INSTRUCTION MANUAL FOR
INSTRUCTION MANUAL FOR
Combo Electrotherapy Device
Model: F100
Shenzhen Roundwhale Technology Co., Ltd.
This manual is valid for the F100 Stimulator
Be sure to read this instruction manual before operation and keep it
where safe.
This user manual is published by Shenzhen Roundwhale Technology
Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F100 and is the answer not in the manual?

Questions and answers

Related Manuals for Roundwhale F100

Summary of Contents for Roundwhale F100

  • Page 1 Combo Electrotherapy Device Model: F100 Shenzhen Roundwhale Technology Co., Ltd. This manual is valid for the F100 Stimulator Be sure to read this instruction manual before operation and keep it where safe. This user manual is published by Shenzhen Roundwhale Technology...
  • Page 2 However, Amendments will be published in a new edition of this manual. All Rights Reserved. F100 Rev. V1.1© 2024, printed on June. 28, 2024. Declaration of conformity: Shenzhen Roundwhale Technology Co., Ltd. declares that the device complies with following normative documents:...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. FOREWORD 2. SAFETY INFORMATION 3. GETTING TO KNOW YOUR DEVICE 4. SPECIFICATION 5. FOOT AND LEG STIMULATION 6. BODY STIMULATION 7. CLEANING AND MAINTENANCE 8. TROUBLESHOOTING 9. STORAGE 10. DISPOSAL 11. ELECTROMAGNETIC COMPATIBILITY (EMC) TABLES 28 12.

  • Page 4: Foreword

    1. FOREWORD 1.1 Introduction The device F100 is TENS (Transcutaneous Electrical Nerve Stimula- tion) and EMS (Electronic Muscle Stimulation) stimulator. Before us- ing, please read all the instructions in this user manual carefully and keep it safe for future use.

  • Page 5: Safety Information

    the body’s natural painkillers. 1.2.3 WHAT IS EMS ? Electrical Muscle Stimulation is an internationally accepted and prov- en way of treating muscular injuries. It works by sending electronic pulses to the muscle needing treatment that causes the muscle to exercise passively.
  • Page 6 upper extremities (arm) and lower extremities (leg) due to strain from exercise or normal household work activities. 2). Relaxation of muscle spasms. 3). Prevention or retardation of disuse atrophy. 4). Increasing local blood circulation. 5). Muscle re-education. 6). Immediate post-surgical stimulation of calf muscles to prevent venous thrombosis.
  • Page 7 with a communication handicap or a mental disability. 6）Patients with cerebrovascular problems-patients with a history of aneurysm, stroke and transient ischaemia shouldn’t be treated using electrical stimulation, as it stimulates peripheral blood flow which can be fatal in such cases. 7）Epileptic patients-Electrical stimulation “pulses”have the po- tential to trigger a seizure.
  • Page 8 of injury. 10) Apply stimulation only to normal, intact, clean, healthy skin. 11) The long-term effects of electrical stimulation are unknown. Elec- trical stimulation device cannot replace drugs. 12) Stimulation should not take place while the user is connected to high-frequency surgical equipment, which may cause burn inju- ries on the skin under the electrodes, as well as problems with the stimulator.
  • Page 9 3) TENS is a symptomatic treatment and, as such, suppresses the sensation of pain that would otherwise serve as a protective mechanism. 4) Effectiveness is highly dependent upon patient selection by a practitioner qualified in the management of pain patients. 5) Since the effects of stimulation of the brain are unknown, stim- ulation should not be applied across your head, and electrodes should not be placed on opposite sides of your head.

  • Page 10: Getting To Know Your Device

    ate the buttons on the control panel. 18) Check the electrode connections before each use. 19) Electrical stimulator should be used only with the electrodes rec- ommended for use by the manufacturer. 20) When output of device more than 10mA or 10 V, the intensity of Channel will filcker.
  • Page 11 USB cable User manual AAA battery 2PCS Remote controller 3.2 LCD display Function description Function description Treatment time Intensity for Body part Intensity for Foot Low battery indicator 3.3 Device illustration...

  • Page 12: Specification

    Output socket for body stimulation. 4. SPECIFICATION 4.1Technical information Device name Combo Electrotherapy Device Model/type F100 Power sources Foot massage device : d.c. 3.7 V Li-ion battery Remote controller : d.c. 3.0V 2*AAA batteries Power supply Input: 100-240V AC, 50/60Hz, 0.2A;...

  • Page 13: Foot And Leg Stimulation

    Output intensity 0-90V (At Load:1000 ohm) Treatment type: TENS and EMS mode Operating condition 5 ° C to 40 ° C with a relative humidity of 15%-93%, atmo- spheric pressure from 700 hPa to 1060 hPa Storage condition -10 ° C to 55 ° C with a relative humidity of 10%-95%, atmo- spheric pressure from 700 hPa to 1060 hPa Dimension 367 mm (L) x 361 mm (W) x 80.5 mm (H)
  • Page 14 5.2 Place both bare feet on to the footpads. Remove all socks and stockings and place bare feet onto the foot- pads. The arch of your foot should be positioned on the raised instep on the footpads. It does not matter if your feet are smaller or bigger than the footpads.
  • Page 15 5.5 Setting the treatment time Using the remote controller to set the treatment time, press [M] but- ton select set treatment time mode, and the symbol ' ' twinkles. Press [+] button or [-] button adjust treatment time. The LCD displays as follows: 5.6 Start treatment and adjust intensity In foot stimulation mode ' '.

  • Page 16: Body Stimulation

    Caution • We recommend using a heel balm on your feel to improve con- ductivity and stimulation. • Each person may require a different intensity level to obtain the optimal muscle stimulation. The device can safely be used on in- tensity level 1 to maximum level 90.
  • Page 17 6.2 Connect electrode wires to Foot massage device. Before proceeding to this step, ensure that the device is completely switched OFF. Hold the insulated portion of the electrode wire con- nector, and insert the plug into the receptacle on the bottom of the Foot massage device.
  • Page 18 Caution 1. Always remove the electrodes from the skin with a moderate pull in order to avoid injury in the event of highly sensitive skin. 2. Before applying the self-adhesive electrodes, it is recommended to wash and degrease the skin, and then dry it. 3.
  • Page 19 Hand Back Abdomen...
  • Page 20 Foot Joint (knee) Joint (elbow) Joint (ankle) Joint (wrist) 6.4 Turn on the device To turn on the device. Press the power button [+/ON] on the device. In the default setting, the display lights will read ' ' 30 minutes, ' 00 output intensity, ' ' 00 output intensity.
  • Page 21 6.5 Select set paremeter Using the remote controller to select treatment mode, press [M] but- ton select set treatment time mode ' ' , foot stimulation mode ' ' and body stimulation mode' 6.6 Setting the treatment time Using the remote controller to set the treatment time, press [M] but- ton select set treatment time mode, and the symbol ' ' twinkles.
  • Page 22 Caution • Each person may require a different intensity level to obtain the optimal muscle stimulation. The device can safely be used on in- tensity level 1 to maximum level 90. 6.8 Turn off the device To turn off the device. Press the [-] button on the device or press and hold the power button 3s on the remote control.
  • Page 23 • Make sure that the device is no longer connected to the patient (the output cables and electrodes must be disconnected). • Connect the USB cable to the charging port on the device. • Connect the USB cable to the charger. •...
  • Page 24 tion between the electrodes and the skin deteriorates over time. 7. The adhesive force of the electrodes depends on the skin proper- ties, storage condition, and the number of applications. If your elec- trode pads no longer fully stick to the skin's surface, replace them with new ones.

  • Page 25: Cleaning And Maintenance

    in such a way that the affected muscles are also enclosed by the electrodes. 7. CLEANING AND MAINTENANCE Fully comply with the following necessary daily maintenance re- quirements to make sure the device is intact and guarantee its long- term performance and safety. 7.1 Cleaning and care for the device 7.1.1 Pull the electrodes out of the stimulator, clean the device with a soft, slightly damp cloth.

  • Page 26: Troubleshooting

    sults of maintenance or repairs by unauthorized persons. 7.2.2 The user must not attempt any repairs to the device or any of its accessories. Please contact the retailer for repair. 7.2.3 Opening of the equipment by unauthorized agencies is not al- lowed and will terminate any claim to warranty.

  • Page 27: Storage

    1. Do the treatment once a day and 1.The treatment time lasts too shorten the treatment time. long. 2. Check and stick the electrode well. Rash or 2.The electrode does not stick 3. Wipe the electrode with a wet cot- tickle on well to the skin.

  • Page 28: Disposal

    10. DISPOSAL Spent batteries do not belong to the household wastes. Dis- posal of the battery according to the current regulations. As a consumer, you have the obligation to dispose of batteries correctly. Consult your municipal authority or your dealer for information about disposal.
  • Page 29 Guidance and manufacture’s declaration — electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such environment. IEC 60601 Test Compliance Electromagnetic Immunity test level...
  • Page 30 Power fre- Power frequency magnetic fields quency should be at levels characteristic of (50Hz/60Hz) 10V/m 10V/m a typical location in typical com- magnetic field mercial or hospital environment. IEC 61000-4-8 NOTE U is the a.c. mains voltage prior to application of the test level. Guidance and manufacture’s declaration –...
  • Page 31 NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic prop- agation is affected by absorption and reflection from structures, objects and people. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.

  • Page 32: Normalized Symbols

    1720 GSM1800; CDMA 1845 Pulse mod- 1700- 1900; GSM 1900; ulation 1990 DECT; LTE Band 1,3, 1970 217Hz 4,25; UMTS Bluetooth, WLAN, Pulse mod- 2400- 2450 802.11 b/g/n, RFID ulation 2570 2450, LTE Band 7 217Hz 5240 Pulse mod- 5100- 5500 WLAN 802.11 a/n ulation...

  • Page 33: Warranty

    Humidity Atmospheric pressure limitation limitation Caution Green Dot Users of the artificial pacemaker CE mark are prohibited from using the device Packaging material cycle mark Unique device identifier Medical device 13. WARRANTY Please contact your dealer or the device center in case of a claim un- der the warranty.
  • Page 34 servance of the user instruction. • All damages due to repairs or tampering by the customer or unau- thorized third parities. • Damage which have arisen during transport from the manufactur- er to the consumer or the service center. • Accessories which are subject to normal wear and tear. •...
  • Page 35 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 36 Shenzhen Roundwhale Technology Co., Ltd. Address: 202, 2/F, Building 27,Dafa Industrial Park，longxi commu- nity,longgang street, longgang district, Shenzhen, China. E-mail: info@roovjoy.com Shanghai International Holding Corp. GmbH(Europe) Address: Eiffestrasse 80,20537 Hamburg, Germany...
