1. Entering the walk-in bathtub:
The U-shape inward swing door handle is located on the inside of the tub, and
is designed for a safer entry with an added deck and a wall mounted grab bar.
Once you are in the tub, remain standing and close the door. While the
door may be closed from a sitting position, it is much more difficult.
Do not open the door unless the tub is completely drained!
Air and Hydro Therapy Massage Option with Ella 5
Piece Fast-Fill Faucet
Deck Mount
Cold Water
Grab Bar
Switch
LED
Chromatherapy
Light
4 Foot
Massage Jets
2" Dual Drain
Lower Air
Massage Jets
Upper Air
Massage Jets
Bidet Air
Massage Jets
Back Hydro
Massage Jets
2 Drain
Hot Water
Diverter
Openers
Switch
ellasbubbles.com
Ella Outward Swing Walk-In Bathtub
Operations Instructions
Hydro Therapy Massage Option with Ella 2 Piece
Spout
2 Drain Openers
Pull-Out
Adjustable
Hand Mixer
Hydro Jets
ON/OFF
Hydro Intensity
Control Dial
LED
Chromatherapy
Light ON/OFF
Foot Massage
Jets ON/OFF
Air Massage
ON/OFF
Foot Massage
Intensity Control
Dial
Grab Bar
Hip & Thigh
Hydro Massage
Jets
2 Calf & Leg
Hydro Massage Jets
Capri Model Shown Above
Fast-Fill Faucet
Deck Mount
Grab Bar
Chromatherapy
Hydro Massage Jets
LED
Light
4 Foot
Massage Jets
2" Dual Drain
2 Calf & Leg
Back Hydro
Massage Jets
Advertisement
Summary of Contents for Ella's OA3672
- Page 1 Ella Outward Swing Walk-In Bathtub Operations Instructions 1. Entering the walk-in bathtub: The U-shape inward swing door handle is located on the inside of the tub, and is designed for a safer entry with an added deck and a wall mounted grab bar. Once you are in the tub, remain standing and close the door.
- Page 2 Do not open the door unless the tub is completely drained! Hot/Cold Hand-Shower Lever 3A. Ella's 2 Piece Fast-Fill Faucet: To turn the water on, lift the lever. The temperature can be adjusted by turning the lever to the left for hot water, and to the right for cold water.
- Page 3 Ella Outward Swing Walk-In Bathtub Operations Instructions 4A. Push Controls Hydro Hydro Infusion Intensity Massage Chromatherapy Massage Microbubble Control Dial ON/OFF ON/OFF Button ON/OFF Therapy Button Button ON/OFF Button 4B. Digital Control Pad Hydro Massage Chromatherapy Massage ON/OFF Button ON/OFF Button 3 Speed Control 4C.
- Page 4 Ella Outward Swing Walk-In Bathtub Operations Instructions 5. Hydrotherapy System Push Control Option: Push ON/OFF control labeled "Water" to turn the hydro pump on. To turn it off, press it again. Digital Control Option: Push the digital ON/OFF control labeled with 3 water streams to turn Hydro Jets Shown the hydro pump on.
- Page 5 Ella Outward Swing Walk-In Bathtub Operations Instructions 6. Air Therapy System Auto-Purge Maintenance System: Air Massage is equipped with an auto-purge feature that automatically turns on 20 minutes after the pump has been turned on. It runs for 120 seconds to ensure your system is clear and free of excess water, moisture, or mildew.
