- Page 1 Fixed Dome Network Cameras Quick Guide V2.01...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! • Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
-
Page 3: Packing List
CAUTION! • The cable connector must not be exposed and must be kept away from water. • Restore and fasten the device after dismounting. • Place the power adapter in a power distribution box. Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. - Page 4 Do not overbend or drag cables during installation; otherwise, poor cable contact may cause malfunction. When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. ...
-
Page 5: Mount Your Camera
Interface Description • Audio input interface, inputs audio signals or starts two- way audio • AUDIO IN / Audio output interface, output audio signals AUDIO OUT Note: Audio input and two-way audio share the interface but cannot be used simultaneously. Serial port, connects external devices for communication, RS485 for example, to control third-party devices... - Page 6 (Optional) Insert Micro SD Card You need to install a Micro SD card first if you want to use the edge storage function. NOTE! For recommended SD card specifications, please contact your dealer or technical support. The figure below is for illustrative purpose only. The actual card slot position may vary. CAUTION! Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation;...
- Page 7 NOTE! • The reset operation works only within 10 minutes after the camera is connected to power. • To restore factory defaults, remove the cover to find the reset button (see the steps above), press and hold the reset button for at least 10 seconds and wait for the device to restart. Mount the Camera The camera supports ceiling mount, wall mount, and pendant mount.
- Page 8 3. Loose the 6 screws on the cover with the hex key or a Torx screwdriver, remove the cover. 4. Remove the protective foam inside the device and the protective film on the inside of the transparent dome cover. 5. Connect all cables. Hang the anti-drop cord on the buckle of the mounting plate.
- Page 9 Caution: • Do not pull hard when leading the tail cables; otherwise, the tail cables may be loose or disconnected. • The external cables can be led through the side of the base. Please remove the waterproof plug with a slotted screwdriver and install a waterproof connector (self-prepared). 6.
- Page 10 7. Adjust the shooting angle. Adjust the horizontal angle by holding the 2 screws at both ends of the light panel and moving the panel left or right to adjust the lens module. Adjust the vertical angle by adjusting the vertical bracket. Adjust the rotation direction by rotating the lens cover.
- Page 11 8. Reinstall the cover, and tighten the 6 screws on the cover with the hex key or a Torx screwdriver until they reach the limit. 9. Remove the protective films from the outside of the transparent dome cover and the illuminator ring. Note: There are 2 pieces of protective films on the illuminator ring.
- Page 12 2. Align the holes of the adapter plate (self-prepared) with those of the mounting plate, and secure them with four screws using the hex key or a Torx screwdriver. Note: The adapter plate with the FRONT logo should face the ground during installation. 3.
-
Page 13: Web Login
4. Mount the base and cover by referring to the steps 3 to 7 in Ceiling Mount. Startup Check that the device is properly installed, and then connect power to start up the device. Web Login Note: Default IP address: To ensure security, please change the password after your first login. - Page 14 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
- Page 15 pecuniary, coverage, exemplary, subsidiary losses, however caused and on any theory of liability, whether in contract, strict liability or tort (including negligence or otherwise) in any way out of the use of the product, even if our company has been advised of the possibility of such damages (other than as may be required by applicable law in cases involving personal injury, incidental or subsidiary damage).
- Page 16 Store or use the device in a proper environment that meets environmental requirements, including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. Make sure the device is securely installed or placed on a flat surface to prevent falling. ...
- Page 17 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
