Smart Comfort BELLA LOUNGE 2463 Assembly Instructions

ASSEMBLY INSTRUCTIONS
BELLA LOUNGE
Bella Immersive Audio Lounge
The components are heavy, assembly should be performed by two people.
If you have any di culty with assembly or operation, please contact the store of purchase in the fi rst instance.
Please read the below safety & electrical instructions before operating
Safety Instructions
• This product is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the product by a person responsible
for their safety.
• Ensure there is no person, animal or item obstructing the area under
the footrest before operating this product.
• Improper use or installation may result in the risk of fi re, electric shock
and/or injury. We assume no liability for any eventual damages caused
by improper use or inappropriate handling, or by any other non-com-
pliance with the instructions in this manual.
• Children should be supervised to ensure that they do not play with
the product.
• This product contains moving parts. Keep fi ngers, hair and body
parts well clear from moving parts. To reduce the risk of injury, keep
Children and pets clear of the product when in use.
Electrical Instructions
• Never force the back or footrest to close faster than the electric motor.
• Before commencing cleaning or maintenance, ensure this product is
disconnected from the power outlet and the back is in the full upright
position.
• Disconnect this product from the power outlet before moving.
• Cease operation and disconnect from the power outlet if you ever
detect a burning odour or smoke coming from the product.
• Do not operate this product if liquid spillage occurs on or around it.
Disconnect from the power outlet and allow product to completely dry
before reconnecting.
• Do not operate the power functions or charge station with wet hands.
• Check the condition of the power cord, electrical cords, transformer,
plug and connector on a monthly basis. Do not operate if wear is
visible on any components.
Synargy is a registered responsible supplier on EESS. Electrical components within our products have been tested to comply with legal
requirements imposed for electrical safety and EMC.
2463
• Do not sit or place additional weight on the arms, back or open
footrest.
• This product is very heavy. Only move this product by lifting the main
body. Never drag by the footrest, back or arm rest.
• Return this product to the full upright position to stand safely and
prevent a tripping hazard.
• Do not operate this product if damage is visible in any form.
• Do not modify or use unauthorised substitute parts.
• This product has been designed and intended for indoor residential
use only. It is not suitable for commercial or outdoor use.
• This product is not intended to be used as part of a health care plan.
Consult your medical professional before operating if you are taking
medication or have physical limitations.
• Ensure the power cord, electrical cords and transformer are clear of
moving parts and not trapped underneath the base.
• Position the power cord to minimise a tripping hazard.
• Never attempt to open or disassemble electrical components.
• We recommend the use of a surge protector (not included).
• Connect power supplies directly to a wall outlet wherever possible. If
a powerboard is required, check its maximum power load and don't
exceed. Never "daisy-chain" more than one powerboard together.
• Make sure all plugs are connected before plugging the power supply
into a power outlet.
• The USB ports (where applicable) are designed with working voltage
of 5V, and can not be used to supply power for laptop computers
(neither PC or Mac). Plugging a laptop computer into the USB port
may end up damaging either the computer or the USB port due to
unmatched working voltage.
Chaise Lounge
(Chaise Section)
Wooden Feet
x5
Step 1
Underneath the chaise is a zipper pocket with the sofa's
support feet. Remove the package and retrieve the feet.
Attach the fi ve wooden feet to the pre-drilled holes
around the outer perimeter of the underside of the
chaise. Additionally, fasten the plastic support foot to
the pre-drilled hole nearer to the center of the chaise
underside. Hand tighten in a clock-wise direction, being
careful not to overtighten.
Chaise Lounge
(Two-seater Section)
Wooden Feet
x4
Step 2
Underneath the seat base is a zipper pocket with the
feet and power supply cables. Remove the package
and set aside for the following steps.
Attach the four wooden feet to the pre-drilled holes
around the outer perimeter of the underside of the seat
base. Additionally, fasten the one plastic support foot to
the pre-drilled hole nearer to the center. Hand tighten in
a clock-wise direction, being careful not to overtighten.
Plastic Foot
x1
Plastic Foot Power Supply
x1 x1
