Adventure Series Sliders: Jeep JL-JLRS4A
Installation Instructions
*** Please read through instructions before starting installation
Congratulations for purchasing TNT, Inc. Adventure Series Sliders for your Jeep
JL. Begin by unpacking your kit and comparing the contents of the box to the
packing list at the end of this manual. Please observe proper shop safety
procedures when performing this install. Use proper eye and hearing protection
as required.
Tools Needed:
Drill
5/16" drill bit
9/16" Socket
10mm Socket
18mm socket
Ratchet or Impact
Master Your Terrain
(307) – 775 – 9565
www.tntcustoms.com
Advertisement
Summary of Contents for TNT Adventure Series
- Page 1 Installation Instructions *** Please read through instructions before starting installation Congratulations for purchasing TNT, Inc. Adventure Series Sliders for your Jeep JL. Begin by unpacking your kit and comparing the contents of the box to the packing list at the end of this manual. Please observe proper shop safety procedures when performing this install.
- Page 2 STEP 1: Remove factory sliders if equipped. STEP 2: Using an 18mm socket remove the body mount bolts from the two body mounts under rear door. Use a 10mm socket to remove body mount nuts that are located beside the body bolts. STEP 3: If equipped use an 18 mm socket to remove the 2 bolts (one on each side) holding the factory front skid plate to the frame.
- Page 3 STEP 6: Repeat installation steps for opposite side. Figure 2...
- Page 4 Packing List Parts List 1. Driver side Adventure series Slider 2. Passenger side Adventure series Slider 3. Hardware kit Hardware Kit: • 12 (3/8” X 1”) Thread Cutting bolts • 2 (12mm -1.5 X 35 mm) bolts • 2 (12mm) washer...
