USER MANUAL
I
COEX™ 3000 LE Series Camera
Station
Installation and Maintenance
Document Number
06\PM0624
Issue
2
Date
September 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COEX 3000 LE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Synectics COEX 3000 LE Series

  • Page 1 USER MANUAL COEX™ 3000 LE Series Camera Station Installation and Maintenance Document Number 06\PM0624 Issue Date September 2022...
  • Page 2 Synectics will not accept liability for any loss, damage, costs, actions or demands (of any kind) suffered by any party who uses (in any way) or relies on (directly or indirectly) any information contained in this document, provided always that nothing herein will exclude or limit Synectics' liability to third parties in respect of matters for which it cannot lawfully exclude liability.
  • Page 3: Table Of Contents

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Contents Introduction Scope and Conventions Instructions for Safe Use Regulatory Information Product Description Model Code Designations 2.1.1 Getting to Know Your Camera Product Marking Accessories Special Tools Installation Orientation of the Pan-Tilt-Zoom (PTZ) Model Mounting the PTZ Model Orientation and Mounting the Fixed Camera Model Terminating the Camera...
  • Page 4: Introduction

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Introduction Synectics specialize in the design, manufacture and supply of turnkey CCTV surveillance system solutions, providing COEX™ products for the Oil & Gas, Marine and Industrial markets. For further information, visit our website at www.synecticsglobal.com...
  • Page 5: Instructions For Safe Use

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Instructions for Safe Use Read this manual thoroughly and retain it for future reference. Before installing or operating this equipment, observe the following warnings: The equipment operates flameproof joints which have widths and gaps which are other than the relevant minimum or maximum permitted in Table 3 of IEC 60079-1.
  • Page 6 Only use tools and replacement parts supplied or recommended by Synectics. Any repairs or repla- cing of parts must be carried out by the manufacturer or an approved repair agent. Do not attempt to open the equipment without the approved tooling.
  • Page 7 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL The following tables itemize each flame path, detailing the maximum constructional gap and minimum width. It is your responsibility to ensure that these flame paths are maintained within the following parameters for the lifetime of the equipment.
  • Page 8: Regulatory Information

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Optical Output Operation This device may contain lasers depending on the model selected. All lasers incorporated are Class 1 in accordance with IEC60825-1 and meets the International Electro-technical Commission (IEC) for eye safety standards.
  • Page 9 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL user will be required to correct the interference at their own expense. Modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment under EU rules. Europe This product fulfils the requirements for immunity according to EN 61000-6-2 - Generic standards, immunity for industrial environments (class A device).
  • Page 10: Product Description

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Product Description The COEX™ product range has been designed to encompass fixed and pan-tilt-zoom models, providing the versatility required to meet each customer's specific needs. The COEX™ 3000 LE Series Camera Station offers the following features as standard: ATEX &...
  • Page 11: Model Code Designations

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Model Code Designations 2.1.1 Getting to Know Your Camera Product model designations can seem confusing, that is why we have broken this down to explain exactly what it means, so you can identify your particular model and understand its capabilities. Model Code Designations For more information on each designation, please read the notes on the next page.
  • Page 12 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Designation Descriptions Housing Size The size 1 housing accommodates one day/night camera or one thermal camera. Speed/Type Continuous variable speed affords rotation of the pan axis without physical limit stops. Preset positioning and programmable soft-stops are available.
  • Page 13: Product Marking

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Product Marking The product model designation is detailed on the stainless steel label, permanently fixed to the camera enclosure. All certification details and ratings, together with the serial number are either etched, engraved or stamped for maximum durability.
  • Page 14: Accessories

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Accessories The following items may be ordered separately for use with the C3000 camera stations: Part Number Description Preview COEX™ C-Series Stainless Steel Mounting 64-0000-0711 Bracket (8 hole variant) COEX™ C-Series Stainless Steel Mounting 64-0000-0018 Bracket (4 hole variant) COEX™...
  • Page 15 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Part Number Description Preview COEX™ C-Series Stainless Steel Fall Arrestor 64-0099-0000 Arrangement (Base type 1 variant) COEX™ C-Series Stainless Steel Fall Arrestor 64-0099-0001 Arrangement (Base type 3 variant) 80-9251-0000 Corcom - 10EMC1 - EMC Mains Power Filter Copyright 2022 ©...
  • Page 16: Special Tools

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Special Tools Part Number Description Preview 55-0000-0006 C3000 Base Type 1 Access Tool 55-0000-0007 C3000 Base Type 2 Access Tool 55-0000-0008 C3000 Pan and Tilt Access Tool 55-0000-0009 C-Series Wiper Lip Seal Replacement Tool 55-0000-0005 C3000 Wiper Rod Grease Applicator Copyright 2022 ©...
  • Page 17 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Part Number Description Preview C3000 0-20Nm Torque Wrench with 55-0000-0003 Adaptors C3000 with Base Type 1 40-200Nm Torque 55-0000-0000 Wrench with Adaptor C3000 with Base Type 2 40-200Nm Torque 55-0000-0002 Wrench with Adaptor Copyright 2022 ©...
  • Page 18: Installation

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Installation Orientation of the Pan-Tilt-Zoom (PTZ) Model The C3000 PTZ model is factory configured for upright or inverted orientation, depending on the customer's order. To switch the camera's orientation, follow the steps detailed below (the following example shows changing the camera from upright to inverted;...
  • Page 19: Mounting The Ptz Model

    Mounting the PTZ Model Ensure that the support/mounting structure is secure and rigid. Synectics is not liable for any loss, damage or injury resulting from poor structural mounting or installation. Installing under gantries and steel structures may lead to cross-contamination on the stainless surfaces and result in superficial surface corrosion of this product.
  • Page 20 Getting to Know Your Camera section. Synectics recommends the following installation method for wall brackets to achieve the correct field of view. This method ensures that the camera is oriented on the bracket with reference to the cable tail direction, so that when the camera is viewing down and travels around its pan rotation, the cable does not obstruct on the field of view.
  • Page 21 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Setup: Factory-fitted mechanical limits are not adjustable. The continuous rotation model has no mechanical limit fitted to the pan axis. Note: If an 8-hole bracket is specified, only 4 of the 8 holes are utilized for fixing the camera. The 8- hole bracket simply provides the added benefit of allowing the camera to be positioned at 45°...
  • Page 22: Orientation And Mounting The Fixed Camera Model

    To switch the camera's orientation, follow the steps detailed below. Ensure that the support/mounting structure is secure and rigid. Synectics shall not be liable for any loss, damage or injury resulting from poor structural mounting or installation. Installation under gantries and steel structures can lead to cross-contamination on the stainless surfaces and result in superficial surface corrosion of this product.
  • Page 23 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Base Type 3 and 4 Fixed Cameras 1. Position the camera station on the support 2. Adjust the tilt angle by loosening the 2X structure, as shown. Direct the camera at the socket head cap screws as shown.
  • Page 24: Terminating The Camera

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Terminating the Camera C3000 camera stations are factory fitted with a composite cable tail. The cable is connected to the termination PCB within the camera station. Warning: All host cables and cable entry devices must be suitably rated for the equipment and potentially hazardous areas (check certification label on the rear of camera housing).
  • Page 25 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL PTZ Base Type 1 - Standard Cable - Termination EL10652 PCB The following table displays the assigned identification of the individual cores or conductors of the factory- fitted standard cable tail (always check the project-specific documentation, if supplied). Assignment Color Wire Type...
  • Page 26 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Access to Fixed/PTZ Base Type 3 and 4 - Termination Compartment Warning: All host cables and cable entry devices must be suitably rated for the equipment and potentially hazardous areas (check certification label on the rear of camera housing). They must also have a suitable IP rating for the equipment and the proposed environment.
  • Page 27 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Protective earth terminal 2. The protective earth terminal must be used to earth the equipment. Terminate the incoming earth to the main bond provision (1). Secondary bonds (2) shall be assembled as above, but shall have M6 shakeproof washers (3) assembled as shown and secured with M6 nuts (4) and firmly tighten.
  • Page 28 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL 5. Route all excess lengths of fiber optic cables around the inside of the tray to restrict movement 7. Fusion splice as necessary to short pigtails and avoid sharp bends. Fusion splice protectors and where applicable route fiber optic cables (2) can be held in the position shown via the back around the inside of the tray and...
  • Page 29 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Warning: Do not force closed, as this may damage the connector. If in doubt, withdraw the electronics chassis and refit, gently moving it back and forth to get a positive connector engagement.
  • Page 30 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Fixed/PTZ Base Type 3 - Standard Cable - Termination EL12271 The following table displays the assigned identification of the individual cores or conductors of the factory- fitted cable tail (Always check project-specific documentation, if supplied). Assignment Color Wire Type...
  • Page 31 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Note: An optional board (EL13726) may be fitted in place of EL12271 for Base Type 3, enabling mains or volt-free closing contact wash switching. Copyright 2022 © Synectic Systems Group Limited. All rights reserved. 31 of 63...
  • Page 32 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Fixed/PTZ Base Type 4 - Standard Cable - Termination EL12271 The following table displays the assigned identification of the individual cores or conductors of the factory- fitted cable tail (Always check project-specific documentation, if supplied). Assignment Color Wire Type...
  • Page 33 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Note: An optional board (EL13726) may be fitted in place of EL12271 for Base Type 4, enabling mains or volt-free closing contact wash switching. Copyright 2022 © Synectic Systems Group Limited. All rights reserved. 33 of 63...
  • Page 34 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Access to Fixed Camera Housing Warning: All host cables and cable entry devices must be suitably rated for the equipment and potentially hazardous areas (check certification label on the rear of camera housing). They must also have a suitable IP rating for the equipment and the proposed environment.
  • Page 35 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Fixed Camera - Standard Cable - Termination PC1703 The following table displays the assigned identification of the individual cores or conductors of the factory- fitted standard cable tail (always check project-specific documentation, if supplied). ID-Pin Connector Type Assignment...
  • Page 36: Auxiliaries - Setup And Configuration

    The camera station may be harmed or permanently damaged if the resulting high voltage back EMF is not suitably suppressed. For further information or advice, contact Synectics. Fixed camera models come equipped with two output relays and up to 4 alarm inputs.
  • Page 37 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL The JP6 header configures the behavior of Relay 1. By default the unit is configured as shown in figure 1. Moving the jumper on JP6, as shown in figure 2, changes it to a closing contact output. The JP5 header configures the behavior of Relay 2.
  • Page 38: Configuration

    Synxplorer to discover the unit and discern its IP address. Unit Discovery Using Synxplorer Synxplorer is a utility which identifies Synectics web-server equipped devices on a network and lists them. Using this list, you can identify such devices and their current network settings. This method is especially effective if you have more than one unit on the same network.
  • Page 39: Troubleshooting

    After initial issue diagnosis, upgrade to the latest available version before attempting other troubleshooting processes. You can download the latest available firmware from the Synectics Global Support Portal: https://support.synecticsglobal.com To apply a new firmware file to the camera: Access the camera unit's GUI using its current IP address as a URL.
  • Page 40 ONVIF client. For this reason, it is recommended to use an NTP server to synchronize all units (if available within the local network). Download the latest available firmware version from the Synectics Global Support Portal: https://support.synecticsglobal.com URL format: rtsp://***.***.***.***/stream#...
  • Page 41 Ensure the switch setting for fibre optic speed is set to match the SFP fitted. Fiber speed is printed on the label of the SFP. Fiber-enabled units equipped with the Synectics SYN2153 fiber modem are configured as shown in the following table. Switch Switch...
  • Page 42 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Troubleshooting Day/Night Video Ensure that the unit is powered on properly and that the supply fuse is not blown. In the GUI: Go to the Home tab and check for live video. Using the drop-down, select Stream 1, Stream 2 ..
  • Page 43 Continuous rotation units require a wash preset to be defined. Ensure this is set properly in the GUI. For information, see the COEX™ LE Series Camera Station - Software Configuration Guide on the Synectics Global Support Portal. In the GUI:...
  • Page 44 To raise a support request ticket, go to the Synectics Global Support Portal: Helpdesk https://support.synecticsglobal.com/hc/en-gb/requests/ticket_forms/new?preview [theme_id]=200332783&preview_as_role=end_user To return the unit, go to the Synectics Global Support Portal and complete the Return Return Material Authorization (RMA) form, giving as much detail as possible: Product https://support.synecticsglobal.com/hc/en-gb/articles/202215733-Return-Material-...
  • Page 45 USER MANUAL Note: Contact the manufacturer of the microSD for information regarding its reliability and typical lifespan. Continuous recording will shorten the microSD card lifespan. Synectics recommends that you use Class 10 microSD cards. Copyright 2022 © Synectic Systems Group Limited. All rights reserved.
  • Page 46: Maintenance

    Replace components if necessary. If fitted, inspect wiper blades for wear or damage. Note: The wipers are consumable items. Synectics recommends replacing the wipers every 12 months to maintain their full functionality during continued use (more often might be required depending on local environmental conditions).
  • Page 47 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Routine Inspection - Visual A visual check of the unit should be carried out regularly. Ensure that there are no obstructions capable of fouling the movement or the equipment when in motion. Visually check that the following components are present and that there are no visible signs of damage or excessive wear (see following diagrams for each component): Camera mounting fixings...
  • Page 48 Synectics immediately. Failure to do so might result in serious injury and invalidation of the warranty For replacement parts, contact Synectics, quoting the serial number of the unit, the part number and a description of the required part Warning: It is the responsibility of the end user to ensure all the flame path characteristics are maintained for the lifetime of the product.
  • Page 49 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Detailed Inspection - Camera Enclosure Ensure unit is de-energized before carrying out any detailed inspection work. A further detailed inspection may be carried out by a suitably trained engineer when it is necessary to enter the camera enclosure.
  • Page 50 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Detailed Inspection - Pan and Tilt Enclosure Ensure unit is de-energized before carrying out any detailed inspection work. If it is necessary to enter the pan and tilt enclosure, a further detailed inspection may be carried out by a suitably trained engineer.
  • Page 51 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Detailed Inspection - Base Type 1 Enclosure Ensure the unit is de-energized before carrying out any detailed inspection work. If it is necessary to enter the base type 1 enclosure, a further detailed inspection may be carried out by a suitably trained engineer.
  • Page 52 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Detailed Inspection - Base Types 3 and 4 Enclosure Ensure the unit is de-energized before carrying out any detailed inspection work. If it is necessary to enter the base type 3 enclosure, a further detailed inspection may be carried out by a suitably trained engineer.
  • Page 53 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL To refit the components: Carefully slide the electronics chassis into the enclosure, as shown in the diagram on the left. Ensure locating pin aligns with the hole on the gland plate, and the D connector engages correctly with the chassis.
  • Page 54: Spare Parts

    65-0099-0005 Replacement wash hose 65-0099-0006 C3000 wash hose bracket * Synectics may require further information at the time of ordering, as the replacement requires model specific configuration. Copyright 2022 © Synectic Systems Group Limited. All rights reserved. 54 of 63...
  • Page 55: Product Specification

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Product Specification Product model options displayed in [ ] 1. CERTIFICATIONS / RATINGS* ATEX II 2GD, Ex db IIB/IIC Gb; Ex tb IIIC Db; T4 / T5 / T6 ATEX, IECEx & UKCA EN60079-0, EN60079-1, EN60079-31, IEC60079-0, IEC60079-1, IEC60079-31 Certified Temperature (Fixed)
  • Page 56 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL 2. MECHANICAL Fixed Material Electro-polished 316L stainless steel Window Optical 4K grade toughened glass, thermostatically operated demister [wiper* Pan Turning Circle Non Applicable Ø 560 mm / 22.05" Ø 360 mm / 14.17" Tilt Turning Circle Ø...
  • Page 57 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL 3. ELECTRICAL Fixed Fixed / Base Type 1 / Input 24 V AC/DC (±10%) 50/60 Hz Base Type 2 / Base Type 4 Voltage Options Base Type 3 (100 to 240) V AC 50/60 Hz 8 VA Quiescent 9 VA Quiescent Fixed...
  • Page 58 Audio Detection* Variable detection level and time interval Direct to SD card Local Recording* Synectics Intelligent Edge Recording (SIER) Dependent on certification and equipment fitted. Dependent on cable tail option. Wash output relay option shall be specified at the time of order..
  • Page 59 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL 5. DAY/NIGHT CAMERA / LENS Image Sensor 1/1.8" Progressive CMOS Sensor 1/2.8" Progressive CMOS Sensor 4K 2160p 25/30 fps FHD 1080p 25/30/50/60 Signal System FHD 1080p 25/30 fps 3864 (H) x 2180 (V), Approximately 8 2065 (H) x 1553 (V), approximately 3 Effective Pixels megapixels...
  • Page 60 COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL 7. NETWORK Interface Options* Ethernet (100Base-T, 10-Base-T), Auto duplex, Auto/10/100 IPv4/v6, TCP/IP, UDP, ICMP,ARP, DHCP, DNS, DDNS, HTTP, HTTPS, NTP, RTSP/RTP, Protocols IGMP, SNMP, TLS, PPPoE, QoS, UPnP, SMTP, FTP Control Protocol* SYNX HD, ONVIF (Profile S/G/T compliant) Video Stream Delivery RTSP/RTP (Unicast: UDP/TCP, Multicast UDP)
  • Page 61: Warranty

    If this unit fails to operate due to a defect of materials or workmanship within twelve (12) months of the delivery date, it will either be repaired or replaced by Synectics, on a return to base basis. If a defect does occur, contact the dealer from whom you purchased this equipment, quoting original purchase order number and serial number of the part.
  • Page 62: Correct Disposal Of This Product

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Correct Disposal of this Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking, shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
  • Page 63: Contact Information

    COEX™ 3000 LE Series Camera Station Installation and Maintenance USER MANUAL Contact Information For product and software assistance, visit Synectics online at www.synecticsglobal.com or search our Global Support Portal at https://support.synecticsglobal.com/hc/en-gb. If you require further assistance, contact us directly: Synectic Systems Group Ltd...
