Raynic CR1005 Quick Start Manual

Extra Large Digital Calendar Clock With Thermometer
CR1005
THE BEST CHOICE FOR YOUR HOME
Chapter 1 LOCATION OF CONTROLS
2
3
6
7
9 12 14 20
10 13 16
11 15 17
25 26 27
1. WEEK DISPLAY 2. TIME DISPLAY
4. ALARM 1 / ALARM 2 / ALARM 3 INDICATOR
6. MONTH DISPLAY 7. DATE DISPLAY
9. NEXT BUTTON 10. PREV BUTTON
12. ALARM 1 BUTTON 13. ALARM 2 BUTTON
15. ALARM OFF BUTTON 16. SNOOZE / DIMMER BUTTON
17. YEAR BUTTON 18. DAY BUTTON
20. HOUR BUTTON 21. MINUTE BUTTON
23. 24 HOUR / 12 HUOR SWITCH BUTTON
24. FAHRENHEIT / CELSIUS SWITCH BUTTON
25. SPEAKER 26. HEAT EMISSION HOLE 27. HANGING HOLE
28. TEMPERATURE INDUCTOR 29. BACKUP BATTERY COMPARTMENT
30. DC POWER INPUT INTERFACE
32. USB OUTPUT CHARGER 33. BRACKET
1
4
C
5
8
22 24
21 23
28
29
30
31
32
33
19
18
3. AM/PM INDICATOR
5. TEMPERATURE DISPLAY
8. YEAR DISPLAY
11. SAVE BUTTON
14. ALARM3 BUTTON
19. MONTH BUTTON
22. DST BUTTON
31. USB OUTPUT CHARGER
- 01 -
Contact our experts
support@raynic.com
Http://www.raynic.com
Chapter 2 INSTALL ATION
How to Install Clock on wall with mounting rackets
1 2
Nail the bracket to the wall
4 5
Hang up the clock through the hole
Stick a circular sticker
How to Install Clock with Support Brackets
Just follow these two steps to make your clock stand firmly:
Step 1: The top, bottom, left and right points of the bracket should be
pressed into the groove completely(see picture 1 below).
Please note: Be sure to press all four points into the groove.
Step 2: After the four points are pressed into the groove, then slide the
bracket up(see picture 2 below).
When you can hear the "Ka" sound, it means the installation is successful!
Otherwise, please reinstall.
Made in PRC
3
Stick a circular sticker
6
Finished hanging the clock
- 02 -
Version 1.1
