- Page 1 OPERATING MANUAL ENVIROsense ETS series Environmental transmitters V1.1...
-
Page 2: Table Of Contents
ENVIROsense ETS series – Environmental transmitters V1.0 Contents Introduction ..................... 3 Technical specifications ................4 Installation ....................6 3.1 Electrical connections ................6 Configuration .................... 8 ASCII proprietary protocol ............... 9 Modbus-RTU protocol ................14 Maintenance ................... 18 Safety instructions ................. 18 Accessories ordering codes .............. -
Page 3: Introduction
ENVIROsense ETS series – Environmental transmitters V1.0 Introduction ENVIROsense is an environmental temperature, relative humidity and, optionally, bar- ometric pressure transmitter with RS485 Modbus-RTU output. Two optional additional 0…1 V, 0…5 V or 0…10 V (depending on model) analog outputs for temperature and relative humidity or dew point, with configurable temperature and humidity ranges. -
Page 4: Technical Specifications
ENVIROsense ETS series – Environmental transmitters V1.0 2 Technical specifications Sensor RH Capacitive Temperature Pt100 Pressure Piezoresistive Measuring range RH 0…100% Temperature -40…+80 °C Pressure 300…1100 hPa Resolution RH 0.01% Temperature 0.01 °C Pressure 0.1 hPa Accuracy RH ETS60…: ±1.8% (0…85%) / 2.5% (85…100%) @ T=15…35 °C (2 + 1.5% of measured value)% @ T= remaining range... - Page 5 ENVIROsense ETS series – Environmental transmitters V1.0 Dimensions (mm) Page 5 of 24...
-
Page 6: Installation
ENVIROsense ETS series – Environmental transmitters V1.0 3 Installation For outdoor installation, use the HD9007A-1 or HD9007A-2 bracket with protection against solar radiations, suitable for fixing to a Ø30…50 mm mast. The support requires the HD9007T26.2 adapter from Ø26 to Ø14 mm. - Page 7 ENVIROsense ETS series – Environmental transmitters V1.0 ETSxxMW… / ETSxxMX… / ETSxxMY… CPM12-8… Function wire color Power supply negative (GND) White Transmitter male Power supply positive (+Vdc) Brown connector Digital ground (DGND) Green RS485 Data - Yellow RS485 Data +...
-
Page 8: Configuration
ENVIROsense ETS series – Environmental transmitters V1.0 4 Configuration The configuration of the transmitter can be done: • By sending serial commands from a PC, via a standard communication program (see the chapter “ASCII proprietary protocol”). • Via the “Holding Registers” in Modbus-RTU mode (see the chapter “Modbus-RTU protocol”). -
Page 9: Ascii Proprietary Protocol
ENVIROsense ETS series – Environmental transmitters V1.0 5 ASCII proprietary protocol To communicate with the transmitter via the ASCII proprietary protocol: 1. Connect the transmitter to the PC and start a standard serial communication pro- gram. 2. In the serial communication program, set the Baud Rate 57600, the parameters 8N2 and the COM port number to which the transmitter is connected. -
Page 10: Units Of Measurement
ENVIROsense ETS series – Environmental transmitters V1.0 Enabling/disabling the wait for the @ command at power up: Command Reply Description WCTn WCT;&| Enable/disable the 10-second wait for the @ command at power up: ▪ Disabled if n=0 ▪ Enabled if n=1 Default : Enabled (n=1) RCT;n... - Page 11 ENVIROsense ETS series – Environmental transmitters V1.0 Measurements reading: Command Reply Description S0;meas| Prints the measurements in the following sequence: ▪ Temperature in °C ▪ Relative humidity in % ▪ Specific humidity in g/kg ▪ Absolute humidity in g/m ▪ Dew point in °C ▪...
- Page 12 ENVIROsense ETS series – Environmental transmitters V1.0 Command Reply Description CAAin CAAi;&| Sets the direct or reversed correspondence between ana- log output and humidity: If n=0: Min. output Min. RH or Td ▪ Max. output Max. RH or Td If n=1: Min.
- Page 13 ENVIROsense ETS series – Environmental transmitters V1.0 Relative humidity calibration: Command Reply Description CRHIn CRHI;&| Sets the type of calibration to be used: ▪ Factory calibration if n=0 (default) ▪ User calibration if n=1 RRHI RRHI;n| Reads the type of calibration in use.
-
Page 14: Modbus-Rtu Protocol
ENVIROsense ETS series – Environmental transmitters V1.0 6 Modbus-RTU protocol By default, the transmitter has Modbus address 1 and communication parameters 19200, 8E1. The address and the communication parameters can be changed by using the appropriate serial commands of the proprietary protocol or, alternatively, directly with Modbus commands by changing the value of the Holding Registers described later. - Page 15 ENVIROsense ETS series – Environmental transmitters V1.0 Address Description Format Specific humidity 16-bit Integer Barometric pressure 16-bit Integer Frost point temperature 16-bit Integer Saturation vapour pressure above water 16-bit Integer Saturation vapour pressure above ice 16-bit Integer TRANSMITTER GENERAL INFORMATION 100…109...
- Page 16 ENVIROsense ETS series – Environmental transmitters V1.0 Indirizzo Descrizione Formato Modbus-RTU address (1…247, default=1). 16-bit Integer Temperature unit of measurement: 16-bit Integer 0=°C (default) 1=°F Type of calibration to be used: 16-bit Integer 0=Factory calibration (default) 1=User calibration Calibrates the RH point Nr. 0 to the value entered in the regis- 16-bit Integer ter, in hundredths of %RH.
- Page 17 ENVIROsense ETS series – Environmental transmitters V1.0 Indirizzo Descrizione Formato Calibrates the RH point Nr. 4 to the value entered in the regis- 16-bit Integer ter, in hundredths of %RH. The value must be in the range 8000…9500 (=80.00…95.00%). Value, in hundredths of %RH, measured before calibration of 16-bit Integer point Nr.
-
Page 18: Maintenance
ENVIROsense ETS series – Environmental transmitters V1.0 7 Maintenance In order to grant measurements high accuracy, it is necessary to clean the filter peri- odically. To clean the filter, unscrew it from the transmitter body and wash it under running water with the help of a brush. -
Page 19: Accessories Ordering Codes
ENVIROsense ETS series – Environmental transmitters V1.0 9 Accessories ordering codes The transmitter is supplied with M12 female free connector (only if the optional cable is not ordered). The cable and the protection shield from solar radiations must be ordered separately. - Page 20 ENVIROsense ETS series – Environmental transmitters V1.0 OTES Page 20 of 24...
- Page 21 ENVIROsense ETS series – Environmental transmitters V1.0 OTES Page 21 of 24...
- Page 22 ENVIROsense ETS series – Environmental transmitters V1.0 OTES Page 22 of 24...
- Page 23 WARRANTY The manufacturer is required to respond to the "factory warranty" only in those cases provided by Legislative Decree 6 September 2005 - n. 206. Each instrument is sold after rigorous inspections; if any manufacturing defect is found, it is necessary to contact the distributor where the instrument was purchased from.
- Page 24 Senseca Italy S.r.l. Via Marconi, 5 35050 Selvazzano Dentro (PD) ITALY info@senseca.com...
