Summary of Contents for Baby Elegance Allta CR010
- Page 1 Allta Swing Instruction manual IMPORTANT ： PLEASE READ THE FOLLOWING INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Product Information
Product Information The Baby Elegance Allta swing provides a gentle and soothing natural rocking motion to calm your little one. Featuring Bluetooth connectivity, you can choose from classical pre-set tunes or stream your baby's favorite music right from your phone. -
Page 3: Safety Information
Safety Information PLEASE READ THE INSTRUCTIONS BEFORE ASSEMBLY AND KEEP THEM FOR FUTURE REFERENCE WARNING! • NEVER leave the child unattended. • DO NOT use this product once your child can sit unaided. • This product is not intended for prolonged periods of sleeping. •... - Page 4 Safety Information WARNING! CONTINUED • DO NOT let other children play with this product. • DO NOT use the product as a car seat. • DO NOT use the product near stairs. • DO NOT repair the product on your own and do not modify it. These operations can be performed only by an authorized service technician.
- Page 5 Safety Information SAFETY INSTRUCTIONS • DO NOT use the product if any components are broken or missing. • Powerful sway: Make sure that older child are not allowed to rock the baby too forcefully. • NEVER leave baby unattended. WARNING! Bouncer (max 20 lbs/9 kg): •...
- Page 6 Safety Information Name Electric baby bouncer chair Model No. CR010 Input voltage 100-240V～50/60Hz 0.3A Out voltage DC5.8V/1A Max. load capacity EN12790:2009/EN16232:2013+A1:2018 Standard EN71-1/EN71-2/EN71-3 Production date See the package or product label WARNING! 1）Power supply terminal must not short-circuit. 2）Never use the adapter provided not by the manufacturer， input voltage of adapter:100-240V～50/60Hz/0.3A MAX,Output voltage: DC5.8V/1A.
- Page 7 Components PLEASE CHECK THAT YOU HAVE ALL THE COMPONENTS LISTED BELOW BEFORE STARTING ASSEMBLY 1. Seat 2. Toy Bar 3. Mainframe base Also included: Manual 1 x Adapter 1 x Remote control...
- Page 8 Assembly Seat installation: 1a) Insert the seat into the mainframe base. 1b) Keep the seat D hole and mainframe base D iron shaft in the same direction. Insert the seat into mainframe base,then rotate the seat left and right slightly,then press down the seat after alignment.
- Page 9 Safety IMPORTANT Safety information when using the seat: Make sure that the straps are properly adjusted to snugly fit your baby, providing optimal comfort and safety. Always ensure your baby is securely fastened in their chair and never leave them unattended, as it can pose risks of harm.
- Page 10 Disassembly Seat disassembly: Push the sheet metal in and lift the seat up.
-
Page 11: Power Operation
Power operation Power supply: 1. DC plug can insert into the DC power of 100~240V,50/60Hz, 0.3A. 2. DC interface can be connected by power bank. 3. Output voltage:5.8V,electric current:1A. Never use the adapter of other specifications. 4. Never use the adapter provided not by the manufacturer. 5. -
Page 12: Battery Operation
Battery operation Battery assembly and disassembly: 1. Locate the battery compartment on the underside of the seat 2. Use a Phillips screwdriver to open the battery cover. 3. Load 4 x AAA alkaline dry batteries in the correct polarity. 4. Fasten the battery cover with screws. 5. -
Page 13: Guidelines For Operation
Guidelines for operation Panel function: Remote receiver Music Next tune/ volume play/pause adjustment Speeds Power switch Timing adjustment button Remote function: Music play/pause Power switch MUSIC Timer Timer Timing Last music VOL+ VOL- Music Switch inside music/Mp3 Next music Music Sleep mode Volume up VOL+... - Page 14 Guidelines for operation Bluetooth function: 1. Turn on bluetooth on your mobile phone. 2. Scan for available devices to connect with the swing chair. 3. Connect via bluetooth to wirelessly stream music from your phone to the chair. Turn on bluetooth Search bluetooth devces Paired devices Swing Chair...
- Page 15 Please don’t hesitate to contact us for any more information on this product hello@babyelegance.com This product is manufactured in China Made in China imported by Baby Elegance Baby Elegance Baby Elegance International House 205 Northwest Business Park 142 Cromwell Road...
