- Page 1 Installation Manual Angle-Alu balcony structure System: SPKIT-BAL-01...
-
Page 2: Table Of Contents
Installation Manual CONTENT I. Safety Precaution ............................3 II. Introduction ..............................3 III. Available Module size ..........................4 IV. Tool ................................4 V. Components ..............................5 VI. Installation Instruction ..........................6 5.1 Installation of U hanger ........................6 5.2 Triangle installation ...........................7 5.3 Module installation ..........................9 5.4 Install Modules on the balcony beam ..................10 5.5 Install base on the balcony ......................11 VII. -
Page 3: Safety Precaution
I. Safety Precaution Thank you for purchasing our solar mounting system products. Refer to this manual before installation, operation, maintenance, and inspection. Professional Requirement Only professionals can install as specified. Regulatory Compliance Comply with national/local building and environmental protection regulations. Follow industrial accident prevention and insurance union regulations. -
Page 4: Available Module Size
III. Available Module size Module width of 1000~1500mm (tilt angle:0°、15°、20°、25°、30°) Installation hole distance of 860/990/1200/1400mm (anyone of each for 1 module installation) IV. Tool inner hexagon spanner Power Tool & Sleeve / Batch Torque wrench & sleeve / batch String Band tape String... -
Page 5: Components
V.Components Main component list Triangle set Triangle part hexM8*25 set hexM8*25 set Triangle set U hanger Base... -
Page 6: Installation Instruction
VI. Installation Instruction 5.1 Installation of U hanger Open the pre-assemble triangle, with 2 sets of hex bolts of M8*25 fixt the u hanger on the bottom line of triangle. Dont use it Refer torque 10-12N*M Note： Triangle fixture hole should be right in position, or we are in the wrong process Finish photo... -
Page 7: Triangle Installation
5.2 Triangle installation Choose the right pre-drill hole for different request of the tilt angle following, and fix with the triangle part, fix with M8*25. Fasten refer torque:10-12N*M 30° 0° 用 25° 20° 15°... - Page 8 2. 0°no need 30°finished photo 0°(no triangle part)
-
Page 9: Module Installation
5.3 Module installation Use 4sets of M8*25 bolt set（each including 1 bolt,2 flat washer,1 spring washer,1 nut）， fix the module on the triangle, refer torque value 提示： 固定孔位根据实际 组件确定。 Finish photo... -
Page 10: Install Modules On The Balcony Beam
5.4 Install Modules on the balcony beam After above steps finished, place the U hanger on the balcony and fasten with its bolt Refer torque value:2-4N*M Finish photo... -
Page 11: Install Base On The Balcony
5.5 Install base on the balcony Fix the base on triangle bottom line, with refer torque value of 10-12N*M (M8*25 bolt). After base fixture finished, fasten Al-plate，balcony pole and base together with the M8&55 bolt sets,refer torque value 2-4N*M. Side view Base Alu-plate Triangle... -
Page 12: Finished View
VII. Finished view Front view Back view... -
Page 13: Notice
VIII. Notice 6.1 Dimension The specific dimensions of engineering installation shall be subject to the engineering construction drawings. This installation manual is only for the instruction of product installation method. 6.2. Fastener Because of the good ductility for stainless steel, fasteners have big difference with carbon steel one in nature.
