Repair Guide
Basic Model
LS25BG402ENXGO
Applicable Model
LS**BG4*
Ver.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS BG4 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung LS BG4 Series

  • Page 1 Repair Guide Basic Model LS25BG402ENXGO Applicable Model LS**BG4* Ver.1.1...
  • Page 2: Table Of Contents

    Contents 1. Precautions 1-1. Safety Precautions ..........................1-1 1-1-1. Warnings ..........................1-1 1-1-2. Servicing the Product ......................1-1 1-1-3. Fire and Shock Hazard ......................1-1 1-1-4. Product Safety Notices ......................1-2 1-2. Servicing Precautions ........................1-3 1-2-1. General Servicing Precautions ...................1-3 1-3. Electrostatically Sensitive Devices (ESD) Precautions ..............1-4 1-4.
  • Page 3 Samsung- authorized service provider. Any damage or defect to product resulting from a repair, or an attempt to repair, the product by any person other than a Samsung certified service provider will not be covered by the warranty.
  • Page 4 Samsung’s liability in any case shall be limited to the greatest extent permitted by law. Samsung reserves the right, at its sole discretion, to change, modify, add or remove portions of any part of this manual at any time. It is your responsibility to check the manual periodically for changes. Your use of the manual...
  • Page 5: Precautions

    Precautions 1. Precautions 1-1. Safety Precautions • Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.
  • Page 6: Product Safety Notices

    Precautions 6. Observe the original lead dress, especially near the following areas: Antenna wiring, sharp edges, and especially the AC and high voltage power supplies. Always inspect for pinched, out-of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that no wires or components touch thermally hot parts.
  • Page 7: Servicing Precautions

    Following the repair by a non-authorised service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.
  • Page 8: Electrostatically Sensitive Devices (Esd) Precautions

    Precautions 1-3. Electrostatically Sensitive Devices (ESD) Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
  • Page 9: Installation Precautions

    Precautions 1-4. Installation Precautions 1. For safety reasons, more than a people are required for carrying the product. 2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. 3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.
  • Page 10: Disassembly And Reassemble

    This section of the service manual describes the disassembly and reassembly procedures for the Product. 1. Disconnect the Product from the power source before disassembly. 2. Follow these directions carefully. - Use the Samsung Open Jig and Cushion to remove the Rear Cover. • Open Jig Tool, Protection Cushion (curved models Only) CAUTION - Recommended Torque for Cabinet/Stand screws : 10 ~ 12kgf •...
  • Page 11: Cover Rear Disassembly

    Disassembly and Reassemble • After pushing up the stand fixing button, lift the stand and disassemble it. Remark 2-2. Cover Rear Disassembly • Use the OPEN JIG to disassemble the bottom LOCKING sequentially. Remark - Disassembly direction: from the center to both ends BN81-14946B (Open Jig) 8 Point...
  • Page 12 Disassembly and Reassemble • Lift from bottom to top and open. Remark...
  • Page 13: Main Pcb Disassembly

    Disassembly and Reassemble 2-3. Main PCB Disassembly • Disassemble 3 cables plugged into the main PCB. Remark (FFC CABLE, FUNCTION CABLE, LED CABLE) • Slightly lift the top of the MAIN PCB and lower it down to disassemble it. Remark * Screw for fixing when the fastening mechanism holder is damaged: 6003-000282 (2EA) 6003-000282 (M3xL8)
  • Page 14: Cover Rear Bottom Disassembly

    Disassembly and Reassemble 2-4. Cover Rear Bottom Disassembly • Bottom HOOK separation (8 locations) Remark - Disassembly direction: Disassembly from both ends to center Cover Decoration • Lift the latch on the dotted line display, release the fixation, and disconnect the cable. Remark...
  • Page 15 Disassembly and Reassemble • The screws (6 in total) on the three sides are decomposed, and COVER-FRONT is removed Remark and separated. 6001-003016 (M3xL5) • Decomposition complete. Remark • Reassembly procedures are in the reverse order of disassembly procedures. • The exterior may differ depending on the product. Note...
  • Page 16 Disassembly and Reassemble Task-oriented management items • The marked part is the fixed part of the wire.
