Dimetix DLS-A 15 Reference Manual

Distance laser sensor

Advertisement

Quick Links

Distance Laser Sensor
DLS-A 15
DLS-A 30
DLS-AH 15
DLS-AH 30
Technical Reference Manual
V1.06
Please check www.dimetix.com
for the latest version
https://manual-hub.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLS-A 15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimetix DLS-A 15

  • Page 1 Distance Laser Sensor DLS-A 15 DLS-A 30 DLS-AH 15 DLS-AH 30 Technical Reference Manual V1.06 Please check www.dimetix.com for the latest version https://manual-hub.com/...
  • Page 2: Table Of Contents

    Table of Contents 1 Introduction...............................3 1.1 Product identification..........................4 1.2 Components.............................4 1.3 Validity..............................4 1.4 Measurement range..........................5 1.5 Prevention of erroneous measurements....................5 2 Device setup..............................6 2.1 Connection...............................6 2.2 Controlled mode............................7 2.3 Automatic mode............................8 3 Installation...............................10 3.1 Mounting..............................10 3.2 Device wiring............................10 3.3 Alignment of the laser beam........................12 4 Technical data..............................13 4.1 Measuring accuracy..........................13 4.2 Specifications............................14...
  • Page 3: Introduction

    • IP65 (protected against ingress of dust and water) • 4 LEDs for status signaling • Complementary configuration software available at Dimetix web site (www.dimetix.com) • Optional: Internal heater for module operation down to -40°C • Laser class II (<0.95mW) •...
  • Page 4: Product Identification

    1.1 Product identification The product is identified by the serial label on the top of the enclosure: Version Typical Accuracy 1.5mm 3.0mm Standard version DLS-A 15 DLS-A 30 Part No.: 500502 Part No.: 500501 Extended temperature range DLS-AH 15 DLS-AH 30 Part No.: 500512...
  • Page 5: Measurement Range

    ECHNICAL EFERENCE ANUAL 1.4 Measurement range The DLS-A(H) is an optical instrument, whose operation is influenced by environmental conditions. Therefore, the measurement range achieved in the application can vary. The following conditions may influence the measurement range: Factors increasing range Factors reducing range Target surface Bright and reflecting surfaces such as the...
  • Page 6: Device Setup

    To be able to configure the DLS-A(H), it must be powered and connected to a PC. Figure shows the necessary connections. On the PC, any terminal program can be used to communicate with the module. Additionally, a configuration utility is available on the web page www.dimetix.com. DLS-A(H)
  • Page 7: Controlled Mode

    (RS422), strict Master-Slave communication must be implemented (DLS-A(H) operates as slave). Please consult the Dimetix web page for application notes. Careful testing of the host software together with the devices prior to installation is strongly recommended.
  • Page 8: Automatic Mode

    ECHNICAL EFERENCE ANUAL 2.3 Automatic mode The automatic mode is provided for host-less operation of the DLS-A(H). The analog and digitals outputs are updated according the configuration described below as soon as the unit is powered up. Analog Output The analog output is configurable and works with two ranges: 0..20mA –...
  • Page 9 ECHNICAL EFERENCE ANUAL Action Comment Command Save settings The changed configuration must be saved to make it permanent. Example for module 0: s0s<trm> Save settings for module 0 Set automatic mode Set the DLS-A(H) to the automatic mode with the desired update rate. Example for module 0: s0A+0<trm>...
  • Page 10: Installation

    ECHNICAL EFERENCE ANUAL 3 Installation 3.1 Mounting Three M4 threaded holes in the bottom of the DLS-A(H) make it easy to mount the device. Always obey all applicable safety regulations and never use the device outside the specifications stated under 4 Technical data on page 13 3.2 Device wiring 3.2.1 Cable connection...
  • Page 11 ECHNICAL EFERENCE ANUAL 3.2.3 Controlled mode RS232 When using the RS232 interface only point-to-point communication is possible. ❢ Never connect multiple DLS-A(H)s on a RS232 serial line Host (PC or PLC) DLS-A(H) 9..30VDC 24..30VDC for DLS-AH 14,15 Fig. 4 Point-to-point connection with RS232 RS422 It is possible to connect multiple devices on a single RS422 line.
  • Page 12: Alignment Of The Laser Beam

    ECHNICAL EFERENCE ANUAL 3.2.4 Automatic mode The analog interface of the DLS-A(H) is isolated from the rest of the device. When using the analog interface, connect the analog ground (AGND). Make sure, that the total resistance in the analog path is smaller than 500 Ω. Analog Input AGND 0..20mA...
  • Page 13: Technical Data

    ECHNICAL EFERENCE ANUAL 4 Technical data 4.1 Measuring accuracy The measuring accuracy corresponds to the ISO-recommendation ISO/R 99.7% 1938-1971 with a statistical confidence level of 95.4% (i.e. ± twice the σ 95.4% standard deviation , refer to diagram on the right). The typical measuring accuracy relates to average conditions for measuring.
  • Page 14: Specifications

    ECHNICAL EFERENCE ANUAL 4.2 Specifications Typical measuring accuracy for DLS-A 15 / DLS-AH 15 ± 1.5 mm @ 2s DLS-A 30 / DLS-AH 30 ± 3.0 mm @ 2s Maximum measuring accuracy for DLS-A 15 / DLS-AH 15 ± 2.0 mm DLS-A 30 / DLS-AH 30 ±...
  • Page 15: Electrical Components

    ECHNICAL EFERENCE ANUAL 5 Electrical components 5.1 ID switch This switch is used to set the module ID and can be set from 0 to 9. 5.2 Reset switch To reset the module to factory settings do the following: Switch OFF the power for the module •...
  • Page 16: Connector

    ECHNICAL EFERENCE ANUAL 5.5 Connector 5.5.1 D-Sub connector Designator Description RS232 receive line RS232 send line RS422 send line negative RS422 send line positive RS422 receive line negative RS422 receive line positive DC Power + 9V…+30V for DLS-A +24V…+30V for DLS-AH (Heating option) DO 1 Digital output 1 (Open Drain) DO 2...
  • Page 17: Physical Dimensions

    ECHNICAL EFERENCE ANUAL 6 Physical dimensions 88.5 38.5 3 x M4 x 5 150.0 M16 x 1.5 Laser Beam 152.5 Measuring reference 33.3 80.0 All dimension in mm Distance Laser Sensor Page 17/40 https://manual-hub.com/...
  • Page 18: Factory Settings

    ECHNICAL EFERENCE ANUAL 7 Factory settings 7.1 Operation Mode: Controlled 7.2 Communication parameters Baud: 19200 Data bit: Parity: Even Stop bit: 7.3 Analog outputs Min output: Range min: Range max: Error output: 7.4 Module ID ID Number: 7.5 Digital output 1 (DOUT1) 2m + 5mm = 2005mm OFF: 2m - 5mm = 1995mm...
  • Page 19: Command Set

    ECHNICAL EFERENCE ANUAL 8 Command set 8.1 General 8.1.1 Command termination <trm> All commands for the DLS-A(H) are ASCII based and terminated with <trm> <cr><lf>. 8.1.2 Module identification N Since the module can be addressed with the ID switch, the ID is represented in the commands by .
  • Page 20 ECHNICAL EFERENCE ANUAL 8.2.3 Temperature measurement (sNt) Triggers measurement of temperature. Command input: sNt<trm> Module number (0..9) Return data Successful: gNt+xxxxxxxx<trm> temperature in 1/10°C +xxxxxxxx: Error: gN@Ezzz<trm> zzz: Error code 8.2.4 Laser ON (sNo) Switches laser ON. Command input: sNo<trm> Module number (0..9) Return data Successful:...
  • Page 21 ECHNICAL EFERENCE ANUAL 8.2.6 Tracking with buffering – Start (sNf) Triggers continuous measurement of the distance with internal buffering in the module (buffer for one measurement). The rate of measurements is defined with the sampling time. If the sampling time is set to zero, the measurements are executed as fast as possible.
  • Page 22: Configuration Commands

    ECHNICAL EFERENCE ANUAL 8.3 Configuration commands 8.3.1 Set communication parameter (sNbr) Sets the communication parameters for the serial interface. The new parameters are immediately saved to the Flash Memory and activated after the power Bold = default parameters (first use or after reset) Command input: sNbr+y<trm>...
  • Page 23 ECHNICAL EFERENCE ANUAL 8.3.3 Set analog output min level (sNvm) This command sets the minimum analog output current level (0 or 4 mA). Command input: sNvm+x<trm> Module number (0..9) Minimum output for analog out 0: Minimum signal is 0 mA 1: Minimum signal is 4 mA Return data: Successful:...
  • Page 24 ECHNICAL EFERENCE ANUAL 8.3.6 Set digital output levels (sNn) Sets the distance levels at which the digital outputs are switched ON and OFF with a hysteresis. Two different situations are possible: ON level > OFF level The ON level of the hysteresis is larger than the OFF level. With an increasing distance, the digital output is switched on (open drain closed output is closed) when the distance exceeds the ON level.
  • Page 25 ECHNICAL EFERENCE ANUAL 8.3.7 Save configuration parameters (sNs) This command saves all configuration parameters, which are set by the commands above. The parameters are written to the Flash Memory. Command input: sNs<trm> Module number (0..9) Return data: Successful: gNs?<trm> Error: gN@Ezzz Error code zzz:...
  • Page 26 ECHNICAL EFERENCE ANUAL 8.3.10 Get hardware version (sNN01N) Retrieves the hardware version of the DLS-A(H). Command input: sNN01N<trm> Module number (0..9) Return data Successful: gNN01N+xxxxxxyy<trm> Board number xxxxxx: Revision index Error: gN@Ezzz<trm> Error code zzz: 8.3.11 Get serial number (sNN02N) Retrieves the serial number of the DLS-A(H).
  • Page 27: Command Set For Single Module Operation (Compatibility)

    ECHNICAL EFERENCE ANUAL 8.4 Command set for single module operation (Compatibility) The commands described in this chapter are compatible with commands form the DISTO OEM Module 3.0. These commands only work properly for point-to-point connections of the serial interface from the module to the PC or any other controller.
  • Page 28 ECHNICAL EFERENCE ANUAL 8.4.5 Tracking (h) Triggers continuous measurement of the distance. The measurements are continued until the next command is issued or until a fault arises. The status LEDs and the digital outputs are updated corresponding to the new measured distance.
  • Page 29 ECHNICAL EFERENCE ANUAL 8.4.9 Laser OFF (p) Switches laser OFF. Command input: p<trm> Return data Successful: ?<trm> Error: @Ezzz<trm> Error code zzz: 8.4.10 Software version (N00N) Outputs software version at interface. Command input: N00N<trm> Return data Successful: 13..+xxxxyyyy<trm> Board version number xxxx: SW version number yyyy:...
  • Page 30 ECHNICAL EFERENCE ANUAL 8.4.13 Date of manufacture (N03N) Outputs the date of manufacture at the interface. Command input: N03N<trm> Return data Successful: > 15..+YYYYMMDD<trm year YYYY: month Error: @Ezzz<trm> Error code zzz: 8.4.14 Set communication parameter (N70N) Sets the communication parameters for the serial interface. The new parameters are immediately saved to the Flash Memory and activated after the next startup.
  • Page 31: Error Codes

    (contact Dimetix if error occurs at room temperature) Received signal too weak, distance < 200mm @E255 (Use different target and distances, if the problem persists, please contact Dimetix) Received signal too strong @E256 (Use different target and distances, if the problem persists, please contact Dimetix)
  • Page 32: Accessories

    ECHNICAL EFERENCE ANUAL 9 Accessories 9.1 Viewfinder The telescopic viewfinder can be used for easy alignment of the DLS-A(H) for long distances. Part Number Description 500100 Telescopic viewfinder 9.2 Target plates The target plates provide a defined measuring target. Please use the different sides for the distances as stated below: Front color brown, for measuring distances from 20 m to 200 m •...
  • Page 33: Cables

    ECHNICAL EFERENCE ANUAL 9.4 Cables Part Number Description PC-Connection cable: 500200 DLS-A(H) to - 9 pin D-Sub for PC (RS232) - 2 wires for power supply RS422-Connection cable: 500201 DLS-A(H) to - 5 wires for RS422 - 2 wires for power supply Connection cable for automatic mode: 500202 DLS-A(H) to - 2 wires for current output...
  • Page 34: Safety Instructions

    5) Carrying out modification or conversion of the product 6) Operation after failure in operation 7) Use of accessories from other manufacturers without the express approval of Dimetix. 8) Aiming directly into the sun 9) Deliberate dazzling of third parties; also in the dark 10) Inadequate safeguards at the surveying site (e.g.
  • Page 35: Limits To Use

    Responsibilities of the manufacturer of the original equipment Dimetix AG, CH-9100 Herisau (Dimetix): Dimetix is responsible for supplying the product, including the Technical Reference Manual and original accessories, in a completely safe condition. Responsibilities of the manufacturer of non-Dimetix accessories: The manufacturers of non-Dimetix accessories for the DLS-A(H) are responsible for developing, implementing and communicating safety concepts for their products.
  • Page 36: Hazards In Use

    ECHNICAL EFERENCE ANUAL 10.4 Hazards in use Important hazards in use WARNING: The absence of instruction, or the inadequate imparting of instruction, can lead to incorrect or prohibited use, and can give rise to accidents with far-reaching human, material and environmental consequences. Precautions: All users must follow the safety instructions given by the manufacturer and the directions of the person responsible for the instrument.
  • Page 37: Laser Classification

    ECHNICAL EFERENCE ANUAL WARNING: Operate the equipment appropriately in accordance with the regulations in force. Always prevent access to the equipment by unauthorized personnel. CAUTION: Be careful when pointing a telescope towards the sun, because the telescope functions as a magnifying glass and can injure eyes and/or cause damage inside the DLS-A(H).
  • Page 38: Electromagnetic Compatibility (Emc)

    WARNING: Electromagnetic radiation can cause interference in other equipment. Although the DLS-A(H) meets the strict regulations and standards that are in force in this respect, Dimetix cannot completely exclude the possibility that interference may be caused to other equipment. Distance Laser Sensor Page 38/40 https://manual-hub.com/...
  • Page 39: Labeling

    Laser Product EN 60825-1 (2001) Beam divergence 0.16 x 0.6 mrad Pulse duration 15x10 Max. radiant power* 0.95 mW Dimetix AG CH-9100 Herisau WWW.DIMETIX.COM Measurement uncertainty ±5% Made in Switzerland DLS-A 30 Max. radiant power per pulse 8 mW Type: Part No.:...
  • Page 40: Maintenance

    The DLS-A(H) is almost maintenance free. The only thing you have to do is cleaning the optical surfaces. CAUTION: Look after the optical surfaces with same care that you would apply to spectacles, cameras and field glasses. 10.9 Service If you need to service the device, please contact Dimetix for instructions. Dimetix AG Degersheimerstr. 14 CH-9100 Herisau Switzerland ©...

This manual is also suitable for:

Dls-a 30Dls-ah 15Dls-ah 30
