EXALUS TR7
Spółka z ograniczoną odpowiedzialnością
Kuchary 24F
63-322 Gołuchów
www.exalus.pl
Technical data :
Power Supply:
Rated power:
Operating temperature:
Length of the motor cable:
Number of wires in a cable:
Transmission:
The User Manual is valid for SSR-BIDI motors with 4.2.0 software and later updates (from 01.03.2025)
The motors operate
at 868 MHz
230V 50Hz
40/10 - 144 W
60/10 - 113 W
60/20 - 161 W
from -10 to +50°C
2 m
5
<25 mW
MOTOR USER MANUAL
SSR-BIDI
Advertisement
Summary of Contents for EXALUS HOME SSR-BIDI
- Page 1 60/20 - 161 W Operating temperature: from -10 to +50°C Length of the motor cable: Number of wires in a cable: Transmission: <25 mW The User Manual is valid for SSR-BIDI motors with 4.2.0 software and later updates (from 01.03.2025)
- Page 2 NOTE: The radio receiver, in-built in the motor, allows for direct cooperation with PX- BIDI, NX-BIDI, PXZF-BIDI, NXZF-BIDI, NX-BIDI PRO remote controls and the TR7 control unit. 1. Connection scheme: - Connection scheme of the radio controlled motor with a switch Motor 1 = PE - Protective Earth) wire ( yellow-green...
- Page 3 THE FIRST LAUNCH AND ADDING REMOTE CONTROLS: NOTE: The SSR-BIDI is a Plug&Play type of motor, thus, no manual set-up of end limit positions is required. The drive learns in the course of usual operation - after performing 3 full cycles, it will remember the end limit positions.
- Page 4 3. MANUAL SET-UP OF END LIMITS: Note: The recommended mode of operation of the drive is the mode, in which the motor learns the end limit positions. If, for technical reasons (no window sill, no caps in the bottom slat), it is not possible to automatically calibrate the drive, the end limit positions can be manually set up.
- Page 5 4. RESET OF SETTINGS: 1. Supply voltage to the motor (confirmed with a short UP/DOWN movement). 2. Press the P2 button (confirmed with a short UP/DOWN movement). 3. Press the UP button (confirmed with 2 short UP/DOWN movements), the motor gets completely reset and all assigned remote controls are listed.
- Page 6 8. HALFWAY POSITION: 1. Set the roller shutter in the halfway position. 2. Press and hold the STOP button for 5 seconds (confirmed with a short UP/DOWN movement) (the halfway position has been memorised) 3. To call up the halfway position, press the STOP button of the stopped roller shutter. 4.
- Page 7 10. ADDING MOTOR TO THE TR7 CONTROL UNIT: 1. After logging into the control unit, select “Channels” from the lower menu. 2. Press the "+” button in the right upper corner of the display screen. 3. Press the “Search” button. The control unit will start searching for motors and other devices which will be displayed on the list.
- Page 8 Change the position where the roller shutter stops at the top with UP/DOWN buttons: - for the SSR-BIDI-60 motor - range: from -50 to 50 (steps of 10) - for the SSR-BIDI-40 motor - range: from -50 to 50 (steps of 10) 3.
