Summary of Contents for Inscape Data AirGoggle PTC 800
- Page 1 Quick Reference Guide PTC 800 Professional IP Video Joystick Rev.1.1 (January 2006)
- Page 2 12VDC 1.5 A User manual CD ROM Terminal Block (8 Pin) USB cable PTC 800 Airgoggle PTC 800 Professional IP Video Joystick Standard PTC 800 PAL or NTSC 2. Description: 2.1 The PTC 800 is a pan/tilt controller and it allows operators to perform the following functions : •...
- Page 3 The LCD is used to display current status as well as to provide a menu system for setting operational parameters. 2.2 Features: • Professional Controller • Any DVR with Mouse function • RS-485 Redundancy • Small sized • Battery powered •...
- Page 4 Fig. 2-2 NVM 1000 Tray icon 3. Select Serial Option. 4. Pop up serial setup window 5. Check COM PORT keyboard connected and set parameters like F2. 6. Operate USB keyboard. 7. How to operation special keys. A. Key, enters into 240 OSD menu : push a MENU button during 2 seconds. B.
