Neher ER 2/20 Installation Manual

Installation Manual
Motorized Roller Screen ER 2/20
Please follow these instructions by all means!
For your safeness
• Assembly and electrical installation may only be carried out by qualified personell.
• There are live parts inside of the roller screen box. Therefore make sure that the power supply has been interrupted before opening the

roller screen box (switching off the appropriate fuse etc.)
�
• The connection of the motor may only run in voltage-free condition.
• Make sure that the area beneath the window/door can not be entered during the installation (if necessary, shut off).
• When working under raised parts or working equipment, they must be secured against falling by suitable equipment.
• The insect screen is not qualified as a fall protection.
General information
• Roller screens with radio-controlled motors may not be operated in areas with increased risk of interference (hospitals, airports).

• The product may not be subjected to modifications, additions or alterations.
• Check the parts on proper condition before assembly. Damaged, incomplete or obviously defective parts may not be installed.
• Operation devices like interlocked push buttons or remotes must be installed at a maximum height of 1.3m.
Please read this manual carefully as we do not assume liability for defects resulting from incorrect assembling.
Use only stainless steel screws for mounting.
accessory
mounting material
is only included if
ordered with
mounting holes!
RK 4,2 x 25
15 03 42.25.TX
1
2
4
similar image
NEHER insect screen systems 11/2021
Technical changes reserved
with standard guide rails
small
ratchet
(e.g
2x
Wera)
Torx- deep-hole
bit set
marker
17 03 60
total view
3
2
1. roller screen box
2. lateral guide rails
3. cover profile
4. mesh with sliding bar
stream via QR-Code or
download it from the
recommended tools
TX10
TX15
TX20
tape
screw-
measure
driver Messfix
17 03 40
Fixture with mounting plates
Suitable for mounting on uneven ground. The mounting plates can either be
fixed to the wall or ceilling.
Self-supporting assembly
The roller screen box connected with the guide rails is self-supporting up to a
width of 2000mm and must not additionally screwed.
Please start the assembly film for the assembly of
the additional stop 14 44 30 via QR code
Video guide:
NEHER-App
PE-sealing
tape cordless
12 25 08.02 screw driver
possible assembly modes
width 12 mm mind. 12 mm
mind. 12 mm
additional stop for sliding bar
ER2_20_mont

�

countersink 9,8mm
HSS alu drill
4,5 mm
3,5 mm
masonry drill
level
6 mm
1/7
