Summary of Contents for Maisvch ISM515-2D-2C
- Page 1 Embedded Ethernet Communication Module User Manual ISM515-2D-2C Version:2.2 Please read this user manual carefully before using this product...
- Page 2 All relevant trademarks mentioned in this user manual are separately owned by the relevant manufacturer. Instruction This user manual is available for the ISM515-2D-2C embedded Ethernet communication module. Before using this manual, please read the following license carefully. The products described in this manual are available only under the following license agreement.
- Page 3 Notice of safe use This product has good and reliable performance within the designed range of use, but it is necessary to avoid human damage or destruction to the equipment. Read this manual carefully and keep it for future reference; ...
-
Page 4: Table Of Contents
Performance characteristics ....................... 1 Hardware Description ......................... 3 Definition and description of the pins ....................3 2.1.1 ISM515-2D-2C Embedded module pin diagram (top view) ..............3 2.1.2 ISM515-2D-2C Pin definition list of embedded modules ..............3 2.1.3 ISM515-2D-2C Pin Detail Description ....................5... -
Page 5: Product Overview
▪Powerful function As an embedded industrial Ethernet switch module in the field of high-performance industrial communications, ISM515-2D-2C is also compatible with RS232/485 and CAN bus communications in industrial sites. It also provides advanced network management functions, including: MW-Ring, Quality of Service, rate control, port mirroring, static MAC address forwarding table functions, etc., to meet the diverse needs of users. - Page 6 5S and releasing it) ▪ Low power consumption design The embedded module of the ISM515-2D-2C 100 Mbit industrial Ethernet switch adopts a low-power design scheme with a typical power consumption of less than 1W(only the module...
-
Page 7: Hardware Description
Hardware Description Definition and description of the pins 2.1.1 ISM515-2D-2C Embedded module pin diagram (top view) 2.1.2 ISM515-2D-2C Pin definition list of embedded modules... - Page 8 Table 2-1 ISM515-2D-2C Pin definition list of embedded modules coupler A pin name pin name pin name pin name RXN4 RXP4 TXP1 TXN1 TXN4 TXP4 RXP1 RXN1 TXP5 TXN5 RXN2 RXP2 RXP5 RXN5 TXN2 TXP2 VIN_3V3 VIN_3V3 VIN_3V3 TXP3...
-
Page 9: Ism515-2D-2C Pin Detail Description
CONFIG1 CONFIG5 2.1.3 ISM515-2D-2C Pin Detail Description Table 2-2 ISM515-2D-2C Pin Detail Description pin name pin number Type Function description Ethernet interface: Positive terminal for receiving signal. 1.When port configured 10BASE-T/100BASE-TX mode RXP[1:5] is directly connected to the RXP1 receiving end of the network transformer. - Page 10 Type Function description 100BASE-FX mode, TXP[1:5] connected to pin 8 TD+ of the optical module through the coupling capacitor. 3.These pins can become input pins in adaptive MDI/MDIX mode. 4.To save power, all unused TXP pin ...
- Page 11 Type Function description CONFIG4 2.When CONFIG is connected to +3.3V through a 4.7K resistor, ports 1-5 are CONFIG5 configured as 100M optical ports. 3.When this pin is not in use, it is recommended to connect it to ground.
- Page 12 Type Function description The module restores the factory setting pin, which is active at low level. RELOAD input When the pin input low level lasts longer than 5S, the module enters the factory reset state after detecting the high level.
-
Page 13: Ethernet Interface Description And Reference Circuit
Attention 1. The internal status of the RESERVE and NC pins has been determined, and there is no need to add an external pull-down circuit, otherwise it may cause the core board to work abnormally. 2. For function pins not used by customers, without special instructions, there is no need to ... -
Page 14: 100Base-Tx Reference Circuit
Configuration Method 3. When the pin outputs high and low alternating levels, it indicates that corresponding port has data transmission. 100M Ethernet port speed indicator pin. 1. When the port is configured as... -
Page 15: Other Interface Descriptions
Figure 2-2 100BASE-FX reference circuit Attention: The resistance parameter value on the right side of the 0.1uF capacitor in the figure is only suitable for 3.3V optical modules. If you use a 5V optical module (marked with a dotted line in the figure), you need to refer to the manufacturer's circuit of the optical module. -
Page 16: Can Interface Descriptions
Function description serial port 1 is used for RS485 communication, it is used as the transceiver enable control pin. output The default output is low level in the receiving UART1_RTS state, and the output is high level when sending data. -
Page 17: Indicator Description
Type Function description (Usually high level, low level when there is an ALARM_IN2 alarm signal) Alarm signal output indication, alarm level can ALARM_OUT1 output be configured Alarm output indicator light, low level Table ALARM_OUT2 output indicates alarm 2.3.4 Indicator description... -
Page 18: Power Interface Description
Type Function description active at low level. When the low level duration of the pininput is greater than 5S, after detecting the high level, the module enters the factory reset state. 2.3.7 Power interface description... -
Page 19: Dimensions
Dimensions Dimension Unit: mm... -
Page 20: Performance And Specification
Performance and Specification Specification ISM515-2D-2C switching performance Backplane bandwidth cache size 64KB MAC address table interface 5 channels of 100Base-FX or 10/100Base-T(X), photoelectric 100M port optional Serial port quantity: 2 RS232/485 Baud rate: 600~460800 (bps) serial port Data bits:7,8... - Page 21 ISM515-2D-2C Working environment Operating temperature -40℃~+85℃ Storage temperature -40℃~+85℃ Relative humidity 5%~95%RH (No condensation)
-
Page 22: Repairs And Service
For product repair, replacement or return, please follow Maisvch's procedures. You should first confirm with the technical staff of Maisvch, and then negotiate with the sales staff of Maisvch , to complete the repair, replacement or return of the product. - Page 23 Contact Us WUHAN MAISVCH TECHNOLOGY CO.,LTD Address: No. 079, Room 501, Chuangxinghui Free Trade Finance Building, No.777 Optical Valley 3rd Road, East Lake High-tech Development Zone, Wuhan, Hubei, China. Mail: sales@maisvch.com Official site: www.maisvch.com Copyright © Maisvch Communication All rights reserved...
