Summary of Contents for Alpha Networks MT-WN713NM
- Page 1 MT-WN713NM 150M WIRELESS USB MODULE User’s Manual Release 0.1...
- Page 2 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required.
- Page 4 The MT-WN713NM which is based on the RT5370, is a 802.11 b/g/n wireless embedded Mini-PCI module for AP/ Router + AP. MT-WN713NM will be a RF module of AP board. It has greater throughput at longer range. The MT-WN713NM is a green product.
-
Page 5: Installation
Installation Turn on the computer and Insert the Alpha WUS-N10 Driver CD in the CD-ROM drive When the auto run screen appears, click Install Drivers. The Install Shield Wizard window will appear. By default setup will install to the default location: To install to a different location click Browse and specify the location. - Page 6 Usage Guidelines for FCC Compliance Antenna In order to maintain compliance with FCC regulations,This module has been tested with the following antennas: nix Part Number Antenna Type Antenna Gain DTS Part Number Antenna Type Antenna Gain ANT-2400-01A 1.3 dBi Module Modification The module must not be physically altered in any way.
