Summary of Contents for Cubro NARROW 1845
- Page 1 USER GUIDE SUPER STROLLER NARROW® WALKING FRAME Code: 1845 127kg sales@cubro.co.nz 0800 656 527 cubro.co.nz...
-
Page 2: Table Of Contents
Failure to heed this warning may result in damage to the product or serious injury to the operator/user. CAUTION! Beware of pinch points. ATTENTION! Read and understand the instructions in the user guide before using the product. 0800 656 527 sales@cubro.co.nz www.cubro.co.nz... -
Page 3: Safety Warnings
• Note that a shift of balance due to body movements may increase the risk of the walking frame tipping over. Always make sure the load on the walking frame is even • Surface temperatures of the walking frame can increase/decrease when exposed to external sources of heat (e.g. sunlight, outdoor environment) 0800 656 527 sales@cubro.co.nz www.cubro.co.nz... -
Page 4: Product Specifications & Labels
Width between handles 405mm • Model name and number Seat height 460mm • Refer to instructions for use Seat size 300mm x 300mm Super Stroller Narrow 1845 Indoor 127kg 500mm Overall width 500mm use only Inside width 370mm • Indoor use only... -
Page 5: Instructions For Use
Insert backrest into frame until the snap buttons engage. Ensure backrest is securely fastened HOW TO FOLD Lift the seat (1), remove the basket (2) and pull on the nylon rope (3) to fold the frame (4). 0800 656 527 sales@cubro.co.nz www.cubro.co.nz... -
Page 6: Handle Adjustment
4. Insert the bolt through the frame, handle and plastic washer (3) 5. Ensure before tightening that the hexagonal bolt head is into the hexagonal hole in the frame 6. Tighten knob so handles are firm 0800 656 527 sales@cubro.co.nz www.cubro.co.nz... -
Page 7: Brake Tension Adjustment
MAINTENANCE • Ensure that every part of the walking frame is secure at all times • Check all screws for tightness. If not, tighten if necessary • Replace any broken, damaged of worn items immediately 0800 656 527 sales@cubro.co.nz www.cubro.co.nz... -
Page 8: Maintenance Schedule
Cubro Service For additional copies of this user Department: guide or for a different format, please contact Cubro®. 0800 656 527 +64 7 578 7228 sales@cubro.co.nz 149 Taurikura Drive, Tauriko, Tauranga, New Zealand 0800 656 527 sales@cubro.co.nz... -
Page 9: Limited Warranty
USER GUIDE 8. LIMITED WARRANTY Cubro Ltd warrants the product to be free from defects in materials and workmanship from the date of purchase for a period of 1 year (12 months). Please refer to cubro.co.nz for terms and conditions. - Page 10 Super Stroller Narrow® Walking Frame USER GUIDE 0800 656 527 sales@cubro.co.nz www.cubro.co.nz...
- Page 11 Super Stroller Narrow® Walking Frame USER GUIDE 0800 656 527 sales@cubro.co.nz www.cubro.co.nz...
- Page 12 WARNING: The doing of any unauthorised act in relation to a copyright work may result in both a civil claim for damages and criminal prosecution. 17/03/23 Get in touch & connect Email sales@cubro.co.nz • Call us 0800 656 527 • Visit cubro.co.nz...
