Summary of Contents for GF-SOL-AIR CVSammerwind

Page 1 Comfort Ventilation System CVS ® ® ® ® ammerwind Utilization guidance construction guidance...
Page 2 Labelling of the CE-marker: a) power supply label b) CVS case This declaration of the company GF-Sol-Air Gerhard Feustle , Raistinger Str. 3 , D 86911 Diessen, certifies the agreement with the mentioned regulations. The security advice of this delivered product documentation must be considered.
Page 3 The CVSammerwind creates a durable well-being! The handling and the use is simple. We recommend reading carefully this manual, before the first use of the Comfort Ventilation System (CVSammerwind). In this manual you will find our advice for the correct installation, handling, use and at- tendance.
Page 4: Table Of Contents
Specific value of the equipment Status display Air conversions energy value / loss Equipment elements Security advises Correct airing Function of the CVSammerwind Advantages and characteristics of the CVSammer- wind Operation modes For the cold season For the warm season...
Page 5: Scope Of Supply
Scope of supply Each CVSammerwind packet should include the following construction groups or rather components: Please control with the help of this packing note the completeness of the shipment. The component parts are nearly stored in the apparatus, remove these and store them at a safe place.
Page 6: Status Display
Status displays: Meaning LED-display Functions none Equipment plugged off/ Current supply is missing Orange yellow active Apparatus is working (Switch step. 1, 2 or. 3) Green ready Ventilator off ( Switch step. 0) Reserve For later functions Air exchange/ Energy values/ Losses Adjust- Air vol- Energy exchanges per hour...
Page 7: Machine Elements
Machine elements Entry of the exit air Entry of the mixed air Noise insula- tion Noise insula- tion Fred External air entry Magnet snatch Incoming air Exit air filter filter Electronic op- erating display Counterstream heatexchanger Volume ad- juster Outair exit Low voltage Condensation supply...
Page 8: Security Advises
It is recommended to pull the plug of the power supply or to switch off the CVS in the case of a thunder storm. For your own security you should only use accessories or original components of GF-SOL-AIR. GF-SOL-AIR is not responsible for arising damages our conse- quences in the case of nonadherence. Seite 8 von 32...
Page 9: Correct Airing
Energy dissipation comparison of different housetypes airing by window ref. controlled airing w. heat regain (at equal sized exchange rates) Zero Energy House (voluntary) Energy casualties Passive Energy House (voluntary) building Lowest Energy House EnEV 2002 airing by window (energy saving rule) contr.airing w.
Page 10 Here a little numeric example: − Flat with a living space of 120 m², construction height of 2,50m − Half air exchange per hours (0, 5 point air change per hour after DIN 1946, Part 2 Room air technique, healthy demands) −...
Page 11 Omni presented mould settle at this places, additionally there are ideal living con- ditions in order to spawn. Very fast, you will find ugly places with dark mould, which can be the reason for considerable construction damages. The spawning mould detaches spores in the air, for this reason you can find a high concentration of them in the interior room and they are the reason for different ill- nesses.
Page 12 mould Relationship of comfortability in dependency of temperature and humidity Illmaking substances in living-/working-rooms mildew bakterias, viruses mouldiness uncomfortably humide The comfortability field is like an island surrounded by many illmaking conditions mites comfortable Just controlled airing with heat regain achieves the comfortability field! The Comfort Ventilation System CVS®...
Page 13 air. The game begins again. In the night the relative humidity can increase to more than 100 % due to the long airing break. The result is condensation (at the windows and at cold walls). If the windows are continuously open or if the LWZ is adjusted too high, this brings a relative humidity of less Extending of humidity at uncontrolled airing by window...
Page 14 Warm seasons During hot an muggy summer days, there is the risk due to uncontrolled airing, the humidity values will increase too high in closed rooms, if the air outside contains a humidity of more than 60 %. The table shows the difference between uncontrolled airing with the door and the windows and with controlled airing via heat ex- changer.
Page 15: Function Of The Cvsammerwind
The Comfort Ventilation System CVSammerwind is an airing system for a con- trolled air exchange with a high effective heat recovery. It operates with the lowest energy input and passively working methods and bring a stabilization of the inter- nal temperature in the winter and in the summer.
Page 16: Advantages And Characteristics Of The Cvsammer
Due to a special reverse flow heat exchanger, the CVSammerwind is responsible that more than 85 – 95 % of the warmth or coolness of the used air will be trans- mitted to the incoming fresh air .With the help of this equipment, it will be not...
Page 17: Mode Of Operation
The electronic is trimmed on installation consumption. For the cold seasons: In the cold season you can see that the CVSammerwind is very economic con- cerning the heating costs. The used air – until now it was lost unused by airing – is also useful and heated the cold fresh air to room temperature.
Page 18 be deleted. Depending of the mix ratio, the incoming air is boosted on a level at the entry on the WT on which there is no freezing risk. In the case of a strong inhabitation of a room the humidity entry is very high, for this reason it is possible that there is a lot of condense water.
Page 19: For The Warm Season
For the warm seasons: Also during the warmer seasons, particularly during very hot summer days, we recommend you t use the appropriate mode for each room, in order to have a con- stant temperature in closed rooms for the whole day. This can be made without any particularly measures, thanks to the high efficient heat exchanger in the CVS to- gether with the construction dimension of the rooms which can be considered as a heat storage tank, particularly if there is an exterior insulation.
Page 20 The picture shows the air flow in the room. Given that the air flows vertical at the equipment, the whole room will be achieved. Consequently the Controlled Ventilation complete room will be venti- within Rooms lated. Dust and pollen filter Filters are optional and must be placed on the right side or on the left side on the net of the...
Page 21: Noise Emission
Depending of the dirt in the room you have to clean the CVSammerwind 4times a year or more with a hoofer. If necessary you have to clean some places with a soft brush.
Page 22: Guarantee
Core drill Ø 62mm diamond-studded, Length: wall thick + 5cm, • Alternative drill bit for socket outlets 65 Dm with extension 320mm • Drill template 0901-000016 (you can buy it at GF-Sol-Air) • Impact drill rock drill 4 and 6 mm •...
Page 23: Security Advice
Selection of the kind of construction It is possible to construct the CVSammerwind directly on the wall but also counter bored in the wall. In already existing buildings, people mostly choose the finery construction. In the case of our products, the room loss is vey low, but by a party counter bore in the wall it can be reduced.
Page 24 0, 7 points is also ok) beside a window. Avoid the construction of the CVSammerwind at tight room corners. The closeness of big furniture can handicap the air flow. High cupboard should be moved away for some centimetres from the wall in order to guarantee a ventilation at any place.
Page 25 62 mm 6 mm zeichnen Mark of the drill holes In order to mark the drill holes, please use the delivered hole pattern of carton as model, please consider that the holes for the outgoing and incoming air are on the right side and use a water level for an exactly alignment of the CVS.
Page 26 2. Drilling of the drilling lead-through Kronenbohrer 62 Ø Please consider the security advices! Consider during the drilling a down-grade of 2 -5° outwards. In order to drill you use a core drill with a diameter of 62 mm and a appropriate drilling Bodenplatten- machine, most suitable one with a Hoover, this befestigung...
Page 27 2a. Alternative drilling method In lieu of a core driller it is also possible to work with a drill bit for socket outlets with extension flagpole. In order to get straight openings you have to use a long stone drill for the drilling, which also shows a fall to outside. The drilling serves as guidance for the centring drill of the drill bit for socket outlets (dm up to 68 mm), which only allows a limited drill depth.
Page 28 Durchbrüche in abwechselnder Folge made of the Upu-can. Please consider the Kollissionsfilter Kollissionsfilter advises in the chapter current supply. Now you can fix the CVSammerwind at the wall. Lüftermotor Abluft Lüftermotor Zuluft Lüftermotor Abluft Here it must be considered that the foamed...
Page 29: Power Supply
With the choice of the variable volume adjustments and with the closure of the door, a durable wellbeing begins – due to the Comfort Ventilation System CVSammerwind. Power supply Standard-power supply: A switcher typed wall-plug, which contains at the end of the cable a phone jack adapter of the size 5, 5/2,5mm, will be delivered.
Page 30 Pipe adapter: There are tools for craftsmen in order to facilitate the installation of the CVS. The most craftsmen have a lot of experience with core bits and their power, but an ex- actly drilling in two directions through a wall is a big claim concerning force and concentration, which is mostly impossible to execute alone.
Page 31 We advise to let execute the maintenance or re- pairing by this merchant. 86911 Dießen Phone. (++49) (0)8807 92 40 8-0 Fax. –8, -9 Email: gf-sol-air@t-online.de Homepage: www.gf-sol-air.de Please store this guide at a secure place, like other manuals in order to have it to your disposal at any time.
