Advanced ICE 1488 Installation Manual

Ford f-truck camera

Advertisement

Quick Links

Ford F-Truck Camera
Integration Installation Guide
1488
PLEASE READ BEFORE BEGINNING INSTALLATION
Installation Terms & Conditions
All labels on the product including software versions and serial numbers must not be covered, damaged or removed.
This may void the warranty on the product.
Ensure that all left over accessories, including remote controls and cables, are kept for future use. If replacements are
required in the future they will not be provided free of charge.
Please ensure the installation of this product will not interfere with any factory safety equipment (e.g. Airbags).
If working with Airbags, be sure to disconnect the vehicle Battery before beginning work. This product and
the following instructions are designed for installation by a qualified 12v installer, car audio installer or auto electrician.
Interfaces must not be installed in a location where they will be exposed to extreme
temperatures including, but not limited to, installation on top of a vehicles radio, transmission tunnel or firewall.
Damaged caused by exposure to heat is not covered under warranty.
Important Product Information
This product comes with a 2 year warranty against manufacturer related defects. Please read the included warranty card
and register the device on the Advanced ICE Pty Ltd website.
This installation manual covers a range of products and vehicles.
Contents
Page 1
1488_INS_V1.2
2
2
2
3
3
3
6
7
7
8
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1488 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advanced ICE 1488

  • Page 1: Table Of Contents

    • This product comes with a 2 year warranty against manufacturer related defects. Please read the included warranty card and register the device on the Advanced ICE Pty Ltd website. • This installation manual covers a range of products and vehicles.
  • Page 2: Required Tools For Installation

    Required Tools for Installation • Dash and Trim Removal tools • Dash Protection Tape (Recommended) • 10mm Socket Set Kit Contents Interface Remote LVDS Cable LVDS Extension Cable Infrared Eye (For Remote) Power & CAN T Harness Mode Switch Video Input Harness Interface Connection Ports Description Comments...
  • Page 3: Wiring Information

    Wiring Information Description Used For Connect Camera video signal for Video Input (F CAM) F - CAM cameras that can be viewed when driving Connect Camera video signal for Video Input (R CAM) cameras that can be viewed when in R - CAM reverse using RTC (see user manual) Video Input...
  • Page 4 Step 1 - Dash Removal Scan or click on the QR Code to watch the video on how to perform the dash removal in order to prepare for the installation. Step 2 - LVDS Video Cable Installation Connection Manual 1. Remove the Blue 90 degree LVDS Video connector from the APIM module and connect to the LVDS Extension cable (C).
  • Page 5 Step 3 - Power & CAN-Bus T Harness Installation Connection Manual 1. Carefully remove the 52pin locking connector (A) from the APIM module and connect to the female end of the provided Plug and Play T Harness (B). 2. Insert the supplied 52pin locking connection (C) of the T Harness into the APIM Module.nt 3.
  • Page 6: Mode Change And Operation

    Mode Change and Operation When Driving Long Press the OK button which is the systems Default Activation button to turn on the Camera Source. If additional camera inputs have been activated, then additional long press of this button will cycle through the camera inputs. In Reverse Long Press the OK button to switch from the vehicles factory reverse camera to the Camera input of our interface.
  • Page 7: Interface Menu Settings

    Interface Menu Settings Scan or click on the QR Code to watch the video on how to use the interface menus to configure the system. Vehicle Option Menu In the Vehicle Option Menu the following changes can be made: Car Model The car model menu is an important menu where the interface needs to be set for the correct car that it is being installed in.
  • Page 8: Setup System Menu

    Setup System Menu In the System Setup Menu the following options can be changed: Side Cam Detect This menu allows you to activate additional camera inputs, a total of 3 cameras are available while driving. • CAM OFF - Default One Camera input activated - This camera is always activated •...
  • Page 9: Trouble Shooting & Faqs

    Trouble Shooting & FAQs When I connect the interface I get no image on the factory screen, it’s black? A1. Please check to ensure that the LVDS Video Cables are connected the right way. The Cable with the Red Tape should be connected to the LVDS Video connector on the end - OEM IN. A2.
