WARNING

Failure to follow all instructions and safety precautions in this

manual, in the vehicle and body manufacturers' manuals and

on the safety decals attached to the vehicle, body and this

product could result in serious injury or death to operators,

service technicians or bystanders and/or damage to property.

DO NOT operate the vehicle or install this product before you

AWT2079TCC Camera

READ and UNDERSTAND the vehicle Operation Manual, this

manual and other applicable manufacturers' manuals, and all

safety decals. This product must be installed by certified

technicians/installers familiar with the vehicles on which they

USER MANUAL

will be making the installation.

ISSUED OCTOBER 2018

3E-AWT2079TCC-UM-1018

Table of Contents

Need help?

Do you have a question about the AWT2079TCC and is the answer not in the manual?

Questions and answers

Summary of Contents for 3rd Eye AWT2079TCC

Page 1 This product must be installed by certified technicians/installers familiar with the vehicles on which they USER MANUAL will be making the installation. ISSUED OCTOBER 2018 © 2018 3rd Eye 3E-AWT2079TCC-UM-1018...
Page 2: Table Of Contents
How to Connect the Cable How to Connect the Cable How to Connect the Cable ....................................6 Specifications Specifications Specifications ....................................7 Installation Installation Installation ....................................9 Dimensions Dimensions Dimensions ....................................11 ..................................12 Index Issued October 2018 Copyright 2018, 3rd Eye Table of Contents Printed in U.S.A.
Page 3: Safety Precautions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and, 2. This device must accept any interference received, including interference that may cause undesired operation Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.
Page 4 PRODUCT DOCUMENTATION UPDATES Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is subject to change without notice. Please go to to get the most current documentation for your 3rd Eye www.3rdeyecam.com products.
Page 5 USER MANUAL AWT2079TCC AWT2079TCC CAMERA LICENSE PLATE CAMERA USER MANUAL ISSUED OCTOBER 2018 3E-AWT2079TCC-UM-1018 Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.
Page 6: Information
3. Handle this camera with care. Avoid severe shock or impact to the camera as it contains sensitive parts which can be damaged by improper handling. 4. The allowance temperature range for operation of this camera is between -20 to 65°C (-4 to 146°F) Issued October 2018 Copyright 2018, 3rd Eye Information Printed in U.S.A.
Page 7: Features
FEATURES The AWT2079TCC is a OEM Fit camera that directly replaces the License Plate Light on the Ford Transit. This back up camera features a wide angle lens that captures the area not visible to standard rear view mirrors. The AWT2079TCC provides the custom OEM look while maintaining the light function of your license plate frame.
Page 8: How To Connect The Cable
Rotate the ring on the male connector by hand as shown in image below. STEP 3: Then screw in securely to the threads on the female connector. Issued October 2018 Copyright 2018, 3rd Eye How to Connect the Cable Printed in U.S.A.
Page 9: Specifications
DC12V + 10% Power Consumption 1.5W (MAX) Current 125mA (MAX) Imaging Devices 1/3".7 Digital Sensor TV System NTSC Effective Pixels 648(H) x 488(V) Visual Resolution 480 TV Lines Sync. System Internal Issued October 2018 Copyright 2018, 3rd Eye Specifications Printed in U.S.A.
Page 10 USER MANUAL AWT2079TCC SPECIFICATIONS (CONTINUED) Scanning System 525 Lines /60 Fields S/N Ratio More than 48dB (AGC OFF) Electronic Shutter Auto 1/60 (1/50) - 1/100,000 sec. Issued October 2018 Copyright 2018, 3rd Eye Specifications Printed in U.S.A.
Page 11: Installation
STEP 3 Connect OE Camera to supplied harness and tap power and ground. STEP 4 Adjust contrast and brightness setting with the monitor. Issued October 2018 Copyright 2018, 3rd Eye Installation Printed in U.S.A.
Page 12 USER MANUAL AWT2079TCC INSTALLATION (CONTINUED) Issued October 2018 Copyright 2018, 3rd Eye Installation Printed in U.S.A.
Page 13: Dimensions
USER MANUAL AWT2079TCC DIMENSIONS Issued October 2018 Copyright 2018, 3rd Eye Dimensions Printed in U.S.A.
Page 14: Index
INDEX dimensions features how to connect the cable installation package contents specifications Issued October 2018 Copyright 2018, 3rd Eye Index Printed in U.S.A.
Page 15 WARRANTY DISCLAIMER 4.1 This warranty shall become null, void, and not apply if Client fails to notify 3rd Eye in writing of such defects prior to the expiration of the Warranty Period, if the defect is not reproducible, or if the defect is caused by (a) customer damage, negligence, misuse, tampering, accident, fire, variation or interruption of electricity;...
Page 16 3rd Eye Customer Care: 866-804-2984 Environmental Solutions Group 201 W. Main Street, Ste 300 Chattanooga, TN 37408...
