GPS POSITION receiver.
Page 65: Traffic
7.16 Traffic Check traffic if interfaced to ST3453H. Perform checkout per Traffic manufacturer’s installation manual. SIGNAL FUNCTION RESULT PASS FAIL Put Traffic device in Traffic test pattern should display on the TRAFFIC self test mode ST3453H traffic page. 82050-IM-C ST3453H INSTALLATION MANUAL Page 7-8...
Page 66: Mute Switch
7.17 MUTE switch If installed, verify that the external MUTE pushbutton operates the mute function. Holding the MUTE pushbutton for 2 seconds will perform the TAWS INH function and terrain will be removed from the display Pass / Fail: Remarks: ______________________________________________________ 7.18 Sensitivity switch If installed, verify that the external Sensitivity pushbutton operates the Sensitivity mode function.
Page 67: Visibility And Accessibility
Pass / Fail: Remarks: ______________________________________________________ 7.23 Visibility and Accessibility Verify visibility and accessibility of the ST3453H display and controls from the pilot’s seat. View the display from normal, expected viewing angles. This should include viewing the display from all viewing angles that might be encountered during normal cockpit operations. Pass / Fail: Remarks: ______________________________________________________ 82050-IM-C...
Page 68: Sensor Compatibility
SENSOR COMPATIBILITY Note: Current equipment list is being constantly updated. Please contact factory if equipment for your installation is not listed. The following information may be added to and superseded by additional compatibility information in the future without invalidating the other information in this manual. Air Data MODEL INTERFACE TYPE...
Page 69: Heading System / Ahrs
Heading System / AHRS MODEL INTERFACE TYPE Per Configuration MIL-STD-1553 Various Module Various ARINC 429 High Speed Various ARINC 429 Low Speed Various Various XYZ- Navigation Receiver MANUFACTURER MODEL INTERFACE TYPE Per Configuration MIL-STD-1553 Various Module Various ARINC 429 Low Speed Various ARINC 429 High Speed Various...
Page 70: Position - Primary
Magnetic Heading Localizer Deviation Glideslope Deviation Radar Altimeter Radio Altitude GPS/FMS MIL-STD-1553 ONLY The following ARINC 429 labels are representative of the necessary position source content required from MIL-STD-1553. Consult with Sandel Avionics for details. 82050-IM-C ST3453H INSTALLATION MANUAL Page 8-3...
Page 71 Present Position Latitude Present Position Longitude 076 or 370 MSL Alt –or- (HAE Alt w/ Optional MSL Correction) MSL Correction (if not available, table look up by lat/long HFOM VFOM Time HH:MM:SS 313 or 366 Ground Track or Velocity N-S 312 or 367 Ground Speed or Velocity E-W GPS Vertical Speed...
Page 72: Environmental Qualification Form
ENVIRONMENTAL QUALIFICATION FORM NAMEPLATE NOMENCLATURE: [A2F1Z]BBBUXXXXXXZZAZ[ZW][YY]M[A3G33]XXAX TYPE/MODEL NO: ST3453H/ST3400H-90XN TSO NUMBERS: C194, C113, C87, C118 MANUFACTURER’S SPECIFICATION AND/OR OTHER APPLICABLE SPECIFICATION: MANUFACTURER: Sandel Avionics, Inc. ADDRESS: 2401 Dogwood Way Vista, CA 92081 REVISION & CHANGE NOS. OF D0-160: Revision F DATE TESTED:...
Page 73: Additional Tests
Audio Frequency Susceptibility 18.0 Equipment Tested to Category Z, DC System Protection, EUT Op Induced Signal Susceptibility 19.0 Equipment Tested to Category ZW, VSG Systems Protection, EUT Op Radio Frequency Susceptibility 20.0 Equipment tested to Category YY Radio Frequency Emission 21.0 Equipment tested to Category M, EM Protection, EUT Op Lightning Induced Transient...
Page 74: Instructions For Continued Airworthiness
ST3453H. Over time, the light source may dim and the display may not perform as well in direct sunlight conditions. The user must determine by observation when the display brightness is not suitable for its intended use. Contact the Sandel Customer Service if the light source requires service.
Page 75: Removal And Replacement
10.6 Database Updates Database updates are not required. Information regarding new database releases and the content details of the databases may be obtained by visiting the Sandel website (www.sandel.com ). Database updates may be ordered on-line. It is up to the ST3453H customer to determine if a specific database is applicable to their operations.
Page 76: List Of Effective Drawings And Attachments
LIST OF EFFECTIVE DRAWINGS AND ATTACHMENTS Drawing Title 82050-05 LAYOUT, ST3453H INSTALLATION 82050-07 LAYOUT, ST3453H HeliTAWS 82050-10, Sheet 1 POWER & AUDIO 82050-10, Sheet 2 GPS INTERFACE 429/232 82050-10, Sheet 3 RADALT ANALOG 82050-10, Sheet 4 RADALT ARINC 429 82050-10, Sheet 5 HEADING ARINC 429 82050-10, Sheet 6 HEADING XYZ...
Page 77 LAYOUT, ST3453H CHECKED CONFIDENTIAL: PROPRIETARY RIGHTS NOTICE: ALL RIGHTS RESERVED. THIS MATERIAL INSTALLATION CONTAINS THE VALUABLE PROPERTIES AND TRADE SECRETS OF SANDEL AVIONICS MATERIAL OF CALIFORNIA, UNITED STATES OF AMERICA, EMBODYING SUBSTANTIAL CREATIVE RESP ENG EFFORTS AND CONFIDENTIAL INFORMATION, IDEAS, AND EXPRESSIONS, NO PART ST3453H T.
Page 78 3.060 1.530 .177 THRU .228 THRU .005 .005 8 X R .09 1.605 1.530 3.210 3.060 4 X .438 1.605 4 X .438 3.210 SUGGESTED PANEL CUT OUT (REF. ARINC SPECIFICATION 408A) VISTA, CA SIZE CAGE CODE DWG. NO. CATEGORY REV.
Page 79 .010 CHECKED CONFIDENTIAL: PROPRIETARY RIGHTS NOTICE: ALL RIGHTS RESERVED. THIS MATERIAL HeliTAWS CONTAINS THE VALUABLE PROPERTIES AND TRADE SECRETS OF SANDEL AVIONICS MATERIAL OF CALIFORNIA, UNITED STATES OF AMERICA, EMBODYING SUBSTANTIAL CREATIVE RESP ENG EFFORTS AND CONFIDENTIAL INFORMATION, IDEAS, AND EXPRESSIONS, NO PART ST3453H T.
Page 80 REVISIONS ZONE DESCRIPTION DATE APPROVED 8/21/2012 Initial Release SEE NOTE 1. POWER AIRCRAFT POWER AVIONICS POWER BUS COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY AIRCRAFT GROUND AUDIO OUTPUT COMMON 500 OHM AUDIO OUT NOTES: 1. USE 20AWG SHIELDED WIRE. AUDIO PANEL TCAS 2.
Page 81 REVISIONS ZONE DESCRIPTION DATE APPROVED 8/21/2012 Initial Release 12/18/2012 ARINC 429 position sources not supported. Drawing removed. RFU COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY ARINC 429 POSITION SOURCES ARE NOT SUPPORTED. 2401 DOGWOOD WAY VISTA, CA 92081 USA TITLE ST3453H INSTALLATION DRAWING CAGE CODE DWG NO.
Page 82 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 Updated text to RA PRI 12/18/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY Radar Altimeter Analog ANALOG RADAR ST3453H RA PRI ALTIMETER RADALT A ANALOG + RADALT B ANALOG - RADALT VALID ANALOG VAILID NOTE: USE CAUTION IN SPECIFYING, CONFIGURING, AND TESTING ANALOG RADAR...
Page 83 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 12/18/2012 B4, C4 Updated text to RA PRI and RA SEC RADAR ALTIMETER 429 ST3453H ARINC 429 RA PRI RADAR ALTIMETER COMPUTER CONTROLLED DRAWING RADALT A (HI) ARINC 429 TX A DO NOT REVISE MANUALLY ARINC 429 TX B RADALT B (LO) RADAR ALTIMETER 429...
Page 84 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 Updated text to HDG PRI and HDG SEC 12/18/2012 B4, D4 HEADING 429 ST3453H ARINC COMPASS SYSTEM OUTPUT HDG PRI HDG A ARINC 429 TX A COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY ARINC 429 TX B HDG B HEADING 429...
Page 85 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 Updated text to HDG PRI 12/18/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY ST3453H HDG PRI HEADING X HDG A HEADING Y HDG B INVERTER GND HEADING Z EXCITATION HI INVERTER EXC EXCITATION LO HEADING VALID HDG VALID...
Page 86 REVISIONS ZONE DESCRIPTION DATE APPROVED 8/21/2012 Initial Release NAV/GS ANALOG COMPUTER CONTROLLED DRAWING Superflag (Alternate) DO NOT REVISE MANUALLY ST3453H ST3453H 115k Ohms 1/4 Watt +28VDC VERT LL FLAG IN+ GS FLAG + VERT LL FLAG IN+ Glideslope Super Flag VERT LL FLAG IN - GS FLAG - 1k Ohms...
Page 87 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY NAV/GS & LOC 429 ST3453H NAV 429 A TX NAV 429 A NAV 429 B TX NAV 429 B 2401 DOGWOOD WAY VISTA, CA 92081 USA TITLE ST3453H INSTALLATION DRAWING NAV &...
Page 88 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 Updated text to PA PRI 12/18/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY PRESSURE ALTITUDE ANALOG AIRDATA ST3453H HONEYWELL PA PRI AZ-649 AIRDATA A ALTITUDE OUT AIRDATA B SIGNAL COMMON AIRDATA VALID IN AIRDATA VALID OUT CHASSIS GND 2401 DOGWOOD WAY...
Page 89 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 B4, C4 Updated text to PA PRI and PA SEC 12/18/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY ST3453H PA PRI AIRDATA A ARINC 429 TX A AIRDATA B ARINC 429 TX B ST3453H PA SEC AIRDATA A...
Page 90 REVISIONS ZONE DESCRIPTION DATE APPROVED ANNUNCIATORS AND EXTERNAL SWITCHES 8/21/2012 Initial Release ST3453H Removed P3 reference from Audio Enable Relay and 12/18/2012 updated associated *TCAS INH Software Select note. (RED) LOW OUTPUT WARNING ANNUNCIATOR SEE NOTE 2 (TCAS OPERATE MODE) TAWS WARN SEE NOTE 3 (AMBER)
Page 91 1. "RYAN 900BX TAS" VISTA, CA 92081 USA 2. P1-y: TCAS INH 1. Interconnect shown with Sandel as primary Traffic display. TITLE 2. See Manufacturers Installation Manuals for complete wiring interface. 3. Optional external output P1-AA – configure as TCAS TEST MODE .
Page 92 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY NOT REQUIRED. USE ONLY IF Gear/Discrete - Down Low PRESENT IN AIRCRAFT. ST3453H GEAR NOT REQUIRED. USE ONLY IF Gear/Discrete - Down High PRESENT IN AIRCRAFT.
Page 93 REVISIONS ZONE DESCRIPTION DATE APPROVED Initial Release 8/21/2012 COMPUTER CONTROLLED DRAWING DO NOT REVISE MANUALLY ST3453H 1553 BUS A PRIMARY BUS (A) 1553 BUS A POSITIVE 1553 BUS A POSITIVE 1553 BUS A NEGATIVE 1553 BUS A NEGATIVE PRI 1553 GND ST3453H 1553 BUS B SECONDARY BUS (B)
