Summary of Contents for Powerhorse 6133517
- Page 1 20in. Surface Cleaner Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #6133517 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a POWERHORSE product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): _____________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ......................4-5 Specific Operation Warnings ....................... 6 Main Parts of Product ........................... 6 Assembly Instructions ........................6-9 Before Each Use ............................ 9 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use This surface cleaner is designed to clean a variety of outdoor surfaces such as concrete, asphalt, paving stone walkways pool decks etc. The cleaner connects to a pressure washer rated up to 4000 PSI, 10 GPM with fluid temperatures up to 212° F. Packaging Contents ... - Page 5 ⚠WARNING PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury.
-
Page 6: Specific Operation Warnings
Specific Operation Warnings ⚠WARNING DO NOT exceed the rated PSI capacity. Keep body parts clear of nozzle heads and away from skirt while operating the machine. DO NOT lift the surface cleaner from the surface or point nozzle heads at people while operating. ... - Page 7 Picture A Insert L=65mm Lock Pin into both outside aligned hole to fix down strut assembly with main machine general rotate assembly in step 1. Page 7 of 16...
- Page 8 Picture B Further fix with B-shaped Lock Pin on inner side after step 2, as <Picture B> shows. Picture C Thread sealing taped high-pressure hose 1/4 NPT connector with spray gun and make sure it tightened. As <Picture C> shows. Picture D Use zip tie to fasten high pressure hose with strut <Picture D>.
-
Page 9: Before Each Use
Picture F Thread sealing taped high pressure hose assembly connector side into main machine rotate assembly hole as <Picture G> shows. Picture G Before Each Use ⚠WARNING Perform the following inspections before each to ensure the cleaner is working properly. ... -
Page 10: Operating Instructions
Operating Instructions ⚠WARNING Do not use the surface cleaner with a pressure washer that has a fluid delivery greater than 4000 PSI, 10 GPM, and 212° F. Fluid delivery above these parameters may overload the cleaner and cause damage to components and possibly person injury. ... -
Page 11: Troubleshooting
Maintenance Interval Maintenance Point Turn off electricity equipment Keep product inner wall and brush under water to flash dirt away inside and outside Daily after operating Wipe water stains off Store under dry and ordinary room temperature Clean nozzle regularly After the first 20 operating hours Remove dirt attached on nozzle Check screw or nut about stability... -
Page 12: Parts Diagram
Parts Diagram Page 12 of 16... -
Page 13: Parts List
Parts List Reference Part Number Part Description Quantity G02629 G26 Spray Gun 000436 Steel Rubber High-pressure Hose 000437 Up Strut Assembly 000435 Gun Fixture 000438 Down Strut Assembly 000439 20inch General Rotate Assembly 900749 Zip Tie 000441 Brush Assembly 000440 Rotate Pole Assembly 200769 Connector Base... - Page 14 Replace a Nozzle To replace a clogged, worn, or damaged nozzle, simply unscrew it from the sprayer and screw on a new or cleaned replacement nozzle. User should twist nozzle with thread sealing tape before applying to rotate tube assembly, without thread sealing tape may cause water leak problem.
-
Page 15: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Powerhorse product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 16 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in THAILAND Page 16 of 16...
