miseno 69002424 User Manual

Medicine cabinet - single door with led lighted mirror
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

USER GUIDE
MEDICINE CABINET - SINGLE
DOOR WITH LED LIGHTED MIRROR
Model: 69002424

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 69002424 and is the answer not in the manual?

Questions and answers

Related Manuals for miseno 69002424

Summary of Contents for miseno 69002424

  • Page 1 USER GUIDE MEDICINE CABINET - SINGLE DOOR WITH LED LIGHTED MIRROR Model: 69002424...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Please read through this installation instruction so you will know how to install and operate your model properly. Keep this document in a safe place for future reference after use. WARNING This product must be installed in accordance with the installation instruction by qualified technician.

  • Page 3: Installation

    INSTALLATION For drywall installation, mark the hole locations and drill Φ 6mm holes for the drywall Insert provided drywall Install the mounting bracket. anchors. Install a junction anchors. box behind the mirror for power connections. Hardwire both cables to 110V AC if no Hang the medicine cabinet to Pull the cabinet slightly away wall switch is used.

  • Page 4: Installation Dimensions

    INSTALLATION DIMENSIONS 15.6 Cabinet Exterior Dimensions Cabinet Interior Dimensions Cabinet Door Dimensions Model # W x H x D W x H x D Diameter 69002424 15.6" x 15.1" x 4.4" 14.1" x 14" x 4" 24"...

  • Page 5: Basic Operation

    BASIC OPERATION Touch switch A small circle around the touch switch will light up when the main light is off. Tap on the switch to turn on/off the main light. The small circle will turn off when the main light is on. While the main light is on, press and hold the switch for about 3 seconds to change the color temperature.

  • Page 6: Care And Maintenance

    This warranty is valid to the original purchaser only and does not cover product damage due to installation error, product abuse, product misuse, etc. whether or not performed by professionals. Miseno will not be responsible for labor charges and/or damage incurred in installation, repair or replacement nor for any incidental or consequential damages.
  • Page 7 Exploded view Part Description Mirror Door LED Light Hinge Bracket Hinge AC & USB Outlets LED Driver Electrical Cover Mirrored Back Board Aluminum Frame Glass Shelf Touch Switch...
  • Page 8 rev1.9...
