Ion Technologies Sumpro

Battery Back-Up

*** Attached with individual manuals for Ion BA75i

(BA Series) pumps and Ion Genesis controller. ***

Introduction

Reasonable care and safe methods should be

practiced. Check local codes and requirements

before installation. This manual contains important

information for the safe use of this product. Read

this manual completely before using this product and

refer to it often for continued safe product use.

Note: This manual covers the installation of the

inverter, regardless of what pump, switch or

controller combination is included in the system you

purchased. For more detailed installation information

and troubleshooting regarding the pump, switch or

controller, please refer to their individual manuals.

DO NOT THROW AWAY OR LOSE THIS MANUAL.

Keep it in a safe place so that you may refer to it when

needed.

Warning

WARNING: Always disconnect the Unit from

the receptacle power source and battery

before handling or making any adjustments to the

system.

Battery Backup Warning:

1. Risk of electrical shock this Unit has not been

investigated for use in outdoor areas.

www.ionproducts.net

OPERATION MANUAL

Dated: 07/08/2020

Document Name: SUMPRO_100_OM

2. Risk of electrical shock. Connect only to a

properly grounded, three pronged grounding

type receptacle. Under any circumstances,

do not remove the grounding prong from the

power cord.

3. Do not smoke, use sparkable electrical devices

or open flame when working on this unit!

4. Do not install Unit in locations classified as

hazardous per N.E.C., ANSI/NFPA 70 - 2014.

The Sumpro® is designed to operate a load up to

12 Amps. If operating more than one pump, the

combined FLA cannot exceed 12 Amps.

Important Safety Instructions

Before proceeding further, please review the safety

instructions carefully.

General Precautions:

•

Before using the inverter read all instructions

and caution markings on the inverter, the

batteries & all appropriate sections of this

instruction manual.

•

Do not expose the inverter to any type of

chemicals. The inverter is designed for interior

use only.

•

Do not disassemble the inverter; contact

Metropolitan Industries Wholesale Customer

Support at (800) 323-1665 when service or

repair is required. Opening by unqualified

personnel can lead to electrical shock or fire

hazard and void the warranty.

•

To reduce risk of electric shock, disconnect all

wiring before cleaning.

batteries generate explosive gases during normal

operation. Install the batteries in a well ventilated

area.

To reduce the risk of battery explosion, follow all the

instructions of the battery supplier or any equipment

you intend to use in the vicinity of batteries.

FAILURE TO HEED ABOVE CAUTIONS

COULD RESULT IN INJURY OR DEATH.

WARNING: Avoid exposing the inverter or

batteries to any type of explosive gases, as

Page 1 of 12

Table of Contents

Need help?

Do you have a question about the Ion Technologies Sumpro iB30102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Metropolitan Industries Ion Technologies Sumpro iB30102

Page 1 • Do not disassemble the inverter; contact and troubleshooting regarding the pump, switch or Metropolitan Industries Wholesale Customer controller, please refer to their individual manuals. Support at (800) 323-1665 when service or DO NOT THROW AWAY OR LOSE THIS MANUAL.
Page 2: Battery Safety
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 2 of 12 • Use the correct insulated tools to make AC/DC CAUTION: The electrolyte is a dilute sulfuric wiring connections. acid that is harmful to the skin and eyes. It is electrically conductive and corrosive.
Page 3: Tools Needed
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 3 of 12 Deep Cycle Batteries (RECOMMENDED) reach of the power cord. When fully assembled, the head unit with batteries weighs appoximately 200 Deep Cycle batteries, also known as marine batteries, lbs.
Page 4 Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 4 of 12 Figure A ALTERNATIVE DC INPUT ACCESS COVER BATTERY BOX MOUNTING SCREWS POSITIVE BATTERY LEAD AND TERMINAL FUSE LINK NEGATIVE BATTERY LEAD AND TERMINAL Detail A NEGATIVE TERMINAL POSITIVE TERMINAL...
Page 5 Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 5 of 12 Figure B BATTERY BOX LID SCREW ONE THIS SIDE AND ONE OPPOSITE SIDE Figure C DC1 TERMINALS DC2 TERMINALS 6P6C/RJ11 JACK REMOVE KNOCKOUT INSTALL FLEXIBLE METAL CONDUIT Plug the Sumpro...
Page 6: Testing The System
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 6 of 12 Please read the following instructions carefully before a. Blinks when alarm condition occurs and attempting to connect an alternative DC source. silence has NOT been pressed 1.
Page 7: Replacing Batteries
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 7 of 12 Replacing Batteries Wear full eye protection and protective clothing. When replacing the batteries, use the same type and size batteries. See battery requirements (Page 2). CAUTION: The electrolyte is a dilute sulfuric acid that is harmful to the skin and eyes.
Page 8: Troubleshooting
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 8 of 12 3. Clean all battery connections and leads with a Troubleshooting wire brush or sand paper. Even new batteries could have a slight coating on the connections Please read the following before calling in for technical support as these are the most common, and easiest that could cause issues.
Page 9: Battery Voltage
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 9 of 12 LCD Display Description Remedy Battery voltage when batteries are Normal Battery Voltage deemed present. 26.7 V Battery capacity when batteries Normal Battery Capacity are deemed present.
Page 10 Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 10 of 12 LCD Display Description Remedy The unit has suspended battery Battery charging will Cool Lock OFF: charging because it needs to cool resume after the timer off for a period of time.
Page 11: Warranty Registration Card
Ion Technologies Sumpro OPERATION MANUAL ® Dated: 07/08/2020 Battery Back-Up Document Name: SUMPRO_100_OM Page 11 of 12 Warranty Registration Card Please fill out and send back to: Metropolitan Ind. Warranty Department P.O. Box 7266 Romeoville, IL 60446. Or to register online, go to www.ionproducts.net Sumpro Warranty Registration Card ®...
Page 12 Page 12 of 12 3 Year Residential Warranty Coverage and Term. Metropolitan Industries, Inc. (“Metropolitan”) warrants to the original purchaser (the “Buyer”) of each Ion® product (the “product”), that any part thereof which proves to be defective in material or workmanship within three (3) years from date of manufacture, will be replaced at no charge with a new or remanufactured part, F.O.B.
Page 13 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 1 of 12 & M arks eanIngs DANGER: Keep the pump equipment out of the reach of children! Warns that the failure to follow the directions given could cause serious risk to individuals or objects.
Page 14 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 2 of 12 6. Piping: Plastic PVC pipe could be installed in the WARNING: The pump can be used for sea outlet piping, but drain hose, galvanized steel or water inflammable, corrosive,...
Page 15 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 3 of 12 then plug pump into the piggyback plug. See from water splashes. Before using the pump, Figure 2. always inspect it visually (especially power cable and plug). 12.
Page 16 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 4 of 12 the following: following: 1. Check valve is installed backwards. Arrow on 1. Pump impeller is partially clogged, causing motor to run slow and overload. Remove pump valve should point in direction of flow.
Page 17: Warranty
BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 5 of 12 VoId arranty The following may cause severe damage to pump and will void the warranty: 1. Using an extension cord. 2. Power cord has been cut or altered. 3.
Page 18: Safety Precautions
BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 6 of 12 CAUTION: Bottom of switch should not be mounted lower than suction inlet of pump. When installing the Ion switch with the pipe mounted ® bracket be sure not to set the switch too low or too high on the pipe.
Page 19 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 7 of 12 and national electrical codes. FIGURE C WARNING: Electrical outlet must not be located in pump pit. For best performance, do not use electrical extension cords. NSTALLATION RAWING 3”...
Page 20 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 8 of 12 range Ion switch. ® ROUBLESHOOTING c. For a pump-mounted switch, see Page Switch Does Not Turn On Pump 2, Figure D to verify that the On level is 1.
Page 21 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 9 of 12 otes www.ionproducts.net...
Page 22 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 10 of 12 otes www.ionproducts.net...
Page 23 BA Series OPERATION MANUAL Dated: 07/19/2022 Sump Pump Document Name: IonTechnologiesBASeries_OM Page 11 of 12 otes www.ionproducts.net...
Page 24 Page 12 of 12 3 Year Residential Warranty Coverage and Term. Metropolitan Industries, Inc. (“Metropolitan”) warrants to the original purchaser (the “Buyer”) of each StormPro/Sumpro product (the “product”), that any part thereof which proves to be defective in material or workmanship within three (3) years from date of manufacture, will be replaced at no charge with a new or remanufactured part, F.O.B.
Page 25: Pump Controller
Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 1 of 8 eneral verview Thank you for purchasing an Ion Genesis controller. ® Take the time to read the instructions carefully before using this appliance.
Page 26 METROPOLITAN INDUSTRIES, INC. TITLE: PROJECT: It is recommended that the system be tested by filling water level.
Page 27 Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 3 of 8 Emergency Run Time operation. If unsure about the settings, contact technical support. The Emergency Run Time is the minimum number of seconds a pump(s) will run when water has reached The controller has a menu of user-configurable the HIGH LEVEL SENSOR.
Page 28 Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 4 of 8 ault eScriPtion cceSSorieS The controller determines pump condition via its Ion Technologies 35AC built-in electrical current sensor.
Page 29 Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 5 of 8 eneSiS ialer nStallation ® Phone Line Ion Genesis ® Phone Dialer (optional) Pump 1 Power Cord Pump 2 Remote...
Page 30 Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 6 of 8 Figure 2: Duplex Operation – 2 pumps with similar current draw installed; both intended to run simultaneously when required.
Page 31 Ion Genesis II Pump Controller OPERATION MANUAL ® Dated: 07/10/2017 Digital Level Control with Pump Alternation Document Name: IonGenesisII_OM and High Water Alarm Page 7 of 8 Figure 5: Non-Alternating, Simplex Operation – 1 pump installed, only pump 1 will run. Pump 2 is disabled. Pump Number Open Remote...
Page 32 Page 8 of 8 3 Year Residential Warranty Coverage and Term. Metropolitan Industries, Inc. (“Metropolitan”) warrants to the original purchaser (the “Buyer”) of each Ion® product (the “product”), that any part thereof which proves to be defective in material or workmanship within three (3) years from date of manufacture, will be replaced at no charge with a new or remanufactured part, F.O.B.
