Summary of Contents for Abode AINDH2002
- Page 1 Induction Electric Hob Instruction Manual Model number(s): AINDH2002 For Customer Services & Spare Parts please call 0345 209 7461 IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Positioning ………………………………………. Product Overview ………………………………………. Induction Introduction ………………………………………. Usage ………………………………………. 8-16 Cleaning & Maintenance ………………………………………. 17-18 Trouble shooting ………………………………………. 19-20 Error codes ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. Connections to the Mains ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. • Do not tamper with the appliance's interior. If necessary, call our customer helpline • Do not switch on the appliance if it is damaged in any way. Contact our customer helpline •...
-
Page 5: Positioning
Safety Instructions • Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the customer services. • Components inside the appliance may have sharp edges. Wear protective gloves. • Saucepans may suddenly move due to liquid between the pan base and the hotplate. -
Page 6: Product Overview
Product overview 1. Cooking zone 600W - 1800W 200W - 1000W 2. Cooking controls 3. Display Unit & Spare Parts If any of the above parts are missing please contact the customer service team on 0345 209 7461. -
Page 7: Induction Introduction
Induction introduction Induction hobs only heat the pan rather than the cooking surface heating up like a standard electric hob. They do this by creating a magnetic field between the pan base and an element underneath the glass top; this makes induction hobs safer and cheaper to run as they use only the precise amount of energy you need. -
Page 8: Usage
Usage Controls The appliance has 2 cooking zones and these are controlled by the touch controls at the bottom of the hob. Each hob has a set of controls and these are directly below the cooking zone: The function of each touch control and the meaning of each icon is explained below: Cooking zone display The display shows the power, temperature, time, hot surface... -
Page 9: Using The Touch Controls
Usage Power on/off Press and hold for at least 2 seconds to turn the unit on and press to turn the unit off. Using the touch controls The controls respond to touch, so you don’t need to apply pressure to them. Below are tips on how to use the controls: •... - Page 10 Usage Wattages & Temperatures The settings below are guidelines only, the exact setting you will require will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction hob to find the settings that best suit you. Heat setting Suitability Power...
- Page 11 Usage To use the cooking zone Note: • When you touch a symbol, the respective function is activated. • Always keep the controls dry. Moisture reduces their effectiveness. • Do not pull pans close to the displays and sensors. The electronics could overheat.
- Page 12 Usage indicator light will light up above the word Temp. 5. You can modify the power or temperature setting of the cooking zone at any time during cooking. To do this touch the buttons. The power range and temperature ranges are shown in the below table: Zone 1 (1800W) Zone 2 (1000W) Temperature...
-
Page 13: Locking The Controls
Usage Locking the controls You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). To lock Press and hold the controls at the same time for at least 3 seconds to activate lock function, ‘Loc’ will be shown on the display and will be shown every few seconds (the power or temperature will also be shown). - Page 14 Usage 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and flick between this and the power/temperature every 10 or so seconds. 6. When cooking timer expires, the cooking zone will switch off automatically.
- Page 15 Usage Residual heat warning When the hob has been operated there will be some residual heat. The display of controls of which ever cooking zone has been used will show a ‘-H-’ symbol to warn you of the residual heat and to keep away from it. The ‘-H-’...
- Page 16 Usage Pans & energy saving The following advice is to prevent damage to pans and help you save energy: Zones Suitable pan sizes (diameter) 1800W (max) 200mm 1000W (max) 200mm Do not use small pans on large Always use pans that are the zones right size for each zone Do not cook without a lid or...
-
Page 17: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Follow all instructions and warnings included with the cleaning agents. How to clean Observe the information in the table below to ensure that the surface is not damaged by using the wrong type of cleaning agent. -
Page 18: How To Clean
Cleaning and Maintenance: How to clean: • After each use, clean the surface of each zone once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, it will become stuck to the surface and more difficult to remove later. •... -
Page 19: Trouble Shooting
Trouble Shooting: Problem Solution The plug is not plugged in Connect the appliance to the electricity supply Power cut or faulty fuse No power Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The child lock/control lock is operational Controls aren’t... -
Page 20: Error Codes
Trouble Shooting: Problem Solution Sliding or dragging pans may scratch the glass Always lift pans off the hob Rough pot and pan bases scratch the ceramic Scratches, Replace cookware discolouration or Spillages can cause discolouration blistering Remove/clean all spillages immediately Sugar can cause the surface to blister Remove/clean all spillages immediately Cookware can become deformed if boiled dry... -
Page 21: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact customer services with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Customer Services. -
Page 22: Technical Specification
Technical Specification Model number AINDH2002 Rated Voltage 220V – 240V ~ 50Hz/60Hz Wattage (W) 2800W (1800W & 1000W) External Dimensions (H x W x D) (CMS) 6.8cm x 60cm x 36cm... -
Page 23: Connections To The Mains
Connections to the mains This appliance is designed to operate from a mains supply of 220-240V~50/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. How to change the fuse 1. Slot the end of a screwdriver into the recess in the fuse holder of the plug. - Page 24 Imported by: Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD. For Customer Services & Spare Parts please call 0345 209 7461 The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
