Summary of Contents for IAS D-SPX-2
- Page 1 D-SPX-2 D-SPX-3 D-SPX-4 nstallatIon anual Singlepoint www.ias.net.au...
-
Page 2: Table Of Contents
SINGLEPOINT INSTALLATION MANUAL Contents The Singlepoint Controller ....................3 Operating Instructions ......................3 System Overview ........................3 Singlepoint Touchpad ..................... 3 Motorised Dampers ......................4 Cabling Requirements ..................... 4 Component Positioning ....................4 Spill Zones ........................... 4 Commissioning.......................... 4 Operating Instructions ......................5 Technical specifications ...................... -
Page 3: The Singlepoint Controller
SINGLEPOINT INSTALLATION MANUAL InglepoInt ontroller Singlepoint is an economical, easy to install wall controller that operates independently of the air conditioning plant to provide on/off zoning control for two to four zones. Features include: • Integrated sensor or optional remote room sensor (not included) Select the integrated sensor or the optional remote room sensor. -
Page 4: Motorised Dampers
Install the jumper for spill zone operation. Commissioning Some of the motor sockets are not used in the D-SPX-2 and D-SPX-3 models. On the D-SPX-2 model, only the centre two sockets are used. On the D-SPX-3 model, the bottom socket (farthest from the power connection) is not used. -
Page 5: Operating Instructions
Avoid electromagnetic radiation sources Avoid dust contamination Avoid highly corrosive environments Troubleshooting Guide Further assistance may be obtained from IAS Service and Support on 1800 354 434 if needed. Symptom Suggested Remedial Action Red Fault LED is lit on motor Excess current draw on output. -
Page 6: Connection Diagram
SINGLEPOINT INSTALLATION MANUAL onneCtIon IagraMs 2 Zone Connections Transformer Zone 1 Damper Unused Socket Spill Set Jumper Zone 2 Damper 3 Zone Connections Zone 1 Damper Transformer Zone 2 Damper Spill Set Jumper Zone 3 Damper 4 Zone Connections Zone 1 Damper Transformer Zone 2... -
Page 7: Innocab Cable Crimping Instructions
The heart of the system is the Inno-cab cable. It is available with or without shielding. 6 core unshielded cable 5 core + 1 shielded cable IAS cat# RM-CAB-6-100 IAS cat# RM-CAB-S-100 Brown Yellow Green Red White Drain Blue Yellow Green Red Black White IMPORTANT NOTES: Inno-cab connections are polarity conscious. - Page 8 SINGLEPOINT INSTALLATION MANUAL Product Support Freecall 1800 354 434 www.ias.net.au support@ias.net.au National Sales Phone: 1300 306 125 sales@ias.net.au Ver. 2010.08 Distributed in Australia by Innovative Air Systems Pty Ltd...
