Version 2.00 | 2015/07/07
User Manual
Wireless N450 Home Router
DIR-629

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIR-629 and is the answer not in the manual?

Questions and answers

Related Manuals for D-Link DIR-629

Summary of Contents for D-Link DIR-629

  • Page 1 Version 2.00 | 2015/07/07 User Manual Wireless N450 Home Router DIR-629...

  • Page 2: Preface

    Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description 1.00 November 11, 2013 • Initial release for revision A1 2.00...

  • Page 3: Table Of Contents

    Internet Connection Setup Wizard .......24 Advanced Wireless ............67 Internet (Manual) ..............30 Wi-Fi Protected Setup (WPS) ........68 Static (assigned by ISP) ..........32 Advanced Network Settings ........70 PPPoE (DSL) ..............33 Tools ..................71 PPTP ..................35 Admin.................71 L2TP ..................37 Time ..................73 D-Link DIR-629 User Manual...
  • Page 4 Connect a Wireless Client to your Router ......87 WPS Button ...................87 Windows® 8 ...................88 WPA/WPA2 ................88 Windows® 7 ...................90 WPA/WPA2 ................90 WPS ..................93 Windows Vista® ................97 WPA/WPA2 ................98 WPS/WCN 2.0 ..............100 Windows® XP ................101 WPA/WPA2 ................. 102 D-Link DIR-629 User Manual...

  • Page 5: Product Overview

    Wi-Fi Configuration Note If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage rating than the one included with the DIR-629 will cause damage and void the warranty for this product.

  • Page 6: System Requirements

    Utility Requirements Microsoft Internet Explorer® 7, Mozilla® Firefox® 9.0, Google® Chrome 16.0, or Safari® 4 or higher Windows Users: Make sure you have the latest version of Java ® installed. Visit www.java.com to download the latest version. D-Link DIR-629 User Manual...

  • Page 7: Introduction

    Section 1 - Product Overview Introduction The D-Link DIR-629 is an IEEE 802.11n compliant device that delivers up 300 mbps of wireless bandwidth while staying backward compatible with 802.11n/g/b devices. Connect the DIR-629 to a Cable or DSL modem and provide high-speed Internet access to multiple computers, game consoles, and media players.

  • Page 8: Features

    Section 1 - Product Overview Features • Ultimate Fast Wireless Networking - The DIR-629 provides up to 300 Mbps of wireless bandwidth in the 2.4 GHz band. This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio. The performance of this 802.11n wireless router gives you the freedom of wireless networking at speeds faster than 802.11g.

  • Page 9: Hardware Overview

    Connector for the supplied power adapter. Press the button and hold for 1-7 seconds to activate WPS-PBC Discovery Mode. Reset & WPS Press the button and hold for at least 8 seconds to reset the router to the Button default settings. D-Link DIR-629 User Manual...

  • Page 10: Leds

    This LED blinks during WPS handshake phase. WLAN LED A solid light indicates that the wireless segment is ready. 5 Local Network LEDs A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4. D-Link DIR-629 User Manual...

  • Page 11: Installation

    • If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoet, Broadjump, or Enternet 300 from your computer or you will not be able to connect to the Internet. D-Link DIR-629 User Manual...

  • Page 12: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

  • Page 13: Manual Setup

    3. Unplug the Ethernet cable from your modem (or existing router if upgrading) that is connected to your computer. Plug it into the LAN port labeled 1 on the back of your router. The router is now connected to your computer. DIR-629 Computer D-Link DIR-629 User Manual...
  • Page 14 7. If you are connecting to a Broadband service that uses a dynamic connection (not PPPoE), you may be online already. Try opening a web browser and enter a web site. If a solid light indicates a connection on the Internet port, the router should be able to connect to the Internet. D-Link DIR-629 User Manual...

  • Page 15: Configuration

    There are several different ways you can configure your router to connect to the Internet and connect to your clients: • D-Link Setup Wizard - This wizard will launch when you log into the router for the first time. Refer to page 12.

  • Page 16: Quick Setup Wizard

    If this is your first time logging into the router, this wizard will start automatically. This wizard is designed to guide you through a step-by-step process to configure your new D-Link router and connect to the Internet. Click Next to continue. Step 1: Configure Your Internet Connection Please wait while your router detects your Internet connection type.
  • Page 17 Internet connection you have, this screen will appear. Click Guide me through the Internet Connection Settings to display a list of connection types to choose from. Select your Internet connection type and click Next to continue. D-Link DIR-629 User Manual...
  • Page 18 ISP. Click Next to continue. If the router detected or you selected L2TP, enter your L2TP username, password, and other information supplied by your ISP. Click Next to continue. D-Link DIR-629 User Manual...
  • Page 19 Click Next to continue. Step 1: Set Your Password In order to secure your router, please enter a new password. Check the Enable Graphical Authentication box to enable CAPTCHA authentication for added security. Click Next to continue. D-Link DIR-629 User Manual...
  • Page 20 If you want to create a bookmark to the router, click OK. Click Cancel if you do not want to create a bookmark. If you clicked Yes, a window may appear (depending on what web browser you are using) to create a bookmark. D-Link DIR-629 User Manual...

  • Page 21: Qrs Mobile App

    Note: The following steps show the Android interface of the QRS Mobile app. If you are using an iPhone, iPad, or iPod touch, the appearance may be different to that of the screenshots, but the process is the same. D-Link DIR-629 User Manual...
  • Page 22 At this point, please ensure that you the router is connected to a modem. Plug one end of the provided Ethernet cable into your DSL or cable modem, and plug the other end into the port marked INTERNET on the DIR-629. Tap Next to automatically detect your Internet connection and proceed to the next step.
  • Page 23 Enter the administrator password of your choice. Unlike the Wi-Fi password, this password is only required when you need to configure the router. See Quick Setup Wizard on page 19 for details of when this password is used. Tap Next to proceed. D-Link DIR-629 User Manual...
  • Page 24 Notify me when new firmware is available box and tap Next. Otherwise, just tap Next to proceed. Step 9 You will be presented with a summary of your chosen settings. Tap Save to complete the setup. D-Link DIR-629 User Manual...
  • Page 25 Share By NFC, Share By E-mail, or tap Finish to exit the app. If you tap Share By NFC, you can now touch the tag with your other device until the confirmation message appears. Note: NFC is not supported by iPhone, iPad, and iPod touch devices. D-Link DIR-629 User Manual...

  • Page 26: Web-Based Configuration Utility

    Section 3 - Configuration Web-based Configuration Utility To access the configuration utility, open a web-browser such as Internet Explorer and enter address of the router http:/dlinkrouter.local./ or http://192.168.0.1. Leave the password blank by default. D-Link DIR-629 User Manual...

  • Page 27: Internet Connection Setup

    Click Manual Internet Connection Setup to configure your connection manually and continue to the next page. If you want to configure your router to connect to the Internet using the wizard, click Internet Connection Setup Wizard. You will be directed to the Quick Setup Wizard. D-Link DIR-629 User Manual...

  • Page 28: Internet Connection Setup Wizard

    Click Next to continue. Step 1: Set Your Password By default, the D-Link Router does not have a password configured for ad- ministrator access to the Web-based configuration pages. To secure your new networking device, please enter and verify a password in the spaces provided.

  • Page 29: Step 3: Internet Connection

    Choose this option if your Internet connection requires an L2TP username and password to get online. Static IP Choose this option if your Internet Setup Provider provided you with IP Address: Address information that has to be manually configured. D-Link DIR-629 User Manual...
  • Page 30 User Name: Enter the PPPoE account user name used here. This information is given by the ISP. Password: Enter the PPPoE account password used here. This information is given by the ISP. Click Next to continue. D-Link DIR-629 User Manual...
  • Page 31 Enter the Secondary DNS IP address used here. This field is normally op- DNS Address: tional. Only one DNS address is required for a functional Internet connec- tion, but using a second DNS address provides more stability. Click Next to continue. D-Link DIR-629 User Manual...
  • Page 32 Enter the Secondary DNS IP address used here. This field is normally op- DNS Address: tional. Only one DNS address is required for a functional Internet connec- tion, but using a second DNS address provides more stability. Click Next to continue. D-Link DIR-629 User Manual...

  • Page 33: Setup Complete

    Only one DNS address is required for a functional Internet connec- tion, but using a second DNS address provides more stability. Setup Complete! This is the last page of the Internet Connection Setup Wizard. Click the Connect button to save your settings. D-Link DIR-629 User Manual...

  • Page 34: Internet (Manual)

    The options available to choose from are Static IP, Dynamic IP, PPPoE, PPTP, L2TP, and DS-Lite. After selecting a specific Internet Connection type, this page will automati- cally refresh and provide unique configuration fields related to the specified Internet Connection type. D-Link DIR-629 User Manual...
  • Page 35 MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. D-Link DIR-629 User Manual...

  • Page 36: Manual Internet Setup

    Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Copy Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. D-Link DIR-629 User Manual...

  • Page 37: Internet Setup

    Use the radio buttons to specify the reconnect mode. The user can specify Mode: a custom schedule or specify the On Demand, or Manual option. To specify a custom schedule, use the drop-down menu to select one of the schedules that has been defined in the Schedules page. D-Link DIR-629 User Manual...
  • Page 38 Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. To create a new schedule, click the New Schedule button to open the Schedules page. Schedules will be discussed later. D-Link DIR-629 User Manual...

  • Page 39: Pptp

    Enter the PPTP Server IP address used here. This is normally the same a IP Address: the PPTP Gateway IP address. Username: Enter the PPTP username used here. Password: Enter the PPTP password used here. Verify Re-enter the PPTP password used here. Password: D-Link DIR-629 User Manual...
  • Page 40 MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. D-Link DIR-629 User Manual...

  • Page 41: L2Tp

    Enter the L2TP Server IP address used here. This is normally the same a the IP Address: L2TP Gateway IP address. Username: Enter the L2TP username used here. Password: Enter the L2TP password used here. Verify Re-enter the L2TP password used here. Password: D-Link DIR-629 User Manual...
  • Page 42 MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card. D-Link DIR-629 User Manual...

  • Page 43: Wireless Connection Setup Wizard

    Click on the Prev button to return to the previous page. Click on the Next button to continue to the next page. Click on the Cancel button to discard the changes made and return to the main wireless page. D-Link DIR-629 User Manual...
  • Page 44 Click on the Save button to accept the changes made. After click the Save button the device will save the settings made and return to the main wireless page. End of Wizard. D-Link DIR-629 User Manual...

  • Page 45: Wi-Fi Protected Setup Wizard

    Click on the Prev button to return to the previous page. Click on the Next button to continue to the next page. Click on the Cancel button to discard the changes made and return to the main wireless page. D-Link DIR-629 User Manual...
  • Page 46 Click on the Wire- less Status button to navigate to the Status > Wireless page to view what wireless client are connected to this device. End of Wizard. D-Link DIR-629 User Manual...

  • Page 47: Manual Wireless Network Setup

    Here the user can manually select the preferred frequency band to use for this wireless network. Enable Auto The auto channel selection setting can be selected to allow this device to Channel choose the channel with the least amount of interference. Scan: D-Link DIR-629 User Manual...
  • Page 48 If you are not using encryption then they could connect to your network. When Invisible mode is enabled, you must enter the Wireless Network Name (SSID) on the client manually to connect to the network. D-Link DIR-629 User Manual...

  • Page 49: Wireless Security

    Section 3 - Configuration Wireless Security This section will show you the different levels of security you can use to protect your data from intruders. The DIR-629 offers the following types of security: • WPA2 (Wi-Fi Protected Access 2) • WPA2-PSK (Pre-Shared Key) •...

  • Page 50: Wireless Security Mode

    You may also enter any text string into a WEP key box, in which case it will be converted into a hexadecimal key using the ASCII values of the charac- ters. A maximum of 5 text characters can be entered for 64-bit keys, and a maximum of 13 characters for 128-bit keys. D-Link DIR-629 User Manual...
  • Page 51 Interval: Pre-Shared Enter the shared secret used here. This secret phrase needs to be the Key: same on all of the wireless clients for them to be able to connect to the wireless network successfully. D-Link DIR-629 User Manual...
  • Page 52 RADIUS Server Enter the shared secret used here. This secret phrase needs to be the Shared Secret: same on all of the wireless clients for them to be able to connect to the wireless network successfully. D-Link DIR-629 User Manual...

  • Page 53: Network Settings

    Enter the Domain name (Optional). Domain: Enable DNS Uncheck the box to transfer the DNS server information from your ISP to your Relay: computers. If checked, your computers will use the router for a DNS server. D-Link DIR-629 User Manual...

  • Page 54: Dhcp Server Settings

    DHCP Server Settings DHCP stands for Dynamic Host Control Protocol. The DIR-629 has a built-in DHCP server. The DHCP Server will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.
  • Page 55 WINS servers available, however, it is preferred you try M-Node operation first. This setting has no effect if the ‘Learn NetBIOS information from WAN’ is activated. WINS IP Enter your WINS Server IP address(es). Address: D-Link DIR-629 User Manual...

  • Page 56: Dhcp Reservation

    MAC Address, and IP address. List: Enable: Check to enable the reservation. Edit: Click the edit icon to make changes to the reservation entry. Delete: Click to remove the reservation from the list. D-Link DIR-629 User Manual...

  • Page 57: Advanced

    You can create your own times in the Tools > Schedules section. Inbound Select Allow All (most common) or a created Inbound filter. You may create Filter: your own inbound filters in the Advanced > Inbound Filter page. D-Link DIR-629 User Manual...

  • Page 58: Port Forwarding

    You can create your own times in the Tools > Schedules section. Inbound Select Allow All (most common) or a created Inbound filter. You may create Filter: your own inbound filters in the Advanced > Inbound Filter page. D-Link DIR-629 User Manual...

  • Page 59: Application Rules

    “Trigger Port” field, select the protocol type as TCP or UDP, then enter the firewall (public) ports associated with the trigger port to open them for inbound traffic. The DIR-629 provides some predefined applications in the table on the bottom of the web page. Select the application you want to use and enable it.

  • Page 60: Qos Engine

    ISP. ISP’s often define speed as a download/upload pair. For example, 1.5 Mbits/284 Kbits. Using this example, you would enter 1500. Alternatively you can test your downlink speed with a service such as www.dslreports.com. D-Link DIR-629 User Manual...
  • Page 61 In this column the Queue Priority used will be displayed. Priority: Queue After choosing to use the Weight Fair Queue option, under Queue Type, Weight: the user will be able to manual enter the Queue Weight for each individu- al Queue ID. D-Link DIR-629 User Manual...
  • Page 62 0.0.0.1 to 255.255.255.254. Application Enter the application port number used here. Port: Click on the Save Settings button to accept the changes made. Click on the Don’t Save Settings button to discard the changes made. D-Link DIR-629 User Manual...

  • Page 63: Network Filters

    To find the MAC address on a computer, please refer to the Networking Basics Address: section in this manual. DHCP Client: Select a DHCP client from the drop-down menu and click << to copy that MAC Address. D-Link DIR-629 User Manual...

  • Page 64: Inbound Filters

    Inbound This section will list any rules that are created. You may click the Edit icon Filter Rules to change the settings or enable/disable the rule, or click the Delete icon List: to remove the rule. D-Link DIR-629 User Manual...

  • Page 65: Access Control

    P2P utilities or games. Add Policy: Click the Add Policy button to start the Access Control Wizard. Access Control Wizard Click Next to continue with the wizard. D-Link DIR-629 User Manual...
  • Page 66 Select IP address, MAC address, or Other Machines. IP Address Enter the IP address of the computer you want to apply the rule to. Machine Enter the PC MAC address (i.e. 00:00.00.00.00). Address Select the filtering method and then click Next to continue. D-Link DIR-629 User Manual...
  • Page 67 Enter the starting port number. Start Dest Port End Enter the ending port number. To enable web logging, click Enable. Click Save to save the access control rule. Your newly created policy will now show up under Policy Table. D-Link DIR-629 User Manual...

  • Page 68: Website Filters

    Select either DENY computers access to ONLY these sites or ALLOW Add Website computers access to ONLY these sites. Filtering Rule: Enter the keywords or URLs that you want to allow or block. Click Save Website URL/ Settings. Domain: D-Link DIR-629 User Manual...

  • Page 69: Firewall Settings

    Firewall Settings A firewall protects your network from the outside world. The DIR-629 offers a firewall type functionality. The SPI feature helps prevent cyber attacks. Sometimes you may want a computer exposed to the outside world for certain types of applications.
  • Page 70 NAT. Some VoIP applications and devices have the ability to discover NAT devices and work around them. This ALG may interfere with the operation of such devices. If you are having trouble making VoIP calls, try turning this ALG off. D-Link DIR-629 User Manual...

  • Page 71: Advanced Wireless

    Enable this option to reduce interference from other wireless networks in Coexistence: your area. If the channel width is operating at 40 MHz and there is another wireless network’s channel over-lapping and causing interference, the router will automatically change to 20 MHz. D-Link DIR-629 User Manual...

  • Page 72: Wi-Fi Protected Setup (Wps)

    Restore the default PIN of the router. Default: Generate Create a random number that is a valid PIN. This becomes the router’s PIN. New PIN: You can then copy this PIN to the user interface of the wireless client. D-Link DIR-629 User Manual...

  • Page 73: Wps Button

    You can also simply press and hold the button on the back of the router for 1-7 seconds to activate WPS-PBC Discovery Mode, and then press the WPS button on your wireless client to automatically connect without logging into the router. Refer to page page 87 for more information. WPS Button D-Link DIR-629 User Manual...

  • Page 74: Advanced Network Settings

    UPnP provides compatibility with networking equipment, software and peripherals. WAN Ping: Checking the box will allow the DIR-629 to respond to pings. Unchecking the box may provide some extra security from hackers. WAN Port You may set the port speed of the Internet port to 10 Mbps, 100 Mbps, or Speed: Auto (recommended).

  • Page 75: Tools

    Management interface. Management: Remote The port number used to access the DIR-629 is used in the URL. Example: http://x.x.x.x:8080 whereas x.x.x.x is the Internet IP address of the DIR-629 Admin Port: and 8080 is the port used for the Web Management interface.
  • Page 76 This section will list any rules that are created. You may click the Edit icon to change the settings or enable/disable the rule, or click the Delete icon to Inbound Filter: remove the rule. Details will display the current status. DIR-629 D-Link DIR-629 User Manual...

  • Page 77: Time

    To manually input the time, enter the values in these fields for the Year, Month, Day, Hour, Minute, and Second and then click Set Time. You can also click Sync. Your Computer’s Time Settings to synch the date and time with the computer you are currently on. D-Link DIR-629 User Manual...

  • Page 78: Syslog

    The address of the SysLog server that will be used to send the logs. You may Server IP also select your computer from the drop-down menu (only if receiving an IP Address: address from the router via DHCP). D-Link DIR-629 User Manual...

  • Page 79: Email Settings

    Selecting this option will send the logs via email according to schedule. Schedule: This option is enabled when On Schedule is selected. You can select a schedule from the list of defined schedules. To create a schedule, go to Tools > Schedules. D-Link DIR-629 User Manual...

  • Page 80: System

    Settings: have created. If you want to save the current router configuration settings, use the Save button above. Reboot Click to reboot the router. Device: D-Link DIR-629 User Manual...

  • Page 81: Firmware

    You can upgrade the firmware of the access point here. Make sure the firmware you want to use is on the local hard drive of the computer. Click on Browse to locate the firmware file to be used for the update. Please check the D-Link support website for firmware updates at http://support.dlink.com.

  • Page 82: Dynamic Dns

    Username or Enter the Username or key for your DDNS account. Key: Password or Enter the Password or key for your DDNS account. Key: Timeout: Enter a timeout time (in hours). Status: Displays the current connection status. D-Link DIR-629 User Manual...

  • Page 83: System Check

    The Ping Test is used to send Ping packets to test if a computer is on the Internet. Enter the IP address that you wish to Ping and click Ping. Ping Results: The results of your ping attempts will be displayed here. D-Link DIR-629 User Manual...

  • Page 84: Schedules

    You must click Save Settings at the top for your schedules to go into effect. Schedule The list of schedules will be listed here. Click the Edit icon to make changes Rules List: or click the Delete icon to remove the schedule. D-Link DIR-629 User Manual...

  • Page 85: Status

    Device Info This page displays the current information for the DIR-629. It will display the LAN, WAN (Internet), and Wireless information. If your Internet connection is set up for a Dynamic IP address then a Release button and a Renew button will be displayed. Use Release to disconnect from your ISP and use Renew to connect to your ISP.

  • Page 86: Logs

    This option will send a copy of the router log to your email address configured in the Tools > Email Settings screen. Save Log: This option will save the router log to a file on your computer. D-Link DIR-629 User Manual...

  • Page 87: Statistics

    Statistics The screen below displays the Traffic Statistics. Here you can view the amount of packets that pass through the DIR-629 on both the WAN, LAN ports and the wireless segments. The traffic counter will reset if the device is rebooted.

  • Page 88: Internet Sessions

    The Internet Sessions page displays full details of active Internet sessions through your router. An Internet session is a conversation between a program or application on a LAN-side computer and a program or application on a WAN-side computer. D-Link DIR-629 User Manual...

  • Page 89: Wireless

    Section 3 - Configuration Wireless The wireless client table displays a list of current connected wireless clients. This table also displays the connection time and MAC address of the connected wireless clients. D-Link DIR-629 User Manual...

  • Page 90: Support

    Section 3 - Configuration Support D-Link DIR-629 User Manual...

  • Page 91: Connect A Wireless Client To Your Router

    WPS. Once you know, follow the steps below: Step 1 - Press the WPS button on the side of DIR-629 for 1-7 seconds. If held longer than 8 seconds the router will reset. The Internet LED on the front will start to blink.

  • Page 92: Windows® 8

    To join an existing network, locate the wireless network icon in the taskbar, next to the time display. Wireless Icon Clicking on this icon will display a list of wireless networks which are within connecting proximity of your computer. Select the desired network by clicking on the network name. D-Link DIR-629 User Manual...
  • Page 93 WPS button on your router at the point to enable the WPS function. When you have established a successful connection a wireless network, the word Connected will appear next to the name of the network to which you are connected. D-Link DIR-629 User Manual...

  • Page 94: Windows® 7

    If you are joining an existing network, you will need to know the security key or passphrase being used. 1. Click on the wireless icon in your system tray (lower-right corner). Wireless Icon 2. The utility will display any available wireless networks in your area. D-Link DIR-629 User Manual...
  • Page 95 If you get a good signal but cannot access the Internet, check your TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. 4. The following window appears while your computer tries to connect to the router. D-Link DIR-629 User Manual...
  • Page 96 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DIR-629 User Manual...

  • Page 97: Wps

    Section 4 - Connecting to a Wireless Network The WPS feature of the DIR-629 can be configured using Windows® 7. Carry out the following steps to use Windows® 7 to configure the WPS feature: 1. Click the Start button and select Computer from the Start menu.
  • Page 98 Section 4 - Connecting to a Wireless Network 3. Double-click the DIR-629. 4. Input the WPS PIN number (on the router label or in the Setup > Wireless Setup menu in the Router’s Web UI) and click Next. D-Link DIR-629 User Manual...
  • Page 99 Section 4 - Connecting to a Wireless Network 5. Type a name to identify the network. 6. To configure advanced settings, click the icon. Click Next to continue. D-Link DIR-629 User Manual...
  • Page 100 Make a note of the security key as you may need to provide this security key if adding an older wireless device to the network in the future. 9. Click Close to complete WPS setup. D-Link DIR-629 User Manual...

  • Page 101: Windows Vista

    (displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check you TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DIR-629 User Manual...

  • Page 102: Wpa/Wpa2

    1. Open the Windows Vista® Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower right corner of screen). Select Connect to a network. 2. Highlight the Wi-Fi name (SSID) you would like to connect to and click Connect. D-Link DIR-629 User Manual...
  • Page 103 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DIR-629 User Manual...

  • Page 104: Wps/Wcn 2.0

    Reset PIN to Default button. If you are using third party software to set up Wi-Fi Protection, carefully follow the directions. When you are finished, proceed to the next section to set up the newly-configured router. D-Link DIR-629 User Manual...

  • Page 105: Windows® Xp

    Wi-Fi network (displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check you TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DIR-629 User Manual...

  • Page 106: Wpa/Wpa2

    1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 2. Highlight the Wi-Fi network (SSID) you would like to connect to and click Connect. D-Link DIR-629 User Manual...
  • Page 107 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The Wi-Fi password must be exactly the same as on the wireless router. D-Link DIR-629 User Manual...

  • Page 108: Troubleshooting

    1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.
  • Page 109 • Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your web management.
  • Page 110 • Windows® 95, 98, and Me users type in command (Windows® NT, 2000, XP, Vista®, and 7 users type in cmd) and press Enter (or click OK). • Once the window opens, you’ll need to do a special ping. Use the following syntax: ping [url] [-f] [-l] [MTU value] Example: ping yahoo.com -f -l 1472 D-Link DIR-629 User Manual...
  • Page 111 • To change the MTU enter the number in the MTU field and click Save Settings to save your settings. • Test your email. If changing the MTU does not resolve the problem, continue changing the MTU in increments of ten. D-Link DIR-629 User Manual...

  • Page 112: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

  • Page 113: What Is Wireless

    D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. How does wireless work? Wireless works similar to how cordless phone work, through radio signals to transmit data from one point A to point B.
  • Page 114 Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home • Gives everyone at home broadband access •...

  • Page 115: Tips

    The wireless connection in public places is usually called “hotspots”. Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like: Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.

  • Page 116: Wireless Modes

    • Ad-Hoc – Directly connecting to another computer, for peer-to-peer communication, using wireless network adapters on each computer, such as two or more DIR-629 wireless network Cardbus adapters. An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point.

  • Page 117: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 118: Statically Assign An Ip Address

    Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step 5 Click OK twice to save your settings. D-Link DIR-629 User Manual...

  • Page 119: Technical Specifications

    IEEE 802.11g: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps • IEEE 802.11b: 11, 5.5, 2, and 1 Mbps Antenna Type • Three fixed external 5 dBi dipole antennas Wireless frequency range may vary according to regional regulations. D-Link DIR-629 User Manual...

  • Page 120: Regulatory Information

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. D-Link DIR-629 User Manual...
  • Page 121 20 cm between the radiator and your body. Warning This unit is to be used with a power supply, Model AMS135-1201000FU or MU12AR120100-A1. Avertissement Cet appareil doit etre utilise avec une source de courrant, modele AMS135-1201000FU ou MU12AR120100-A1. D-Link DIR-629 User Manual...
  • Page 122 • This device is restricted from functioning in Ad-hoc mode while operating in 5 Ghz. Ad-hoc mode is direct peer-to-peer communication between two client devices without an Access Point. • Access points will support DFS (Dynamic Frequency Selection) and TPC (Transmit Power Control) functionality as required when operating in 5 Ghz within the EU. D-Link DIR-629 User Manual...
  • Page 123 Spectrum Regulation MHz, Europa (ETSI) max. EIRP Innenbereich max. EIRP Außenbereich Europa 2400 - 2483.5 MHz 100 mW 100 mW 2400 - 2454 MHz 100 mW 100 mW Frankreich 2454 - 2483.5 MHz 100 mW 10 mW D-Link DIR-629 User Manual...

  • Page 124: European Community Declaration Of Conformity

    Appendix D - Regulatory Information European Community Declaration of Conformity: D-Link tímto prohlašuje, že tento DIR-629 je ve shodě se základními požadavky a dalšími Česky [Czech] příslušnými ustanoveními směrnice 1999/5/ES. Undertegnede D-Link erklærer herved, at følgende udstyr DIR-629 overholder de Dansk [Danish] væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 125 D-Link declara que este DIR-629 está conforme com os requisitos essenciais e outras Português [Portuguese] disposições da Directiva 1999/5/CE. D-Link izjavlja, da je ta DIR-629 v skladu z bistvenimi zahtevami in ostalimi relevantnimi Slovensko [Slovenian] določili direktive 1999/5/ES. D-Link týmto vyhlasuje, že DIR-629 spĺňa základné požiadavky a všetky príslušné...

  • Page 126: Safety Instructions

    D-Link may result in the loss of product warranty. Unless expressly approved by an authorized representative of D-Link in writing, you may not and may not permit others to: • Disassemble or reverse engineer the device or attempt to derive source code (underlying ideas, algorithms, or structure) from the device or from any other information provided by D-Link, except to the extent that this restriction is expressly prohibited by local law.
  • Page 127 • Install the power supply before connecting the power cable to the power supply. • Unplug the power cable before removing the power supply. • If the system has multiple sources of power, disconnect power from the device by unplugging all power cables from the power supplies. D-Link DIR-629 User Manual...
  • Page 128 • Always unplug the power before cleaning this device. • Do not use liquid or aerosol cleaners of any kind. Use only compressed air that is recommended for electronic devices. • Use a dry cloth for cleaning. D-Link DIR-629 User Manual...
  • Page 129 Environmental This product may contain a battery. Recycle or dispose of batteries in accordance with the battery manufacturer's instructions and local/national disposal and recycling regulations. For more information, please refer to the warranty guide. D-Link DIR-629 User Manual...
  • Page 130 D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.
  • Page 131 Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
  • Page 132 En D-Link, comprendemos y estamos comprometidos con la reducción del impacto que puedan tener nuestras actividades y nuestros productos en el medio ambiente. Para reducir este impacto, D-Link diseña y fabrica sus productos para que sean lo más ecológicos posible, utilizando materiales reciclables y de baja toxicidad tanto en los productos como en el embalaje.
  • Page 133 D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
  • Page 134 Firma D-Link zaleca, aby Państwo zawsze prawidłowo wyłączali z użytku swoje produkty D-Link, gdy nie są one wykorzystywane. Postępując w ten sposób pozwalają Państwo oszczędzać energię i zmniejszać emisje CO2.
  • Page 135 D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné...
  • Page 136 D-Link og miljøet Hos D-Link forstår vi oss på og er forpliktet til å minske innvirkningen som vår drift og våre produkter kan ha på miljøet. For å minimalisere denne innvirkningen designer og lager D-Link produkter som er så miljøvennlig som mulig, ved å...
  • Page 137 Suosittelemme, että irrotat D-Link-tuotteesi virtalähteestä tai sammutat ne aina, kun ne eivät ole käytössä. Toimimalla näin autat säästämään energiaa ja vähentämään hiilidioksiidipäästöjä.
  • Page 138 På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.

Table of Contents
