grün-pumpen p310 Instruction Manual

Instruction manual
motor p310 / p310-Mag / p310-A / p310-A-Mag /
p310-A-SR / p310-A-SR-Mag
General safety information
This device is not intended to be used by persons (including children) with limited physical,
sensory or mental capabilities, or lack of experience and / or knowledge, unless supervised or
provided by a person responsible for their safety her instructions on how to use the device.
Children should be prohibited from operating and playing with the device. The storage of the
device should be inaccessible to children.
Before all
Motor and pump tube are packed separately. Any accessories ordered may be in the same packaging.
Therefore search the packaging material carefully before dumping it.
1. Technical Data
motor type
power
nominal speed (at 50 Hz)
protection
approval
CE mark
weight
guarantee (not including wearing
parts e.g. carbon brush, cable ...)
ordering code for mains supply
230V/50 Hz
115V/50-60 Hz
remarks
2. Before operation please regard the following advices.
* Before inserting the plug into the power mains please make sure that cable, plug, housing and
socket are not damaged.
* Take care that the data regarding voltage and frequence mentioned on the motor are according
to voltage and frequence of your mains power network.
* Take care that motor and pump tube are linked tight together before operating the pump.
* Make sure that the pump is fixed tight during operation and that the hose is fixed tight to the pump
tube.
* Don't run the pump unattended.
* Don't run the pump dry.
* Make sure that the pump tube is chemically compatible to the transfered liquid.
grün-pumpen gmbh - Philipp-Reis-Straße 3 - D-63755 Alzenau - Tel.:+49 6023-9643-130 - Fax.: +49 6023-9643-139
1
for
p310 / p310-Mag
520 Watt
8500 rpm
splash-proof
VDE
yes
3,5 kg
6 month
if not other stated
500-0016 / 500-0030
500-0028 / 500-0032
motor protected by
thermal overload relais
including low voltage
release
email: info@gruen-pumpen.de - web: www.gruen-pumpen.de
p310-A / p310-A-Mag
520 Watt
8500 rpm
splash-proof
VDE
yes
3,5 kg
6 month
if not other stated
500-0017 / 500-0031
500-0029 / 500-0033
motor protected by
thermal overload relais
without low voltage release
p310-A-SR / p310-A-SR-Mag
520 Watt
8000 rpm
splash-proof
VDE
yes
3,5 kg
6 month
If not other stated
500-0054 / 500-0058
500-0057 / 500-0059
motor protected by thermal
overload relais without low
voltage release with speed
reducer
