MENEGOTTI TECHNICAL MANUAL

CONCRETE SAW

MCP-350 | MCP-450

QR-Code:

Point your cell phone or tablet camera

to access the updated version of

Technical

Catalogs online, or click the link below

to access the website.

www.mgtamerica.com

Attention:

Before operate Menegotti equipament, read this

Technical Manual, itself will inform and instruct the

operator about the operation.

By the way, you avoid possible working accidents and early

maintenance on at the equipment.

Manuals and Parts

Note: Cu�ng disc is not included.

Table of Contents

Need help?

Do you have a question about the MCP-350 and is the answer not in the manual?

Questions and answers

Summary of Contents for MENEGOTTI MCP-350

Page 1 Attention: Note: Cu�ng disc is not included. Before operate Menegotti equipament, read this Technical Manual, itself will inform and instruct the operator about the operation. By the way, you avoid possible working accidents and early...
Page 2 Welcome, you are part of the huge Menego� “customers family”. A�er sales Departament and Technical Assistance MENEGOTTI. A�en�on: For be�er comodity, store and keep this manual in a properly spot so it can be easily checked.
Page 3 Menego� Group Menego� is reference in the development of solu�ons in machines and tools for the Construc�on machinery, Handling and Lawn | Garden Segments. A Brazilian company, present in more than 40 countries, has its headquarters in Jaraguá do Sul, Santa Catarina, units in Brazil and in the United States.
Page 4 * ALWAYS use cau�on and common sense when opera�ng the equipment. * ALWAYS in case of damaged or missing parts, immediately contact MENEGOTTI by phone at 770 910 7450 for replacement of same; * ALWAYS with the machine turned oﬀ, make a daily inspec�on of the parts of the equipment. In case of problems, immediately contact the Menego�...
Page 5 * NEVER use the machine indoors (without ven�la�on). Engine exhaust gases contain carbon monoxide; exposure to carbon monoxide can cause loss of consciousness and may lead to death; * NEVER ingest fuel or inhale its vapors, and avoid skin contact. In case of skin contact, wash the aﬀected surface immediately. If fuel comes into contact with operator's eyes, ﬂush immediately with water and seek medical a�en�on as soon as possible.
Page 6 Operator safety with the cu�ng disc: * ALWAYS use cu�ng discs made of steel on the Concrete Saw; * ALWAYS inspect the disc before using it. It must not have cracks, dents, or ﬂaws in the core and/or steel edge. The center of the chuck hole must remain intact, and �ght;...
Page 7: Specifications
Technical Speciﬁca�ons SPECIFICATIONS MCP 350 MCP 450 Engine Honda GX160 Menego� 200 Honda GX 270 Menego� 270 Honda GX390 Menego� 390 Power - HP Weight - Kg Maximum cu�ng depth - mm 300-350 350-450 Dimensions of the cu�ng disc (mm) Depth adjustment Manual Rota�on Manual...
Page 8: Receiving The Machine
Machine Opera�on The following informa�on shows you the procedures for using the equipment, from receiving it, to ini�al inspec�on and prepara�on, to instruc�ons on how to cut a surface. Failure to follow these instruc�ons may endanger the safety of the operator and even people working near the machine. Check out the step-by-step instruc�ons for using this equipment: Receiving the machine: Immediately a�er accep�ng delivery of your new equipment and before pu�ng it into service:...
Page 9 Star�ng the Engine 1. Open the fuel valve lever by moving the switch from the "OFF" to the "ON" posi�on, as shown in the following ﬁgures; 2. Set the engine stop switch from the "OFF" posi�on to the "ON" posi�on, as shown in the following ﬁgures;...
Page 10 3. Move the thro�le lever/rod to approximately 1/4 of its full travel (25% thro�le), as indicated in the following ﬁgure; ATTENTION: If it exceeds this value (25%), there is a risk that, when star�ng the engine, it has enough capacity to make the machine work without the operator being prepared to start opera�ons, a fact that can result in accidents or damage to the machine.
Page 11 5. Pull the star�ng rod/handle lightly to make the internal components ﬁt properly un�l it oﬀers a slight resistance to movement, as shown in the following ﬁgures; ATTENTION: This ﬁrst movement must be smooth for the correct ﬁ�ng of the components shown in the following ﬁgures. Once the rods open and ﬁt into the limi�ng walls, if the movement is abrupt and not con�nuous, the ﬁ�ng may not occur as it should, which compromises the internal walls of this system, and also decreases the useful life of the retractable starter rope.
Page 12: Turning Off The Engine
6. Pull the star�ng rod/handle con�nuously, quickly, and ﬁrmly to start the engine; ATTENTION: Both the pulling and returning movement of the retractable starter rod/handle must be ﬁrm and con�nuous, in order to avoid breakage of internal components. To perform the correct movement, just pull the rod to the posi�on that oﬀers a li�le resistance, which indicates the ideal ﬁt of the internal components, and from this point on, con�nue the movement in a con�nuous, fast and ﬁrm way, without sudden movements, the same is valid for returning the rod to the ini�al posi�on, that is, do not release the rod/handle while the rope is taut and out of the housing.
Page 13 Types of cu�ng: There are 2 types of cu�ng to be used with the Concrete Saw: wet and dry. The cu�ng speed to use depends en�rely on using the correct disc for the material being cut. Before star�ng: 1. Use the correct disc for the cu�ng condi�ons; 2.
Page 14: Belts And Pulleys
CAUTION: Pay a�en�on in situa�ons of cu�ng in terrain with great unevenness. Engine leaning at extreme angles can cause oil to enter the cylinder head, making the engine diﬃcult to start. Dry cut: * Never use any cu�er without safety guards in place; * Do not exceed the maximum speed established for the diameter of the disc;...
Page 15: Engine Pulley
Engine Face edge Engine pulley Disc sha� pulley...
Page 16: Transport And Storage
Transport and Storage Transport: 1. Always turn oﬀ the engine when transpor�ng the machine; 2. Make sure the li�ing device has suﬃcient capacity to support the machine (see nameplate on machine); 3. Use the li�ing point when li�ing the machine, as shown in the ﬁgures below. Also use suitable li�ing equipment to ensure safe movement of the cu�er; 4.
Page 17: Machine Maintenance
Machine Maintenance Maintenance with security: * NEVER lubricate components or a�empt repairs while the machine is running; * ALWAYS allow the machine an adequate amount of �me to cool down before servicing; * Repair the machine immediately and always replace the broken parts; * Dispose of hazardous waste properly.
Page 18 * During lubrica�on, ensure thorough cleaning; * To avoid the risk of accidents, use the correct tool for the job and keep tools clean; * Draining the engine oil is best done when the oil is not hot; * Any spilled oil must be cleaned up immediately; * Use only clean oil containers and only fresh, clean oils and grease of the correct grade;...
Page 19: Engine Maintenance Plan
- Engine maintenance plan: ITEM First month or Every 3 months Every 6 months Every year or In all opera�ons H - Honda Engine | M - Menego� Engine 20Hrs or 50Hrs or 100Hrs 300Hrs Check level H | M Engine oil Change H | M...
Page 20 Troubleshoo�ng PROBLEM CAUSE SOLUTION Pump the water system. *In wet cu�ng: Lack of water (usually on one side of the disc). Check the water ﬂow on both sides of the disc. IRREGULAR SEGMENT WEAR Equipment defects can also cause wear and tear. Replace bad bearings, worn chuck sha� or misaligned sha�. Check alignment by perpendicularity, both ver�cally and horizontally, on Misaligned saw head.
Page 21 PROBLEM CAUSE SOLUTION *In wet cu�ng: Check the water connec�on. Make sure the ﬂow is adequate on both sides of the disc and that there are no Cu�ng disc is overhea�ng due to lack of coolant obstruc�ons. (water or air). Use enough water to cool the cut.
Page 22 Follow-up of oil changes: Engine Oil Last Exchange Date Reduc�on Gear Oil Last Exchange Date...
Page 23: Product Warranty
This warranty replaces any other warranty, implicit or explicit, as well as all any Model: Serial Number: obliga�on or responsibility on the part of our company in rela�on to the above City: Date: men�oned product. MENEGOTTI Post Sales Department and Technical Assistance. Menegotti Authorized Service Customer...
Page 24 Solid values, sustainable future. Unit • Unidad Menmaq Unit • Unidad Mentec Unit • Unidad Menfer Unit • Unidad MNA United States...
