LD-300-RS-SS
Powered Label Dispenser in Stainless Steel
•
High-Low Speed Select
•
Adjustable Label Sensor
•
Not for Transparent or Black Labels
Remove all parts from the shipping container and verify contents.
PACKAGE CONTENTS:
•
User Manual (this document)
•
Label Dispenser Unit
•
Power Supply Module
Retain the Shipping Container and Packaging for Storage and Transport.
VERY IMPORTANT:
•
Keep Label Sensor Eye clean. Wipe with a soft cloth occasionally. Be careful not to damage the sensor.
Do not use any chemical on the Sensor.
•
Keep Tape Stripper Bar and Web Guide Bars clean. Use isopropyl alcohol or "Goo-Gone"™ to clean
adhesive residue from parts. Adhesive build-up can cause malfunction and damage to your unit.
SPECIFICATIONS:
Weight of the machine: 6 Kg.
Max. Label Roll Weight: 6 Kg.
Max. Label Roll Size:
300 mm diameter
Max. Label Width:
218 mm diameter
Input: 220-240VAC – 50-60Hz.
Power Supply:
Output: 15VDC – 4.33A
Advertisement
Related Manuals for Labelmate LD-300-RS-SS
Summary of Contents for Labelmate LD-300-RS-SS
- Page 1 LD-300-RS-SS Powered Label Dispenser in Stainless Steel • High-Low Speed Select • Adjustable Label Sensor • Not for Transparent or Black Labels Remove all parts from the shipping container and verify contents. PACKAGE CONTENTS: • User Manual (this document) •...
- Page 2 SET-UP AND USE: Make sure the Power Switch is in the “OFF” position. Set your LD-300-RS-SS in place and plug the cord from the Power Supply Module into the Power Input Jack on the rear of the Unit. Connect the Power Supply Module to a suitable power source.
- Page 4 All Labelmate Products are warranted to the original end-user customer to be free from defects in materials and workmanship. If it is determined by Labelmate that a product has failed under the terms of this warranty, the product will be repaired or replaced at no charge to the customer.
