HYN100+
LTE Cat.1&GSM GPS tracker
HUIYE HYN100+ is an LTE Cat.1 & GSM GPS tracker with a high-precision positioning tracking feature, designed
for location-based services such as Fleet Management, vehicle rental, vehicle tracking, and logistics monitoring
applications, etc.
HYN100+ has multiple I/O interfaces that can be used for monitoring or controlling external devices, which
achieve driving behavior monitoring, crash detection, jamming detection, motion detection, ignition detection,
special alarms based on digital inputs, and other features.
Driving Behavior
Monitoring
Aggressive driving behavior
detection, e.g. harsh acceleration,
cornering, and braking.
Motion
Detection
Motion alarm based on internal
accelerometer
Application
Vehicle Tracking
Special
Alarm
Tow Alarm, Speeding Alarm,
Idling Alarm. Special alarm
based on the digital inputs.
Ignition
Detection
Alerts for engine is switched on or
off
Vehicle Rental
With HUIYE, Connect to a Smarter Future
Accident data collection for
reconstruction and analysis
Alarm based on jamming
Fleet Management
www.huiye.com
Crash
Detection
Jamming
Detection
detection
Logistics
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYN100+ and is the answer not in the manual?

Questions and answers

Related Manuals for HUIYE HYN100+

Summary of Contents for HUIYE HYN100+

  • Page 1 With HUIYE, Connect to a Smarter Future HYN100+ LTE Cat.1&GSM GPS tracker HUIYE HYN100+ is an LTE Cat.1 & GSM GPS tracker with a high-precision positioning tracking feature, designed for location-based services such as Fleet Management, vehicle rental, vehicle tracking, and logistics monitoring applications, etc.

  • Page 2: Table Of Contents

    With HUIYE, Connect to a Smarter Future CONTENT Web: www.huiye.com E-mail: marketing@huiye.com Product Information ......................... 3 Know your device ..........................4 PIN out ............................4 Wiring scheme ..........................4 Set up your device ........................... 6 PC connection (Windows) ....................... 6 How to install USB Driver (Windows) ....................

  • Page 3: Product Information

    With HUIYE, Connect to a Smarter Future Product Information Model name HYN100+ GNSS Specifications GNSS BDS, GPS, GLONASS, Galileo, QZSS Tracking sensitivity -165 dBm Position accuracy(CEP) < 2m CEP Velocity accuracy 0.1m/s Cold starts 26s Hot starts 1s TTFF (Time To First Fix ）...

  • Page 4: Know Your Device

    With HUIYE, Connect to a Smarter Future Know your device MICRO SIM GNSS LIGHT NETWORK LIGHT (RED) (GREEN) BATTERY BATTERY TYPE-C SWITCH PIN out DESCRIPTION Blue | 1_PWR The power supply pins (3.3 V- 4.2V) of the external device are connected to GND.
  • Page 5 With HUIYE, Connect to a Smarter Future (Grey) is Analog Input / Digital Input port. Connect the oil circuit sensor or use the button Black Grey Button , only one of the two methods can be chosen. Grey power...

  • Page 6: Set Up Your Device

    With HUIYE, Connect to a Smarter Future Set up your device Open the back cover along the side seams to install the SIM card. Side seams Open the SIM card slot cover Toggle open the SIM card slot cover according to the direction indicated by the arrow, install the SIM card, close the card slot cover tightly according to the direction indicated, then turn the power switch to the ON position, close the back cover and fasten it, and you can hear the clicking sound after fastening.

  • Page 7: Configuration

    With HUIYE, Connect to a Smarter Future Configuration HYN100+ After connecting the PC with the TYPE-C serial cable, the shortcut key “win + x” enters the menu and selects Device Manager (M). Check for a “USB-SERIAL CH340” port in the Device Manager Ports menu.

  • Page 8: Safety Information

    With HUIYE, Connect to a Smarter Future etc., additional isolation should be applied. •Wires cannot be connected to the board computers or control units. CONNECTING POWER SOURCE •Be sure that after the car computer falls asleep, power is still available on chosen wire. Depending on car, this may happen in5 to 30 minutes period.

  • Page 9: Warranty

    •Warranty is not applicable for supplementary product equipment (i. e. PSU, power cables, antennas) unless the accessory is defective on arrival. * Developing Copyright © 2024, Huiye IoT Technology Co., Ltd. V.202504 Specifications and information given in this document are subject to change by HUIYE without prior notice.
  • Page 10 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
