PORTABLE MAGNETIC DRILLING MACHINE
Read this manual carefully before operating your Nitto Kohki
Portable Magnetic Drilling Machine. Keep this manual with
your machine. All users of the Nitto Kohki Portable Magnetic
Drilling Machine must read this manual.
ATRA ACE
Professional Tool
Model
Power Supply (Single Phase)
Rated Power Consumption
Rated Current
Drill motor
No-load Speed
Load Speed
Magnet Power Consumption
HI-BROACH One-touch type
AUSTBROACH
Drilling Capability
Twist Drill
Max Magnetic Force
Magnet Size
Weight
The specifi cations and confi gurations contained in this document are subject to
change without prior notice due to improvements we are making day in, day out.
Keep the manual handy – so you can use it whenever necessary.
Model WO-3200
For One-Touch Type Annular Cutter Only
(Side-Lock Type Annular Cutter cannot be used.)
Specifi cations
Hole diameter MAX. φ32 mm (1-1/4")
Plate thickness MAX.
MAX. 13 mm (1/2")
99 mm x 177 mm (3-7/8" x 7")
WO-3200
220-240 V 〜 50/60 Hz
950 W
4.3 A
-1
530 min
(rpm)
-1
350 min
(rpm)
70 W
50 mm (2")
9000 N (2028lbs.)
13 kg (28.7lbs.)
Manufactured by :
Nitto Kohki Co., Ltd.
2-9-4, Nakaikegami, Ota-ward,
Tokyo, 146-8555, Japan
Tel : 81 (3) 3755-1111
Fax : 81 (3) 3753-8791
Advertisement
Table of Contents
Related Manuals for Atra Ace WO-3200
Summary of Contents for Atra Ace WO-3200
- Page 1 Portable Magnetic Drilling Machine. Keep this manual with your machine. All users of the Nitto Kohki Portable Magnetic Drilling Machine must read this manual. ATRA ACE Model WO-3200 Professional Tool For One-Touch Type Annular Cutter Only (Side-Lock Type Annular Cutter cannot be used.) Specifi...
-
Page 2: Table Of Contents
CONTENTS page GENERAL SAFETY RULES ………………………………… 2 T h a n k y o u v e r y m u c h f o r y o u r POWER TOOL SAFETY ……………………………………… 3 purchase of Nitto Kohki products. Before using your machine, please ABOUT YOUR NITTO PORTABLE MAGNETIC …………………………………………... -
Page 3: General Safety Rules
ABOUT THE WORK AREA GENERAL SAFETY RULES Keep Work Area Clean Always keep your work area clean. Cluttered work WARNING ● areas cause accidents. Always keep clear of other TO OPERATORS objects. Always Wear Proper Clothing Never use the magnetic drilling machine when it is ● ... -
Page 4: Power Tool Safety
drilling machine. Always remove all adjustment tools with a damaged or worn pilot pin. Do not operate the before using the drilling machine. machine with any damaged accessory. Operating Always Use a Cutter that is Appropriate for Your the machine with any damaged part or accessory Work can cause accidents and severe injuries. -
Page 5: About Your Nitto Portable Magnetic
is damaged. burn injury. Never use the Magnet for more than Always use a ground fault circuit interrupter. The use fi ve continuous hours. When you are not using the ● of a ground fault circuit interrupter may be required Magnet, turn the switch to the OFF position and pull by government regulations. - Page 6 plate is necessary to boost the holding power of the Magnet.(Fig.3) Use of an inappropriate back-up plate can result in an accident, If the back-up plate is not thick enough or big enough, the machine will come loose during operation. This can result in an accident and severe injuries.
- Page 7 ● Do not use Cutting Oil for other purposes. electricity will run through the Atra Ace machine Cutting Oil should be used only for drilling. Please v i a i t s M a g n e t , c a u s i n g p o s s i b l e f a i l u r e o r ● ...
-
Page 8: Application
Package Contents Q’ty Check ATRA ACE 1set Pilot Pin 08050 Hex. Socket Screw Key 3 Spanner 8X10 Rod Handle Safety Strap... -
Page 9: Functions Of Electronic Control
5 MACHINE SETUP 4 FUNCTIONS OF ELECTRONIC CONTROL WARNING 4-1. Overload Detecting Function When setting up machine, turn off the Magnet ● The electric drill shuts down automatically when it Switch and disconnect the power supply plug is overloaded to prevent the drill or the blade from from power source. - Page 10 (1) Bring the Drill Motor up by turning the Rod Handle with rust inhibitor, etc. containing nitrite. clockwise. (Fig. 10) Wear safety glasses for eye protection when ● handling Cutting Oil: eye injury may results if it gets into your eyes. Wear protective gloves for hand protection when ●...
-
Page 11: Machine Operation
as industrial waste in accordance with the local laws Hex. Soc. Button Head Screw 8X15 and regulations. Washer 30X8.2X3.2 Treat flushing water through pH adjustment, ● condensation/sedimentation, activated sludge process, activated carbon adsorption, etc., and discharge it in accordance with the regulations of your local municipal bylaw. - Page 12 Drill Motor ON (Fig.16) (3) Aligning with Punch Mark. ● Turning the Motor Switch ON starts the Drill Motor. Turn the Rod Handle counterclockwise to slightly lower the cutter and align the tip of Pilot Pin to the MAGNET MOTOR punch mark.
- Page 13 (9) Finishing Drilling Operation WARNING Jet Oiler (TQ05273) Be careful about chips. ● Do not touch the slug. ● Do not use your hands to remove chips. ● After completion of drilling operation, lift the Drill Motor and turn OFF the Motor Switch (Fig. 25). Oil ling When the Drill Motor stops, immediately turn OFF Tube 4X7X1000...
-
Page 14: How To Use A Twist Drill
(2) Attaching the Adapter Attach the Adapter that is sold separately to the unit. The Adapter can be attached using the same method as shown in “5-4 Mounting/Removing Cutter.” File away any excesses (3) Attaching the drill Fig. 28 Turn the circumference ring on the drill chuck to the left (counterclockwise) to widen out the 6-4. -
Page 15: Troubleshooting
8 TROUBLESHOOTING WARNING Never attempt to repair machine yourself: injury or damage to equipment may result. ● Please feel free to consult the sales agent through which you have purchase your machine or an ● authorized dealer, when the following symptoms appear or when you have any questions about our products. -
Page 16: Maintenance & Service
9 MAINTENANCE/SERVICE WARNING Always disconnect the power and turn off the ● switch before attempting any maintenance. Failure to disconnect the power and turn off the switch during set up, inspection or maintenance can cause accidents and severe injuries. Check to see periodically that mounting screws ●... -
Page 17: Optional Parts
10 OPTIONAL PARTS Cutting chips 10-1. Nitto-Brand Cutting Oil CAUTION Cutter Use Nitto-brand Cutting Oil for Atra Ace. Part No. Part Name TB02621 Cutting Oil 2ℓ (Light Blue) Pilot Pin Fig. 31 10-2. Pilot Pin (metric size) 9-6. Cutter Regrinding Part No. - Page 18 Jet Oiler Tube 4×7×1000 Hex. Socket Head Cap Screw 5×12 Fig. 35 10-7. Chip Breaker 0.3~0.5mm Blade Chip Breaker Ass’y Part No. Part Name Fig. 36 TB07691 Chip Breaker Ass’y TQ11523 Blade (1) Mount Blade Base. (Fig.36) (TP01945) Hex. Socket Head Cap Screw 5×12 Use the Hex.
-
Page 19: Ordering Parts
10-8. Cutter Hi-Broach One-Touch Type 25L(metric sizes) Part No. Size(mm) Part No. Part Name Part No. Part Name Part No. Part Name TK00698 12 X25 TK00336 18 X25 TK00343 22.5X25 TK00351 27 X25 TK00699 13 X25 TK00337 19 X25 TK00344 23 X25 TK00352 28 X25... - Page 22 81 Anson Road #08-39 Singapore 079908 Tel: 6227-5360 Fax: 6227-0192 NITTO KOHKI AUSTRALIA PTY. LTD. 77 Brandl Street Brisbane Technology Park Eight Mile Plains QLD4113, AUSTRALIA Tel: (07)3340-4600 Fax: (07)3340-4640 READ ALL INSTRUCTIONS BEFORE OPERATING THIS TOOL ATRA ACE Model WO-3200 PROFESSIONAL TOOL Printed in JAPAN TQ11365...
